Sealey 800CE Instructions

Thank you for purchasing a Sealey product. Manufactured to a high standard this product will, if used according to these instructions
and properly maintained, give you years of trouble free performance.
IMPORTANT! ENSURE YOU READ AND UNDERSTAND THESE INSTRUCTIONS FULLY BEFORE ATTEMPTING TO USE THE JACK. NOTE THE
SAFE OPERATIONAL REQUIREMENTS, DANGERS, WARNINGS & CAUTIONS. USE THE JACK CORRECTLY AND WITH CARE FOR THE
PURPOSE FOR WHICH IT IS INTENDED. F WARNING! FAILURE TO APPLY THESE INSTRUCTIONS MAY CAUSE DAMAGE OR SERIOUS
PERSONAL, OR FATAL, INJURY.
INSTRUCTIONS SAFE FOR FUTURE USE.
NOTE: The use of symbols in this document is to attract your attention to possible danger. The symbols and warnings themselves do not eliminate any danger, nor
are they substitutes for proper accident prevention measures.
1. SAFETY INSTRUCTIONS
F WARNING! Ensure all preliminary checks are carefully carried out before use of jack. Immediately repair or replace damaged parts
(use authorised service agent). Ensure use of genuine parts only. Non-authorised parts may be dangerous and will invalidate the warranty.
F WARNING! Use jack on level and solid ground, preferably concrete. Ensure the floor over which the jack will be transported is swept clean.
I DANGER! DO NOT use on tarmacadam, or any other soft surface as jack may sink or topple. Serious personal, or fatal, injury may result.
s
! Use jack in a suitable working area, keep area clean and tidy and free from unrelated materials. Ensure there is adequate lighting.
! Before use ensure the gearbox weight and size does not exceed the capacity of the jack.
! Ensure the vehicle is raised and stabilised at the correct height before attempting to move the jack under the vehicle.
! Keep all unauthorised persons away from the jack during lifting and lowering and when in transit.
! Maintain correct balance and footing. Ensure the floor is not slippery and wear non slip shoes.
! Remove ill fitting clothing. Remove ties, watches, rings and other loose jewellery and contain and/or tie back long hair.
F WARNING! Ensure load is placed level and centrally on jack saddle and is fixed in place before attempting to lift, lower, or transport.
! The lowering speed will vary according to the weight of the load and the release valve setting.
! Ensure the jack saddle is fully lowered and is clean, dry, and oil free before attempting to transport the jack.
! Fix load with restraint chains provided. Do not substitute an inferior form of restraint for these chains.
! Diligence is required in ensuring that you continually monitor the operation until completed.
! Should the jack emit any abnormal sounds during use STOP immediately and contact your local service agent.
I DANGER! IF JACK TIPS OR LEANS, STOP WHAT YOUR ARE DOING, MOVE QUICKLY TO A SAFE DISTANCE. DO NOT TRY TO HOLD
s
OR STEADY JACK. Serious personal, or fatal, injury may result.
F WARNING! DO NOT operate jack if any parts are damaged or missing .
% DO NOT exceed the rated capacity of the jack.
% DO NOT allow untrained persons to operate the jack.
% DO NOT place any part of your body within, or under, the jack during use.
% DO NOT raise or lower vehicle lifting platform whilst the transmission jack is being used.
% DO NOT transport the jack, with or without a load, with the saddle in the raised position.
% DO NOT get jack wet or use in damp or wet locations or areas where there is condensation.
% DO NOT operate the jack when you are tired, under the influence of alcohol, drugs or intoxicating medication.
% DO NOT lift or support vehicles with jack and do not use jack as a load sustaining device.
% DO NOT use jack for any purpose other than removal, transportation and installation of transmissions.
% DO NOT use jack without restraint chains and do not replace the chains with an inferior form of restraint.
% DO NOT make any modifications to the jack, and DO NOT adjust or tamper with the safety valve.
% DO NOT remove any labels from the jack. If labels are damaged or unclear replace them.
! Use a qualified person to lubricate and maintain the jack. DO NOT use brake fluid in the hydraulic unit. Use Sealey hydraulic jack oil only.
! Before storing in safe area, ensure all parts are clean, free of grease and oil, (especially saddle) and that saddle is in lowest position.
2. INTRODUCTION & SPECIFICATION
Your transmission jack has been manufactured to a high specification and is equipped with saddle pitch and tilt facilities and precision valves
which allow accurate adjustment and control when lowering the transmission from a vehicle.
2.1. SPECIFICATIONS:
Rated capacity . . . . . . . . . . . . . . . . . . . . . . 800kg
Saddle height (minimum) . . . . . . . . . . . . . .210mm
Saddle height (maximum) . . . . . . . . . . . . .755mm
Hydraulic lift . . . . . . . . . . . . . . . . . . . . . . .545mm
Saddle forward/backward pitch . . . . . . . . . . . .18
2.2. BEFORE FIRST USE
IMPORTANT:
2.2.1. Remove the transit screw plug from the top of the hydraulic cylinder and replace with the drilled breather/filler plug which is attached to it.
Retain original plug for any future transportation.
2.2.2. To eliminate any air that may have accumulated during transit, purge the hydraulic circuit as follows:
Open the release valve by turning release knob on hydraulic unit anti-clockwise.
Pump the jack handle up and down 15 to 20 times.
Turn the release knob clockwise to close the valve.
s s
FAILING TO FOLLOW INSTRUCTIONS WILL ALSO INVALIDATE YOUR WARRANTY. KEEP THESE
BEFORE THE FIRST USE OF JACK REMOVE TRANSIT PLUG AND PURGE AIR FROM THE HYDRAULIC CIRCUIT.
INSTRUCTIONS FOR:
FLOOR TRANSMISSION JACK
800CE
Model:
Saddle left/right tilt . . . . . . . . . . . . . . . . . . . . . .12
Saddle width . . . . . . . . . . . . . . . . . . .250-345mm
Saddle length . . . . . . . . . . . . . . . . . . . . . .352mm
Base length x height x width . . . .845x225x495mm
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60kg
O
O
800CE - (0016) - (1) -010499
