User manual
Massage Chair :
Purpose of use, effect-efficacy
Substitution of massage for home-use
• Thank you very much for purchasing Fujiiryoki massage chair.
• Carefully read this operation manual before use and only use as directed.
• Please read the safety precautions on pages 2-8 before use.
• Keep this operation manual where it will be readily available for future referral.
• Please recycle the outer packaging material where possible.
MR380
general designation: household electric massage chair
Before use
. .. . .. . .. . .. . .. . .. . .. . .. . .. . .. . .. . .. . ..
. .. . .. . .. . .. . .. . .. . .. . .. . .. . .. . .. . .. . .. . .. . .. . .. . . .
. .. . .. . .. . .. . .. . .. . .. . .. . .. . .. . .. . .. . .. . .. . .
How to use
. .. . .. . .. . .. . .. . .. . .. . .. . .. . .. . .. . .. .
Overhauland maintenance methods
. .. . .. . .. . .. . .. . .. . .. . .. . .. . .. . .. . .. . .. . .. . ..
. .. . .. . .. . .. . .. . .. . .. . .. . .. . .. . .. . .. . .
home use
Category: machinery and appliances
. .. . .. . .. . .. . .. . .
11
15
19
. .. . .. . .. . .. . .. . .. . .. . .. . .. . .. . .
22
23
24
47
48
2
9

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MR380 and is the answer not in the manual?

Questions and answers

Summary of Contents for Synca MR380

  • Page 1: Table Of Contents

    User manual MR380 Massage Chair : Category: machinery and appliances general designation: household electric massage chair Before use ....• IMPORTANT SAFETY INSTRUCTIONS ........
  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS • Read these "Important Safety Instructions" before use and use this product properly • These important safety instructions are prescribed to ensure correct usage of the product, and to prevent injury and damage to the user and other persons. •...
  • Page 4 IMPORTANT SAFETY INSTRUCTIONS Never use pins or other metallic fasteners with this appliance. Carefully examine the covering before each use. Discard the appliance if the covering shows any sign of deterioration, such as checking, blistering, or cracking. Use weak stimulation massage when you start to use. Injury may occur.
  • Page 5 Never operate the appliance with the air openings blocked. Keep the air openings free of lint, hair, and the like. Never drop or insert any object into any opening. To disconnect, turn all controls to the off position, than remove plug from outlet. The appliance is intended for household use.
  • Page 6 IMPORTANT SAFETY INSTRUCTIONS...
  • Page 7 This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
  • Page 8 IMPORTANT SAFETY INSTRUCTIONS...
  • Page 9: Place Massage Chair

    Place massage chair Installation location Make sure there is enough space so that the massage chair can be tilted, and the back end of CAUTION the massage chair should be at least 12in away from the wall. 12 in Do not expose the massage chair to direct sunlight or high-temperature environments (such as in front of heating equipment).
  • Page 10 Place massage chair Mobile method Use the rear casters to move the massage chair. According to the method shown in the picture, tilt CAUTION the chair downwards and backwards about 45° to move it. Note: Do not press down too much to avoid prod- uct damage due to complete tipping of the chair.
  • Page 11: Before Use

    Before use Check around Make sure there are no people, pets, or other objects around the unit. CAUTION...
  • Page 12 Before use Anti-pinch safety1:warning signs Please ensure there are no foreign objects in the gaps of the device before use. Before starting the massage, make sure there are no obstructions in the calf, foot, and other areas. Under no circumstanc- es should hands, feet, or head be insert- ed into the area between the calf mecha- nism and the body, as well as the area...
  • Page 13 Anti-Pinch Safety 2: Automatic Pinch Prevention Function Pinch Sensing Explanation The lower part of the backrest of this device is equipped with an anti-pinch function. During the reclining/upright movement, if an object touches the anti-pinch sensing area, the anti-pinch function is triggered, and the device enters pause mode. Remove the object from under the backrest, and press the pause button to resume the reclining/upright movement.
  • Page 14 Before use Calf description Turn on the power CAUTION Product access power cord Power on instructions Turn on the power switch ("I" position) WARNING...
  • Page 15: Product Structure

    Product Structure Component Descriptions: Ambient Light Headrest Speaker Cover Armrest Quick Keys Mobile Phone Slot Seat Side Airbags Armrest Leg massage structure Side Panel Cushion Can be placed on the back or on the seat.
  • Page 16 Product Structure Functional Distribution Head: Speakers Head and neck on both sides to seat Built-in healing music 2D movement Bluetooth connectivity massage for playing music from your phone Waist Heating function Buttocks: Airbag massage Legs Airbag massage, Heating function...
  • Page 17 Product Structure I. Explanation of Right Armrest Quick Keys: Power Button Technique Button Auto Massage Speed Adjustment Air Pressure Button Spot, Partial, Heating Button Full Body Massage Built-in Music and Pause Button Bluetooth Speaker Switch Roller (Wheel)
  • Page 18 Product Structure button Button name describe Short press to turn the device on or off. Power button Long press to enter reclining mode. Manual massage program, refer to page 20 in the Technique Button instruction manual for details. Adjusts the massage speed during manual massage Speed Adjustment programs.
  • Page 19: Operation Instructions

    Operation Instructions II. Start Massage 1.Press the power button to activate the massage chair, and the backrest will automatically adjust its angle. 1.2 Select the auto program: Press the " " key to choose the automatic program (you can select other automatic programs by pressing the "...
  • Page 20 Operation Instructions Manual Massage: Function Button Describe Deep Blue Kneading Variable-speed Kneading Green Violet Tapping Orange Variable-speed Tapping Technique Kneading + Tapping Blue Yellow Variable speed kneading + variable speed Tapping Circular Kneading Purple Shiatsu Rose Three adjustable modes (Full Body, Partial, Fixed Point). Full-length reciprocating massage Small-range partial reciprocating massage Massage...
  • Page 21 1.Enter the main menu of the smart device, open "Settings," select the "Bluetooth" option, turn on "Bluetooth," and automatically "Search for new Bluetooth devices." 2. The device will search for the corresponding Bluetooth model (MR380-XXXXXXX). Click the pairing button. If asked to pair with the device, select "Pair" to complete the pairing.
  • Page 22: Cleaning And Maintenance

    Cleaning and Maintenance Clean PU leather and plastic parts Wipe the skin with a soft dry cloth...
  • Page 23: Troubleshooting

    Troubleshooting The backrest reaches a certain position, pressing the corresponding adjustment button Issue no longer changes it, and it emits a continuous "beep, beep" sound. Due to the product's structural design and ergonomic requirements, there are restrictive protection measures for posture adjustment. A reminder sound will be emitted when Solution reaching the limit.
  • Page 24: Product Specifications

    Product Specifications Product name CirC3 Model name MR380 Power supply(50/60Hz) AC110-240V Rated time 20 min Power consumption(50/60Hz) 100W Safety structure Class Maximum user weight 220lb Country of origin Made in China NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 25 MEMO...
  • Page 26 CONSIGNES DE SÉCURITÉ IMPORTANTES DANGER AVERTISSEMENT •personnes ayant reçu un avis du •personnes •personnes...
  • Page 27 •Sous le fauteuil lui-même •Le dégagement du •Sous le repose-pieds, le dos du repose-pieds •Le dégagement •Derrière le dossier •...
  • Page 28 CONSIGNES DE SÉCURITÉ IMPORTANTES...
  • Page 30 CONSIGNES DE SÉCURITÉ IMPORTANTES...
  • Page 32 CONSIGNES DE SÉCURITÉ IMPORTANTES Une connexion incorrecte du conducteur de mise à la terre de l'équipement peut entraîner un risque de choc électrique. Consultez Si la mise à la terre n'est pas installée, cela peut de court-circuit.
  • Page 33 Installer la chaise de massage ATTENTION ATTENTION...
  • Page 34 Installer la chaise de massage Méthode de déplacement mobile ATTENTION 45°...
  • Page 35 ATTENTION...
  • Page 36 Avant de commencer le massage, dans la région du mollet, du pied et d'autres la tête ne doivent être insérés dans la zone entre le mécanisme du mollet et le corps, ainsi que dans la zone entre l'accoudoir et la Évitez que les mains, les pieds ou la tête ne mobiles du mollet et à...
  • Page 37 ATTENTION...
  • Page 38 ATTENTION AVERTISSEMENT...
  • Page 39 Structure du produit Lumière ambiante Appui-tête Couvercle du haut-parleur Touches rapides de l'accoudoir Emplacement pour téléphone portable Airbags latéraux du siège Accoudoir Structure de massage des jambes Panneau latéral Coussin Peut être placé sur le dos ou sur le siège.
  • Page 40 Structure du produit...
  • Page 41 Structure du produit...
  • Page 42 Structure du produit Bouton Nom du bouton Appuyez brièvement pour allumer ou éteindre l'appareil. Maintenez enfoncé pour entrer en mode d'inclinaison. Bouton de pression 4 niveaux d'intensité. d'air Bouton de pause contrôler la montée ou la descente du dossier. Bouton de rouleau...
  • Page 43 II. Démarrer le massage Bouton ment la montée. Montée ment la descente. Allonger Bouton Nom du programme Bleu Profond Vert Rythme corporel complet tout le corps et libérer le stress. Mouvements principalement pétrissants pour un Violet Apaisement complet du corps massage apaisant global.
  • Page 44 Massage manuel : Bouton Pétrissage Bleu Profond Vert Pétrissage à vitesse variable Violet Tapotement Tapotement à vitesse variable Orange Technique Bleu Pétrissage + Tapotement Pétrissage à vitesse variable + Tapotement à vitesse variable Jaune Pétrissage circulaire Pourpre Pétrissage Shiatsu circulaire Plage de massage Massage par pression d'air :...
  • Page 47 Dépannage Problème Problème Problème Problème Problème Problème...
  • Page 48 Nom du produit CirC3 Modèle MR380 Tension nominale AC 110-240V Temps nominal 20 min Puissance nominale 100W Structure de sécurité Class 100kg Pays d'origine Fabriqué en Chine...
  • Page 49 MEMO...
  • Page 50 MEMO...
  • Page 52 US20240221(1)
