Thank you for buying the X-style 14 mobile phone. This
manual includes the description of the main functions of
the phone.
X-style 14 allows you to use 2 GSM SIM cards in dual
standby mode. This means that in standby mode both cards
are online, whereas during the call 1 card works in active
mode and 1 other card is unavailable.
The content of the manual is correct. The description of
some functions may vary due to changes in software or
provider services. The company keeps the right to make
changes to the technical specifications without previous
warning.
Key remarks on safety measures
This phone is designed for mobile use, for calling and
receiving calls, sending SMS messages, surfing the Internet
(if configured) etc.
Read the section below very carefully and strictly follow the
instructions.
The phone doesn't contain any materials harmful for
health.
● Do not use the phone out in the open during
thunderstorms.
● Do not subject the battery to high temperatures,
explosive and flammable liquids.
● Turn off the phone in situations when using it can cause
danger or other difficulties.

Advertisement

loading
Need help?

Need help?

Do you have a question about the X-style 14 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sigma mobile X-style 14

Summary of Contents for Sigma mobile X-style 14

  • Page 1 X-style 14 allows you to use 2 GSM SIM cards in dual standby mode. This means that in standby mode both cards are online, whereas during the call 1 card works in active mode and 1 other card is unavailable.
  • Page 2 ● Do not put the phone in heating devices such as microwave ovens, stoves, or heaters. ● Do not try to open the mobile phone's frame. If the phone or any of the accessories do not work properly, please contact the closest authorized service center. ●...

  • Page 3: Specifications

    legislation leads legal accountability. More information on the safe utilization of lithium-ion batteries may be obtained at the closest specialized service center. Specifications Phone, frequency GSM 900: 880-915 MHz (Tx), bands 925-960 (Rx) GSM 1800: 1710-1785 MHz (Tx), 1805-1880 (Rx) Number of 2 (miniSIM+nanoSIM).
  • Page 4 Battery Li-Ion, 600 mAh Maximum radiation Bluetooth: 4.32 dBm (2.7 mW). power in the GSM 900: 33 dBm (2 W) frequency bands GSM 1800: 29.2 dBm (832 mW). the radio equipment works Package includes ● Mobile phone x1 ● Battery x1 ●...
  • Page 5 Phone’s appearance Receiver Central key Left soft key (LSK)
  • Page 6 Calling\receiving a call Navigation keys Right soft key (RSK) Reject/cancel/press and hold to turn the phone on or off MicroUSB port Headphone jack Flashlight Flashlight on/off button Keys specification Buttons Functions 0-9 keys Press: to dial a number 1 through 9. Press and hold the keys 2-9: to speed dial the previously installed numbers.
  • Page 7 # key Press to enter the symbol #. Press and hold: to switch user profiles from General to Silent. Left soft key In standby mode: press to open the (LSK) Menu. Choosing between Options in the settings. When the keyboard is locked, press LSK and PSK alternately to unlock.
  • Page 8 Inserting the SIM cards and memory card Open the back cover and take out the battery. Insert the SIM cards in the proper device slots. Then insert the microSD card, if needed. Reinsert the battery, making sure that the battery contacts fit the phone contacts.
  • Page 9 The meaning of symbols on the screen Symbol Meaning Connection signal Battery charge indicator New message Missed call Silent profile activated General profile activated Meeting profile activated Alarm clocks are on...
  • Page 10 Bluetooth mode is on Power the device on\off To turn on the device, press and hold the End Call button until the device screen is activated. To turn off — press and hold the End Call button until the device turns off. The device is locked automatically (if automatic locking is enabled) by pressing the End Call button.
  • Page 11 Using the phone’s Menu To access the Menu, press the Left soft key (LSK) or the Central key. The menu includes the following items: Names (Contacts): contains contacts stored in the phone and on SIM cards. Message: send messages and read incoming messages. Call logs: a register of incoming, outgoing and missed calls.
  • Page 12 Names→Find contacts. To switch the method/language of the search press the # key. To view the contact, select it with the cursor and press the Central key. To make a call, press the Call button. Additional options may be accessed with the Left soft key. New contact: add a new contact.
  • Page 13 Message This menu contains everything you need to send, store, view and delete SMS messages. Write message: select to write and send (or save) a new message. Inbox: folder with received messages. Outbox: folder with sent messages. Drafts: unfinished messages. Sentbox: messages that have been sent.

  • Page 14: Audio Player

    Settings Phone settings: contains settings for date and time, interface language, quick access keys, scheduled power on/off settings. Also, this menu allows you to reset to factory settings. Call settings: the menu allows you to configure the number of active SIM cards, forwarding options, call barring, auto-dialing, auto-recording of calls and others.
  • Page 15 Press the Central key to play/pause. To move to the next/previous file press Right/Left. To create a playlist, copy the music files to the memory card in the “My music” folder. change settings, List→Options→Settings. Voice recorder Note: To use the voice recorder insert a memory card. To start recording sound, press the Central key.

  • Page 16: Troubleshooting

    If the problem is not solved, contact the Sigma mobile service center. ● Check whether the battery is charged and whether the problem persists after reloading the device. ● Try to restore factory settings via Settings → Phone →...
  • Page 17 whether the card is installed in the slot correctly, and reloading the phone. ● The phone does not turn on: check battery charge, connect the charging device once more, and wait at least 10 minutes. Press and hold the Power button for at least 5 seconds.
  • Page 18 Phone password: request occurs during activation. This is the general lock password. By default, the password is 1122. PIN code: if the PIN verification function is enabled, you must enter the code provided with the corresponding SIM card. PUK code, PIN2 code: also provided with SIM card. Privacy code: request occurs if privacy is enabled in security settings, when activating the locking functions.
