MAINS HEAT ALARM
FHN450 Range
(Fitted with FHN600RF)
1. PRODUCT DESCRIPTION
The Firehawk Hearing Impaired System (FHN800HIA) Control Unit comes
CO ALARM
CO10-RF
with a built-in high intensity Flashing Strobe, a plug-in power supply/
charger and a Vibrating Pillow Pad. It can be radio interlinked with other
RF-Link series devices including Firehawk Smoke Alarms (FHB10-RF), Heat
1.1 Plug alarm into pattress and switch on radio base, the pattress led
will flash green twice per second. If not, please complete step 6.0
Alarms (FHH10-RF), Carbon Monoxide Alarms (CO10-RF), Mains FHN600RF
to reset the device.
equipped devices and other Control Units (FHN800HIA).
PLEASE NOTE:
Firehawk RF-Link smoke, heat and co alarms are not included in the
1.2 Secure the alarm wire into the retaining slot.
hearing impaired system and must be purchased separately.
2. FEATURES
IMPORTANT: the wire can interfere with the radios antenna if
• Can be radio interlinked with (one other) additional Firehawk RF-Link
not secured in the retaining slot.
Hearing Impaired Control Unit, Smoke Alarms, Heat Alarms or Carbon
Monoxide alarms for early warning of a developing fire or carbon
monoxide hazard via the vibrating pad and flashing strobe.
• Super safe radio technology to enable fast and easy Linking and
installation.
• Supports up to 14 Firehawk wireless (radio) interlinked alarms devices.
• Rechargeable backup battery with up to 72 hours of operation on a full
charge.
• High intensity Flashing Strobe.
• Supports two Vibrating Pillow Pads with 3 metres of cable.
• Test function to check all hardware and wireless (radio) connections
within a system at once.
• Low battery warning.
• Suitable for use in leisure accommodation vehicle.
3. ALARM ASSEMBLY
Prepare the Hearing Impaired System as follows:
1
Remove the Control Unit stand
(if fitted) by sliding the Control
1
Unit upwards from the stand.
Remove the screw of the access
2
panel and the Panel itself.
Pass the Power Supply and
3
Vibrating Pillow Pad wires
through the back of the stand and
3
Control Unit.
Connect the Vibrating Pillow
4
Pads. It is possible to use single,
double or no Vibrating Pillow Pad
(Strobe Light Only).
Wall Mount: If you prefer to mount
the Control Unit on the wall,
use the mounting plate (shown
below) and attach it to your chosen
position on the wall with suitable
fixing screws. Slide the Control
Unit down onto the plate to locate
it. Remove the cut-out in the
bottom of the access panel.
4. RADIO LINK (WIRELESS) PAIRING
Linking the Wireless (radio) Hearing Impaired System
The Firehawk Hearing Impaired System (FHN800HIA) can be radio
interlinked (wireless) by to one other Firehawk RF-Link Control unit
(FHN800HIA). Smoke Alarms (FHB10-RF), Heat Alarms (FHH10-RF) and
Carbon Monoxide Alarms (CO10-RF) and FHN600RF equipped devices
which are supplied separately.
Up to 14 devices may be interlinked to the system. Please refer to the
enclosed instructions for radio linking (wireless) alarms to the Firehawk
Hearing Impaired System (FHN800HIA).
3.4 Repeat step 3.2 & 3.3 for each alarm to be added to the system.
RF-LINK
MAINS SMOKE ALARM
MODULE
FHN250 Range
3.5 Once all alarms are linked, wait 20 seconds or press the test
(FHN600RF)
(Fitted with FHN600RF)
button on the first alarm to exit linking mode. If the test button
is pressed on the first alarm to exit linking mode, the alarm will
perform a test, step 4.1.
3. LINKED ALARMS READY FOR
INSTALLATION
4.1 Press the TEST BUTTON on any one alarm and wait for each
linked alarm to sound. (Due to signal timings each alarm may
HEARING IMPAIRED CONTROL UNIT
trigger at the same time making it difficult to detect a faulty
FH800HIA
alarm). Please perform a test from each alarm in the system to
ensure every alarm is successfully linked.
1. CONNECT
4.2 Install the alarms around your home then test again with the
alarms in position to ensure there are no radio range issues.
5. LINKING ADDITIONAL ALARMS
To add a new alarm to an existing system complete step 1 and 2 for
all new alarms.
5.1 Open any already linked alarm and press the white RF button on
the radio pattress to enter linking mode, the red and green led
will flash as in step 3.1.
5.2 Repeat step 3.2 for all new alarms.
5.3 Press the white button on the already linked alarm to complete
the process.
6. DEVICE RESET
6.1 To reset the pattress and restore factory settings, Open the alarm
device and hold down the white RF button until the light turns
RED. This will restore factory settings and unlink all devices, the
light will flash green twice per second as in step 1.1.
IMPORTANT: For comprehensive pairing instructions,
please read enlosed pairing leaflet (shown above), scan
this QR code on your phone or visit:
www.fireblitz.co.uk/support/
LINKING TEST
IMPORTANT: Before installing the paired alarms and Hearing
Impaired System (FHN800HIA) around your home it is important to
ensure the pairing process was successful.
To test the system, press the test button on the Control Unit (FHN800HIA),
this will test its hardware and transmit a radio (wireless) test signal to all
linked devices. Each linked device must sound within 30 seconds and all
linked FHN800HIA's will perform a self test! Next press the test button on a
Linked device, the Control Unit (FHN800HIA) will respond by performing a
hardware test and all other alarms will sound. If any device does not sound
or the Control Unit (FHN800HIA) does not perform a hardware test when
the test button on a linked device is pressed the device failed to link to the
system and needs to be added.
2
Place the Control Unit where the strobe can be seen and place the
1
Vibrating Pillow Pad in the most suitable position (see section: Using
the Hearing Impaired System below).
4
2
Once all of the alarms have been paired and tested (above), install the
alarms to your chosen locations using the section Choice and Location
of Alarms in their respective manuals, or see sections 8-10.
3
With alarms in position you must test the entire radio linked (wireless)
system again from each device (see section 4). Every interconnected
device must sound after pressing the test button on the Control Unit
(FHN800HIA) and it must react to a test from each connected alarm
device. If a device fails to sound it may be installed out of radio range
or something is interfering with its signal. Please see radio trouble
shooting guide at
www.fireblitz.co.uk/product/hearing-impaired-system/
GENERAL GUIDANCE
The entire Hearing Impaired System and it's Linked alarms should be
tested at least once per month. The location and type of equipment should
be carefully chosen to ensure it is suitable for the individual or family being
protected. Full guidance on this can be found in BS 5839-6 section 14.
VIBRATING PILLOW PAD
The Vibrating Pillow Pad is for use under the pillow or mattress, laid flat
and as close to the individual as possible. Please test the unit in position to
ensure it can be felt through pillow.
WARNING: DO NOT place the Vibrating Pillow Pad within 15cm of
any heart pacemaker.
STROBE LIGHTS AND EPILEPSY
Strobe lights can, in certain circumstances, trigger an epileptic seizure.
However, this Hearing Impaired System (FHN800HIA) has been designed
and built to the meet the requirements of BS5446- 3:2015 which requires
that the frequency of the flashing strobe should not be more than 2 hertz.
The Epilepsy Foundation say "Generally, flashing lights most likely to trigger
seizures, are between the frequency of 5 to 30 flashes per second (Hertz)"
For further guidance see their link at: https://www.epilepsy.com/what-is-
epilepsy/seizure-triggers/photosensitivity
Pairing Guide
SMOKE ALARM
HEAT ALARM
FHB10-RF
FHH10-RF
CO ALARM
HEARING IMPAIRED CONTROL UNIT
CO10-RF
FH800HIA
READ & RETAIN THESE PAIRING INSTRUCTIONS
5. INSTALLATION
6. USING THE HEARING
IMPAIRED SYSTEM
LED INDICATORS
Green Power LED will be on while the dc power supply is connected and
will flash every 30 seconds when the power supply is disconnected, and
the device is powered by the backup battery.
Yellow Fault LED will flash to indicate a system fault. Please see table
below for list of possible faults.
Red Fire Alarm LED will flash during a FIRE Alarm and when tested from a
Smoke or Heat alarm.
Red CO Alarm LED will flash if Carbon Monoxide has been detected and
when tested from the Carbon Monoxide Alarm.
A
*
Back-Up Battery Fault, The backup battery is flat and
needs time to recharge.
B
**
Radio Interlink Fault, a linked device has disconnected
from the control unit or the radio drop-out detection
system has been disabled as the unit has disconnected
from mains power.
C
***
Fault A & B
D
****
Vibrating Pad Fault, A vibrating pad has disconnected. It
may be un-plugged, or the cable is broken.
E
*****
Fault A & D are active
F
******
Fault B & D
G
The device has not yet been linked to any alarm devices.
ON no flash
H
-
Linked Device Fault - A long 1 second flash indicates a
linked device has a fault. Press the test button three times
rapidly, the faulty device will beep.
Device Reset
To reset the FHN800HIA device press and hold the link button until all lights
will flash sequentially, press the link button again to reset the device. This
will blink all lights and return the device to factory settings.
Turn Off the Control Unit
To turn the device off, remove the power supply and press the test button
6 times.
Hard of Hearing
System
7
YEAR
Warranty
PRODUCT
INFORMATION
FHN800HIA
RECHARGEABLE
MAINS
LED STROBE
VIBRATING
POWERED
LIGHT
BATTERY BACK UP
PILLOW PAD
READ AND RETAIN THIS USER MANUAL
MANUAL
Conforms to
BS5446-3: 2015
