PXA
Amplifiers
PXA MONO AMPLIFIERS
PXA200.1 | PXA500.1
Owner's Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the PXA.1 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Kicker PXA.1 Series

  • Page 1 Amplifiers PXA MONO AMPLIFIERS PXA200.1 | PXA500.1 Owner’s Manual...
  • Page 2: Installation

    25Hz, 24dB/octave slope 25Hz, 24dB/octave slope Remote Bass Pro Tip: To get the best performance from your new KICKER Amplifi er and extend the warranty by 1 year, use genuine KICKER accessories and wiring. INSTALLATION Mounting: Choose a structurally sound location to mount your KICKER amplifi er. Make sure there are no items behind the area where the screws will be driven.
  • Page 3 KICKER KISL (optional) Model External Fuse PXA200.1 1 x 15 Ampere PXA500.1 1 x 45 Ampere to amplifi er from source unit high-level speaker outputs Cut the looped red power cable located on the PXA harness and install a 15A (PXA200.1) or 45A (PXA500.1) fuse.
  • Page 4: Operation

    (Best for Hi-Level input) Input Level: The RCA inputs on KICKER PXA amplifi ers are capable of receiving either Hi or Low-level signals from your source unit. When using a Hi-Level signal, simply set the Input Level switch on the amplifi er to HI.
  • Page 5: Troubleshooting

    There is a Power Protection LED on the side power panel of your Kicker PXA series amplifi er. Depending on the state of the amplifi er and the vehicle’s charging system, the LED will glow either Red or Blue. When the blue LED is lit this indicates the amplifi...
