- Page 1 Flyron Technology Co., Ltd. FN-W101 Triggerable MP3 Audio Player FN-W201 Triggerbale MP3 Audio Player/Wall Speaker User’s Manual Version: V1.1 www.flyrontech.com E-mail: info@flyrontech.com...
-
Page 2: Electrical Parameters
Flyron Technology Co., Ltd. FN-W101 Triggerable MP3 Audio Player 1. Features Equipped with a high quality MP3 player with great sound quality. Built-in 256MB memory by default. Replace sound files easily by connecting the device to computer with a USB data cable. - Page 3 Flyron Technology Co., Ltd. FN-W101 Triggerable MP3 Audio Player playback will be stopped/cancelled. Once the button is kept holding, when the playback of the audio file is finished, it will start to play it repeatedly(loop playback). Pulse non-interruptible one-on-one playback: In this mode, a single negative pulse will start playback. It's ...
-
Page 4: Micro Usb Port
Flyron Technology Co., Ltd. FN-W101 Triggerable MP3 Audio Player 3.2. Audio Files Loading See the image below. There is a micro USB socket at the back of the device. Users can connect it to computer through an Android phone purposed USB cable to load audio files and configuration file. - Page 5 Flyron Technology Co., Ltd. FN-W101 Triggerable MP3 Audio Player 2). Rename the audio files from 001.mp3/wav to “004.mp3/wav”, and make sure they are ranked from “001.mp3/wav” to “004.mp3/wav” in order. 3). Connect the equipment with computer through the USB cable, and you will see a removable disk.
- Page 6 Flyron Technology Co., Ltd. FN-W101 Triggerable MP3 Audio Player 。 。 。 。 。 。 。 。 9-24V DC input 3.3.2. Connection for Working with PIR Sensor 9-24V DC input Output This wiring method is for those customers’ reference, who need the player to be triggered by a PIR sensor. Besides, to achieve this function the trigger mode in the configuration file must be “2”.
- Page 7 Flyron Technology Co., Ltd. FN-W101 Triggerable MP3 Audio Player 9-24V DC input This wiring method is for those customers’ reference, who need the player to play the sound messages automatically in a loop once it’s powered up. Besides, to achieve this function the trigger mode in the configuration file must be “3”.
