  • Page 2: Product Specifications

    1. PRODUCT SPECIFICATIONS Model BCTT24M Engine model Loncin 1P75F Engine displacement 224 cm Rated power: 4.2 kW Max. engine speed: 3000min Fuel Unleaded gasoline, minimum 85 octane Engine oil SAE 10W-30, API SE of SF , for general use Oil capacity 0.51 Liters (0.132 US Gal, 0.110 Imp Gal) Spark plug F7RTTC or equivalent...

  • Page 3: Table Of Contents

    2. TABLE OF CONTENTS 1. PRODUCT SPECIFICATIONS………………………….……….2 2. TABLE OF CONTENTS…………………………………...…...….3 3. GENERAL WARNINGS……………………………………………4 4. GENERAL SAFETY REGULATIONS…………………...……..5 5. SYMBOLS………………………………………………...………..15 6. SET UP………………………………………………………………19 7. CONTROLS AND OPERATIONS…………………….….……29 8. MAINTENANCE…………………………………….……..……..47 9. EXPLODED VIEWS AND PARTS…………………….………56 10. WARRANTY……………………………………………..…….…..73 11. ENGINE MANUAL…………………………………..……………77...

  • Page 4: General Warnings

    3. GENERAL WARNINGS FOLLOW THESE INSTRUCTIONS CAREFULLY! Before use, read and understand the installation and operation instructions in this manual to become familiar with how this riding mower works. Failure to follow all instructions listed below may result in electric shock, fire, and/ or serious injury. 1.

  • Page 5: General Safety Regulations

    Positions on the machine, such as “front”, “back”, “left” or “right” hand side, refer to the direction of forward travel. For all operations regarding the use and maintenance of the engine not described in this manual, refer to the relevant manuals which form an integral part of all the documentation supplied with the machine.
  • Page 6 7. All drivers should seek and obtain professional and practical instruction. Such instruction should emphasize: ▪ The need for care and concentration when working with ride-on machines. ▪ You cannot use the brake to regain control of a ride-on machine sliding down a slope.
  • Page 7 4. Children, or other people who are not familiar with the instructions for use, are not allowed to use the equipment. 5. Comply with local regulations on the minimum age of people operating the equipment. 6. Do not allow children and young people to play on the machine. 7.
  • Page 8 Anyone using the riding lawn mower should first be acquainted with the instructions in this manual and completely familiarize themselves with the controls to ensure correct and safe machine use. 1. Never allow children under sixteen and people not fully acquainted with these instructions to use the lawn mower.
  • Page 9 2. The fact that a machine sliding down a gradient cannot be controlled using the brakes. The main causes of losing control of the machine are: ▪ Lack of wheel grip. ▪ Too much speed. ▪ Inadequate breaking. ▪ Machine not suitable for job to be done. ▪...
  • Page 10 Explosion! 1. Supply petrol before starting the engine. Do not remove the tank cap and do not supply petrol while the engine is running or hot. 2. Should the petrol run over, do not attempt to start the engine, but move the machine well away from the spot where you spilled the petrol.
  • Page 11 1. Travel in the manufacturer recommended direction on slopes. Use caution while operating near drop-offs. 2. Do not operate the machine under any condition where traction, steering, or stability is in question. Tires could slide even if the wheels are stopped. 3.
  • Page 12 Before leaving the driving seat: 1. Place the gear shift in neutral “N” and engage the parking brake. 2. Disengage the blade and lower the blade deck. 3. Stop the engine and remove the key. Before carrying out any inspection, cleaning, and servicing operations on the machine or before unblocking the grass unloading pipe, stop the engine, take out the ignition key and follow the instructions in the operator’s manual.
  • Page 13 GENERAL MAINTENANCE 1. Make sure all the nuts and screws are tight, so the lawn mower is in good operating condition and safe to use. 2. Wait for the engine to completely cool down before cleaning, adjusting, or repairing. Risk of burns! 3.
  • Page 14 MACHINE SAFETY Your lawn mower has been designed in accordance with specific safety standards. Safety systems operate as follows: Prevent engine start unless all machine’s safety conditions are in place. Conditions to be compiled with 1. Start switch end position. 2.

  • Page 15: Symbols

    5. SYMBOLS Your machine must be used with care. This is why labels with illustrations have been placed on the machine, to remind you of the main precautions to take during use. These labels are to be considered an integral part of the machine. Should a label come off or become illegible, contact your dealer to replace it.
  • Page 17 LABEL POSITION IDENTIFICATION OF THE MAIN COMPONENTS BLADE DECK – the casing protecting and enclosing the rotating cutter blade. 2) ROTATING BLADE – the blade that mows the grass and expels the cut grass into the grass bag. 3) GRASS UNLOADING PIPE – the pipe connecting the blade deck to the gras bag.
  • Page 18 4) GRASS BAG – besides collecting the cut grass, this is a safety element that prevents the launching of grass and collected materials. 5) Engine – drives the blade and wheels (see engine manufacturer’s manual) 6) BATTERY – (for model XCH62AE only) provides the power to start the internal combustion engine.

  • Page 19: Set Up

    6. SET UP UNPACKING AND ASSEMBLY OPENING THE PACKAGING: The machine is shipped partially dismantled and packaged in a metal crate to protect it during transport. The packaged machine will appear as in Fig 1. Wear heavy gloves. 1. Remove all shrink wrap and cut the two plastic straps that surround the package. 2.
  • Page 20 To prevent damaging the blade deck and blade, move the cutting deck to its maximum height before driving the riding off the wooden base platform. Be careful when performing this delicate unpacking operation.
  • Page 21 MACHINE PARTS The component parts of the machine to be assembled appear as in Fig 3. When unpacking the machine, take care to gather all individual parts and fittings, and do not damage the cutting deck when taking the machine off the pallet. 1.
  • Page 22 MACHINE ASSEMBLY FITTING THE STEERING WHEEL Position the machine flat and align the front wheels forward. 1. Fit the steering wheel column extension (Fig 5 Part 1) on the shaft (Part 3) and secure it with the screw (Part 2) and nut provided. Tighten well.
  • Page 23 FITTING THE SEAT 1. Fit the seat (Fig 12 Part 1) on the deck with the screws (Fig 12 Part 2). 2. Before tightening the four screws (Fig 13 Part 1) adjust the forward/backward position of the seat to best suit the driver. RIDING MOWER WEIGHT CAPACITY: The total weight capacity (operator and load) must not exceed 113 kg.
  • Page 24 FITTING THE BAG-HOOK SPRING 1. Loosen the screws (Fig 14 Part 1) and remove the rear cover by pressing from inside. 2. Cut the plastic straps (Fig 15 Part 1) to free the hook and spring. 3. Secure the two spring hooks (Fig 16 Part 1) in the two holes indicated by the arrows (Fig 16).
  • Page 25 FITTING THE GRASS COLLECTION BAG The bag frame (Fig 18 Part 1) is preassembled and the screws and nuts for complete fitting are secure at the points indicated by the arrows in Fig 18. 1. Loosen the screws and nuts so as to be able to open and fasten the frame (Fig 19).
  • Page 26 5. Fasten the handle (Fig 23 Part 1) to the bag frame using the screws provided (Fig 23 Part 2) 6. Fit the bag overturning lever in the housing provided as shown in Fig 24, after removing the screw and locknut (Fig 25 Part 1)> 7.
  • Page 27 CONNECTING THE BATTERY Sulfuric acid is poisonous. The electrolytic fluid is a solution of sulfuric acid. Sulfuric acid is corrosive. Sulfuric acid can cause blindness or severe burns. Never throw the battery away into the environment. Follow local authorities’ deposals methods when changing batteries. Position the battery with the polarities as indicated.
  • Page 28 1. Position the machine flat and align the front wheels forward. 2. Loosen the screw (Fig 28 Part 1) which secures the front casing of the engine compartment and move this away as shown in fig 29. 3. Fit the battery (Fig 29 Part 1) in its housing. Position the battery with the polarities as indicated in Fig 29.

  • Page 29: Controls And Operations

    TIRE PRESSURE Correct tire pressure ensures machine stability and the correct alignment of the blade with the ground. Periodically check the pressure of the tires and regulate according to the pressures shown on the technical data table. To inflate the tires, use an inflation gun featuring pressure gauge (Fig 30).
  • Page 30 Filling up must be done with the engine switch off in an open and well- ventilated environment. ▪ Always remember that petrol fumes are highly flammable. ▪ DO NOT USE OPEN FLAMES NEAR THE MOUTH OF THE TANK TO CHECK THE LEVEL, AND DO NOT SMOKE WHEN FILLING UP.
  • Page 31 1. Lift the seat and the door of the engine compartment (Fig 31). 2. Unscrew the oil cap. 3. Use a funnel to fill up (Fig 33). 4. The oil level must be between the MIN and MAX notches of the dipstick (see Fig 33).
  • Page 32 ▪ CLUTCH: The same brake pedal in the top part of its stroke works as a clutch pedal for machine movement. 1. With the pedal released, the clutch is completely engaged and transmits movement to the rear wheels. Speed depends on which gear has been engaged. MOVEMENT ENGAGEMENT AND SPEED CHANGE LEVER (Part 18) Selects machine forward reverse movement.
  • Page 33 BLADE DECK UP DOWN LEVER (Part 16) Lifts or lowers the blade deck and thereby adjusts the grass cutting height. There are four possible height adjustments. Press the handle on the lever and accompany the lever to the required position. When the button is released, the lever remains in the selective selected position.
  • Page 34 5. Do not leave the machine on high grass with the engine running to avoid the risk of starting a fire. 6. Do not use the machine without the side deflector in place. Do not use the machine on lawns with gradients of more than 15° (27%). Do not use the machine on lawns with side gradients above 10°...
  • Page 35 Tire Pressures: FRONT: 1.4 Bar / 20.3 PSI (11 x 4.00-5) REAR: 1.4 Bar / 20.3 PSI (13 x 5.00-6) CHECKING MACHINE SAFETY AND EFFICIENCY 1. Check that the safety devices function as described. 2. Check that the brake is in perfect working order. 3.
  • Page 37 To start the engine with either POWER START or MANUAL START, follow following six steps first: 1. Operate the parking brake. ▪ Press down the brake / clutch pedal (Fig 37 Part 1). ▪ Move the parking brake lever up (Fig 37 Part 2). ▪...
  • Page 38 MANUAL START: 6. Turn the ignition key (Fig 40 Part 1) to “I” position. 7. Grip the engine start cable handle (Fig 41). Give the cable an even, strong, and quick pull. Repeat the operation until the engine starts. ENGINE SWITCH OFF After using the machine: 1.
  • Page 39 TRANSPORTING WITHOUT MOWING This machine has not been approved for use on public roads. It must be used (as indicated by the highway code) in private areas closed to traffic. When transporting the machine: 1. Start the engine. 2. Sit in the driver's seat. 3.
  • Page 40 3. Raise the release lever (Fig 42 Part 1) on the drive and speed change engagement lever (Fig 42 Part 2). 4. Shift the drive and speed change engagement lever to neutral “N” to Reverse “R” (Fig 42 Part 3). 5.
  • Page 41 3. Disengage the blades and raise the cutting deck as high as possible whenever you need to get past an obstacle. This machine has not been approved for mowing when driving in reverse. EMPTYING THE GRASS BAG If the cut grass remains on the ground, this means the grass bag is full: 1.
  • Page 42 4. Switch off the engine and unplug the spark plug cap. Remove the key. 5. Release the bag. 6. Remove the accumulated grass from the rear part of the bag. END OF MOWING When you have finished mowing: 1. Operate the parking brake. 2.
  • Page 43 GRASS BAG The grass bag can be cleaned by means of a strong jet of water. BLADE DECK Washing the inside of the blade deck and of the grass unloading pipe can be done as follows: 1. Position the machine on an outside floor.
  • Page 44 The battery must be kept in a cool and dry place. Before a long storage period (more than 1 month), always charge the battery, and then recharge before using again. The next time the machine is used, check that there are no fuel leaks from the tubes, fuel stopcock or carburetor.
  • Page 45 Start moving forwards very carefully on sloping ground to prevent the risk of tipping over. Reduce the forward speed before going on a slope, particularly downhill. Never use reverse R to reduce speed going downhill. This could cause you to lose control of the vehicle, especially on slippery ground. Never ride the machine on slopes in neutral gear or with the clutch out! Always engage in low gear before leaving the machine stopped and unattended.
  • Page 46 4. Adjust gauge up or down until the left corner touches the slope (see Figure 1 and Figure 2). If there is a gap below the gauge, the slope is too steep for safe operation (see Figure 2 above) Slopes are a major factor related to tip-over and accidents which can result injury or death.

  • Page 47: Maintenance

    8. When you mow large areas, start by turning to the right so that the cut grass will discharge away from shrubs, fences, driveways, etc. After one or two rounds, mow in the opposite direction making left turns until finished. 9.
  • Page 48 The blades are sharp: Risk of serious injury to persons before cleaning, inspecting, and repairing cutting parts, stop the engine and take out the ignition key. Now disconnect the spark plug wire and keep the cap away from the plug to prevent accidental starting (Fig 51). Hot surfaces: Danger of burns.
  • Page 49 Operation Hours Completed (Date or Time) 1. MACHINE (Continued) 1.8 Check transmission Each 25 hours belt 1.9 Check blade belt Each 25 hours 1.10 Bolt and screw Each 25 check hours 1.11 General Lubrication Each 25 hours 1.12 Blade replacement Each hours 1.13 Maintenance review...
  • Page 50 DISMANTLING, SHARPENING, AND BALANCING THE BLADE Check that the blade is sharpened properly and firmly fixed to the bracket. ▪ A badly sharpened blade pulls at the grass and causes the lawn to turn yellow. ▪ A loose blade causes unusual vibration and can be dangerous. All operations on the blade (dismantling, sharpening, balancing, remounting, and / or replacing) require a certain familiarity and special tools for safety reasons.
  • Page 51 REPLACING THE BELT The belt replacement must be carried out at a licensed service center. Replace the belts as soon as they show obvious signs of wear! ALWAYS USE GENUINE REPLACEMENT BELTS! TROUBLESHOOTING Injury hazard if engine is started inadvertently. Protect yourself against injury.
  • Page 52 Malfunction Cause Remedy No ignition spark. Clean spark plug, replace with a new one if necessary, check ignition cable, check ignition system (customer service by a specialized after-sales center). Too much fuel in engine Unscrew spark plug and dry combustion chamber due off.
  • Page 53 Malfunction Cause Remedy Travel drive, brake, Only have check by a clutch and mower specialized after-sales mechanism. center. Starter does not work Starter battery flat or Charge starter battery. weakly charged. Safety switch on operator's Sit on operator's seat seat does not function. correctly;...
  • Page 54 Malfunction Cause Remedy Engine is losing power. Carburetor stetting Have the setting checked (Continued) incorrect. (customer service by a specialized after-sales center). Blade severely worn down. Renew or regrind blade. Reground blade must be balanced. (customer service by a specialized after-sales center).
  • Page 55 If problems persist after having performed the above operations, contact your Dealer or an authorized Service center. MACHINE DIMENSIONS...

  • Page 56: Exploded Views And Parts

    9. EXPLODED VIEWS AND PARTS...

  • Page 73: Warranty

    10. WARRANTY This product is distributed by: MECANAIR 1380 Newton Street, Suite 109, Boucherville, (Québec) J4B 5H2 Phone: 1-833-818-4111 https://www.mecanair.net/en/marque.php WARRANTY Beginning at the time of retail purchase and for the duration of the warranty period MECANAIR warrants that Equipment manufactured by it is warranted to be free from defects in material and workmanship.
  • Page 74 THIS WARRANTY DOES NOT COVER: Any repairs as a result of any parts not supplied by MECANAIR, and this part is responsible for the failure or malfunction. ▪ Any Machine modified, altered, disassembled, or remodeled, ▪ Any repairs required as a result of a failure to install, maintain, store, transport, or operate the Equipment in accordance with standard practices set out in the operator’s manual.
  • Page 75 OTHER STATES, U.S. TERRITORIES, AND CANADA: In other areas of the United States and in Canada, your engine must be designed, built, and equipped to meet the U.S. EPA and Environment Canada emission standards for spark-ignited engines at or below 19 kilowatts. ALL OF THE UNITED STATES AND CANADA: MECANAIR must warrant the emission control system on your power equipment engine for the period of time listed below, provided there has been no...
  • Page 76 Consumable parts are covered up to a maximum of 30 days. SYSTEMS COVERED PARTS IN WARRANTY DESCRIPTION Fuel Metering Carburetor assembly (includes starting enrichment system), Engine temperature sensor, Engine control module, Fuel regulator, Intake manifold Evaporative Fuel Tank, Fuel Cap, Fuel Hoses, Vapor Hoses, Carbon Canister, Canister Mounting Brackets, Fuel Strainer, Fuel cock, Fuel Pump, Fuel Hose Joint, Canister Purge Hose Joint...
  • Page 78 MODEL 1P75F GASOLINE ENGINE OWNER’S MANUAL BEFORE OPERATING ENGINE • Read entire Operating ＆ Maintenance Instructions AND the instructions for the equipment this engine powers. • Failure to follow instructions could result in serious injury or death. THE OPERATING ＆ MAINTENANCE INSTRUCTIONS CONTAIN SAFETY INFORMATION TO •...
  • Page 79 The engine exhaust from this product contains chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm. We do not necessarily know what equipment this engine will power. For that reason, you should carefully read and understand the operating instructions for the equipment on which your engine is placed.

  • Page 80: Engine Safety

    1. ENGINE SAFETY IMPORTANT SAFETY INFORMATION Most accidents with engines can be prevented if you follow all instructions in this manual and on the engine. Some of the most common hazards are discussed below, along with the best way to protect yourself and others. Owner Responsibilities •...
  • Page 81 WHEN OPERATING EQUIPMENT • Do not tip engine or equipment at an angle which causes gasoline to spill. • Do not choke the carburetor to stop the engine. WHEN TRANSPORTING EQUIPMENT • Transport with fuel tank EMPTY or with fuel shut-off valve OFF WHEN STORING GASOLINE OR EQUIPMENT WITH FUEL IN TANK •...
  • Page 82 Rotating parts can contact or entangle hands, feet, hair, clothing, or accessories. Traumatic amputation or severe laceration can result. • Operate equipment with guards in place. • Keep hands and feet away from rotating parts. • Tie up long hair and remove jewelry. •...

  • Page 83: Components

    2. COMPONENTS 2.1 COMPONENTS OF ENGINE 3.1 ENGINE OIL ENGINE OIL RECOMMENDATIONS Oil is a major factor affecting performance and service life. Use 4-stroke automotive detergent oil. SAE 10W-30 is recommended for general use. Other viscosities shown in the chart may be used when the average temperature in your area is within the recommended range.
  • Page 84 AMBIENT TEMPERATURE The SAE oil viscosity and service classification are in the API label on the oil container. We recommend that you use API SERVICE Category SE or SF oil. This engine is shipped from the factory without oil. Check the oil level before starting the engine.

  • Page 85: Fuel

    3.2 FUEL Fuel Recommendations Use clean, fresh, regular unleaded gasoline with a minimum of 85 octane. • These engines are certified to operate on unleaded gasoline. Unleaded gasoline produces fewer engine and spark plug deposits and extends exhaust system life. •...
  • Page 86 3.3.2 Start Engine • Grasp rope handle. Pull slowly until resistance is felt, then pull rapidly to start the engine and avoid kickback. • If the choke was used to start the engine, move the throttle to the fast (or high) position as soon as the engine warms up enough to run smoothly without use of the choke.

  • Page 87: Stopping Engine

    3.4 STOPPING ENGINE • Engine with Throttle Control: Move the throttle control to the stop position. • Turn the fuel valve to the OFF position if you do not intend to restart the engine soon. 4. MAINTENANCE 4.1 THE IMPORTANCE OF MAINTENANCE Good maintenance is essential for safe, economical, and trouble-free operation.

  • Page 88: Maintenance Schedule

    Injury from moving parts. Do not run the engine unless instructed to do • Read the instructions before you begin, and make sure you have the tools and skills required. • To reduce the possibility of fire or explosion, be careful when working around gasoline.

  • Page 89: Change Engine Oil

    Used oil is a hazardous waste product. Dispose of used oil properly. Do not discard with household waste. We suggest you take used oil in a sealed container to your local recycling center or service station for reclamation. 4.4 CHANGE ENGINE OIL Drain the used oil while the engine is warm.

  • Page 90: Refueling

    4.5 REFUELING With the engine stopped, remove the fuel tank cap and check the fuel level. Refill the tank if the fuel level is low. Refuel in a well-ventilated area before starting the engine. If the engine has been running, allow it to cool. Refuel carefully to avoid spilling fuel. Do not fill above the fuel strainer shoulder.

  • Page 91: Spark Plug Service

    4.6.2 Cleaning a) Tap the filter several times on a hard surface to remove dirt or blow compressed air (not exceeding 30 psi [ 207kPa, 2.1kg/cm²]) through the filter from the clean side that faces the engine. Never try to brush off dirt. Brushing will force dirt into the fibers.
  • Page 92 4.7.1 Disconnect the spark plug cap and remove any dirt from around the spark plug area. 4.7.2 Remove the spark plug with a spark plug wrench. 4.7.3 Inspect the spark plug. Replace it if the electrodes are worn, or if the insulator is cracked or chipped.

  • Page 93: Storage/ Transporting

    5. STORAGE/ TRANSPORTING 5.1 STORING YOUR ENGINE Storage Preparation Proper storage preparation is essential for keeping your engine trouble free and looking good. The following steps will help to keep rust and corrosion from impairing your engine’s function and appearance and will make the engine easier to start after storage. 5.1.1 Cleaning If the engine has been running, allow it to cool for at least half an hour before cleaning.
  • Page 94 The Distributor’s Limited Warranty does not cover fuel system damage or engine performance problems resulting from neglected storage preparation. You can extend fuel storage life by adding a fuel stabilizer that is formulated for that purpose, or you can avoid fuel deterioration problems by draining the fuel tank and carburetor.

  • Page 95: Storage Precautions

    5.2 STORAGE PRECAUTIONS a) Change the engine oil. b) Remove the spark plugs. c) Pour a tablespoon (5-10 cc) of clean engine oil into the cylinder. d) Pull the starter rope several times to distribute the oil in the cylinder. e) Reinstall the spark plugs.

  • Page 96: Removal From Storage

    5.3 REMOVAL FROM STORAGE Check your engine as described in the chapter OPERATION. If the fuel was drained during storage preparation, fill the tank with fresh gasoline. If you keep a container of gasoline for refueling, be sure that it contains only fresh gasoline.

  • Page 97: Troubleshooting

    6. TROUBLESHOOTING Engine Will Not Start Possible Cause Correction Move lever to CLOSE unless Choke OPEN. engine is warm. 1. Check control positions Engine switch OFF. Turn engine switch to ON. Out of fuel. Refuel Bad fuel; engine stored without treating or draining Drain fuel tank and 2.

  • Page 98: Technical & Consumer Information

    7. TECHNICAL & CONSUMER INFORMATION Serial Number Location Record the engine serial number in the space below. You will need this serial number when ordering parts, and when making technical or warranty inquiries. Engine serial number: _________________________________ Maintenance Follow the maintenance schedule. Remember that this schedule is based on the assumption that your machine will be used for its designed purpose.

  • Page 99: Specifications

    Quick Reference Information Type SAE 10W-30,API SE or SF, for general use Engine Oil Capacity 0.5L (0.132 US Gal, 0.110 Imp Gal) Type F7RTC or other equivalents. Spark Plug 0.028－0.031 in (0.70－0.80 mm) Carburetor Idle speed 1800±150 rpm Each use Check engine oil.
