Auto Refractometer
User Manual
February 2018
D051-E plus

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ACOMOREF 2 and is the answer not in the manual?

Questions and answers

Related Manuals for Righton ACOMOREF 2

Summary of Contents for Righton ACOMOREF 2

  • Page 1 Auto Refractometer User Manual February 2018 D051-E plus...
  • Page 2 Caution: Please read this User Manual before operating the equipment. This Manual is prepared for the users of the Auto Refractometer ACOMOREF 2. The Manual explains how to operate the equipment, precautions on safety, and equipment specifications. Please contact your dealer regarding installation of the equipment.

  • Page 3: Table Of Contents

    Table of Contents READ THIS SAFETY PRECAUTION BEFORE OPERATING THE EQUIPMENT....5 ■EMC (ELECTROMAGNETIC COMPATIBILITY) ............12 OUTLINE ........................17 ......17 QUIPMENT OUTLINE STANDARD ACCESSORIES AND OPTIONAL ITEMS ..................18 QUIPMENT CLASSIFICATION ..................19 YMBOL ON THE EQUIPMENT ....................
  • Page 4 4-12-2 Alignment direction indication ................59 4-12-3 Auto Quick Function..................... 60 4-12-4 Auto Retro Mode ....................62 4-12-5 Memory Function....................62 4-12-6 Auto start Function ....................64 4-13 ..........................65 RINT 4-13-1 Auto Print Function ....................65 4-13-2 Contents of printing ....................66 4-13-3 Cutting Procedure of Printer Paper ..............
  • Page 5 6-1-2 Cable Transmission to RV-II ................. 88 PC ....................88 ONNECTION WITH 6-2-1 Connection with PC using USB ................89 6-2-2 Connection using RS-232C ................... 89 MAINTENANCE ......................90 ................90 HECK OF EASUREMENT CCURACY ..................90 HANGE OF RINTER APER ....................

  • Page 6: Read This Safety Precaution Before Operating The Equipment

    Caution 1. Purpose of using the equipment ・ Use ACOMOREF 2 only for the purposes of examining the refractive power, such as measurement of the eye refractive power (Spherical, Cylinder, Axis), pupil size etc. Do not use the equipment for others purposes.
  • Page 7 ・ While operating the equipment, be careful to prevent your fingers from being caught by the machine. ・ When moving the chin rest up and down, the examiner must notify the patient movement and keep an eye on the patient during the operation. Operating the equipment without keeping an eye on the patient may injure the patient.
  • Page 8 ・ The ambient conditions of use: Temperature 10°C to 35°C, Relative humidity 30% to 90% (no dew condensation), Atmospheric pressure 800–1060 hPa ・ Avoid using the equipment in a dusty or dirty room. ・ A semi-dark room is best suited for installation of the equipment. Do not place the equipment facing a bright window or an illumination light.
  • Page 9 ・ This equipment is not waterproof. Therefore, avoid using or installing the equipment in a place where liquids, such as rainwater, drinks, chemicals, etc. may splash on it. ・ When condensation (wet from dew) occurs, wait until the dew dries before using the equipment.
  • Page 10 ・ This is a precise optical device equipment embedded with many electrical components. Handle the equipment with care, avoiding impacts. ・ Pay attention to avoid dropping the equipment or hitting it against another object. ・ In case of a failure, unplug the power cord, and contact your dealer without touching the inside of the equipment, etc.
  • Page 11 (especially, forehead support and chinrest) with a cloth dampened with rubbing alcohol for disinfection. ・ Accessory equipment connected to the analog and digital interfaces must be certified according to the appropriate national standards. Furthermore, all configurations shall comply with the IEC 60601-1. Anyone who connects additional equipment to the signal input part or signal output part is responsible for making sure that the system complies with the requirements of the IEC 60601-1.
  • Page 12 While cleaning the measurement window glass, be careful not to damage or break the glass. ・ Built-in battery This equipment has a built-in lithium primary battery as a power supply for the clock and storing various setting. If the battery is exhausted, the time and date printed on the printout results of measurement will be wrong, or various settings will not be stored and thus the equipment is set back to the default settings each time when it turned off.

  • Page 13: Emc (Electromagnetic Compatibility)

    The Electromagnetic Compatibility Directive sets the essential requirements for electrical and electronic equipment that may disturb or even be disturbed by other equipment. The ACOMOREF 2 complies with these requirements as tabled below. Follow the guidance on the tables for use of the device in the electromagnetic environment.
  • Page 14 3.0m (C)EMC (IEC60601-1-2:2014) (1)Emission guidance ACOMOREF 2 is intended for use in the electromagnetic environment specified below. The customer or the user of the ACOMOREF 2 should assure that they are used in such an environment. Emissions test Basic EMC standard or test method ※...
  • Page 15 ※6: Before modulation is applied. ※7: This test level assumes a minimum distance between the ME EQUIPMENT or ME SYSTEM and sources of power frequency magnetic field of at least 15 cm. if the RISK ANALYSIS shows that the ME EQUIPMENT or ME SYSTEM will be used closer than 15 cm to sources of power frequency magnetic field, the IMMUNITY TEST LEVEL shall be adjusted as appropriate for the minimum expected distance.
  • Page 16 amateur radio bands between 0,15 MHz and 80 MHz are 1,8 MHz to 2,0 MHz, 3,5 MHz to 4,0 MHz, 5,3 MHz to 5,4 MHz, 7 MHz to 7,3 MHz, 10,1 MHz to 10,15MHz, 14 MHz to 14,2 MHz, 18,07 MHz to 18,17 MHz, 21,0 MHz to 21,4 MHz, 24,89 MHz to 24,99 MHz, 28,0 MHz to 29,7 MHz and 50,0 MHz to 54,0 MHz.
  • Page 17 (3)Test Specifications for ENCLOSURE PORT IMMUNITY to RF wireless communications equipment Test Band ※ 1 Service ※ 1 Modulation ※ 2 Maximum Distance IMMUNITY Frequency power TEST LEVEL (MHz) (MHz) (V/m) Pulse 380－390 TETRA400 Modulation ※ 2 18Hz ※ 3 GMRS460 430－470 ±5kHz deviation...

  • Page 18: Outline

    Outline Equipment outline, standard accessories, and optional items ACOMOREF 2 is the objective refractive power measurement equipment capable of measuring the refractive powers of the eye, pupil size, as well as conducting retro observations, accommodation micro fluctuation analysis, addition power measurement.

  • Page 19: Equipment Classification

    Equipment classification <Classification as per 93/42EEC (MDD)> Class IIa <Type of protection against electrical shocks> Class I The equipment does not rely only on the basic insulation for the protection against electrical shocks, but also is equipped with a means to connect a device to the protection installation system of the equipment in the case of a failure of the basic insulation so that a metallic part of the device that can be reached by the human body does not receive dangerous electrical potential.

  • Page 20: Symbol On The Equipment

    Symbol on the equipment : This symbol on the instrument indicates the need for caution. : This symbol indicates the necessity of referring to the relevant part of the instruction manual before use. : This indicates that the classified protection level against electrical shocks of the mounting unit is type B.

  • Page 21: Labels And Indications

    Labels and indications This equipment uses labels and indications for various cautions to attract the user’s attention. Body Indication...
  • Page 22 Type B mounting unit...

  • Page 23: Name And Description Of The Function Of Each Unit

    Name and description of the function of each unit System configuration Infrared emitter unit LCD monitor Power lamp Optical axis height mark Measurement unit Joystick button Joystick Printer cover release button Clamp screw Printer cover Sliding table USB interface Power supply switch R232C interface AC inlet Forehead support...
  • Page 24 Model eye holder unit Spare fuses Clamp screw holder (Use for transportation) Printer cover in an opened status Printer paper Model eye Printer cover (Opened status) (Model eye and printer paper storing status)

  • Page 25: Installation And Preparation For Measurement

    Installation and preparation for measurement Installation Open the container box and take out the unit and accessories. Place the equipment on a stable table (such as a motorized table). Remove the two clamp screw for transportation with a Phillips screwdriver. (Refer the figure below.) Put the supplied caps on the screw holes.
  • Page 26 11. When using chin rest paper (optional), pull up the chin rest pins (at two locations) to put the paper between the pins. Chin rest paper stack with about 5 mm thicknesses is adequate to be put in. ・Replace with a new paper for every new patient. ・Tear and replace with a new sheet of paper.

  • Page 27: Preparing Printer Paper

    Preparing printer paper Press the release button of the printer cover. Open the printer cover and remove the remaining printer paper core. Peel off the fixing tape on the new printer paper. Create a fold line at a location just past the trace of peel-off. Cut out the paper carefully along the fold line.

  • Page 28: Measurement

    Measurement Measurement flow Turning on the power Opening screen display 4-3-1 General screen (REF measurement) 4-3-2 Accuracy check using the model eye Preparation for the patient Chin rest position setting Adjust the height of eye Select measurement mode and start measurement REF measurement mode Screening mode Accommodation micro fluctuation mode...

  • Page 29: Turning On The Power

    Turning on the power Turn on the power at the side of the equipment body. The power lamp will be lit green and the opening screen will be display in about 2 seconds. Display screen 4-3-1 Opening Screen 4-3-2 General Screen (REF measurement) Measurement Type Sequence...
  • Page 30 About “ID/Measurement type/Sequence/Mode/Chart brightness/VD value. It shifts to ID input screen. Measurement Change the measurement type (REF/SCR/AMF/ADD) type (→Refer 4-8 “Screening mode”, 4-9 “Accommodation micro fluctuation mode”, 4-10 “Addition power measurement mode”) Sequence Change the measurement sequence. (R) (→Refer 4-7 “REF measurement mode”) Mode Change the measurement mode.
  • Page 31 INPUT ID SCREEN _ _ _ _ _ _ _ _ _ _ _ _ _ & ERASE EXIT ENTER About key. It is possible to input maximum of 15 characters. ID will clear under these two conditions: Re-enter to ID input screen or precede to next measurement after print out/transfer data.

  • Page 32: Function Key Basic Layout

    4-3-3 Function key basic layout Function keys Transmits the measurement data. SEND 5-3-2 For the transmission format, Refer 5-3-2 “Data signal setting screen <OUTPUT> SIGNAL.” RETRO Proceed to RETRO mode. 5-11 PRINT Print the result. 4-11 Move to SETUP SETUP menu. 4-3-4 SET UP screen <SET UP>...

  • Page 33: Printing Screen

    4-3-5 Printing screen Print screen will show upon finish both eye measurement, or press PRINT / SEND key. M 1/50 -REF- -CV- - 4.50 - 4.25 -PUPIL- - 0.25 - 0.75 -PD- 64.0 PRINT No : 00000 ID:0000000000000 NOW PRINTING... GO TO RETRO ? Execute EYE printing.

  • Page 34: Initial Settings

    Display Cause Solution TIME OUT Refraction measurement Check the measurement manual mode cannot conditions and take conducted within five seconds. improvement measures, such Are eyelashes staying in the as raising the eyelid, optical path? darkening the room, Is the eyelid down? confirming opacity with the Is small pupil size? retro-illumination, etc.
  • Page 35 ■SCR setting screen <MEASURE> SCR M-MODE S+C/2 STIMULUS -3.0[D] ■AMF setting screen <MEASURE> AMF M-TIME SCREENING M-MODE S+C/2 STIMULUS -3.0[D] ■ADDITION / INSET setting screen 1 <MEASURE> ADDITION / INSET INSET NEAR 40[cm] INSET t 13[mm] AMF MODE S+C/2 ■ ADDITION / INSET setting screen 2 <MEASURE> ADDITION / INSET AMF TIME 10[s] / 1step ■...

  • Page 36: Accuracy Check Using The Model Eye

    230V area 24H ■ Language setting screen <LANGUAGE> LANGUAGE ENGLISH ■ MEMORY output screen <MEMORY> MEMORY OUTPUT LAST 30 ■ OTHER setting screen <OTHER> BUZZER TOUCH SOUND ALIGN POWER SAVE 3 MIN Accuracy check using the model eye Insert the two pins of the model eye into the mounting holes for the model eye located at the forehead support.
  • Page 37 Explain the following briefly to the patient. ・ “The measurement will find out the best fit lens prescription automatically.” ・ “Hold your eye as still as possible.” ・ “Try to look at the center of the fireworks.” Let the patient sit on the front of the equipment with both of his/her hands placed lightly on the lap.

  • Page 38: Ref Measurement Mode

    REF measurement mode 4 types of measurement mode and 1 type of measurement sequence are available. You can change the measurement mode by pressing mode key. You can select and change the measurement sequence settings with a sequence key. Operations for each selected mode are listed in the table below. Measurement sequence Measurement mode A:AUTO measurement mode...

  • Page 39: Auto Measurement Mode(A) / Auto Measurement Mode2(A2)

    4-7-1 AUTO Measurement mode(A) / AUTO Measurement mode2(A2) The REF measurement can be carried out. Select a measurement sequence from the sequence key. The details of measurement (REF measurement) vary depending on each measurement sequence setting. Select “A” or “A2”from the mode key item A/A2/C/M. Bring the Mire ring into focus by moving the joystick back and forth before putting the bright point in the alignment mark.
  • Page 40 Bright point Alignment direction indicate mark Once <AUTO START> set to ON under <SETUP>-<AUTO REF MODE>, Auto fogging will activate after the bright spot is located within the alignment mark area. If set to OFF, press joystick button to start after alignment. At this time, if the bright point and Mire ring do not look sharply defined, carry out fine adjustment by moving the joystick back and forth so that they come in focus.
  • Page 41 When mark indication is no longer displayed, measurement starts automatically. The equipment judges the measured data’s differences, etc., and if the measurement data become stable, the equipment will finish the measurement automatically, showing the LCD monitor display as in the figure to the left. If you need to print out the data at this point, select the “PRINT”...

  • Page 42: Continuous Measurement Mode(C)

    Move the sliding table toward the examiner and then shift it to the other eye. Carry out measurement following procedures 3-7. Print screen will show after complete of both eye measurement. If the AUTO PRINT has been set to ON (→ Refer 5-3-1 “Print setting screen <OUTPUT>...

  • Page 43: Manual Measurement Mode (M)

    Carry out measurement on the patient following procedures similar to procedures 3 to 7 in 4-7-1 “AUTO measurement mode.” Measurement will keep continue for 30 seconds. ・ REF measurement will show S+C/2 graph. ・ Print out example -[REF]- REF average [R] SPH MAX value - 4.25 –...

  • Page 44: Screening Mode

    Screening mode Accommodation micro fluctuation status will show when stimuli are being applied during fixation chart move gradually towards the eye from an infinite distance. This mode is for screening purpose only. For precise measurement please proceed to AMF mode. 1.
  • Page 45 Screen for starting measurement in the SCR measurement mode REF value at the preliminary Fixation chart starting measurement S + C/2 position SCR measurement graph Press the “+” key to change the showing position of the fixation chart toward the far point. Press the “-”...
  • Page 46 ・ The MELODY starts playing when the measurement starts. During data acquisition, the alignment mark turns green and the measurement time will start counting. If data cannot be acquired, the alignment mark turns white and the number of times will not count. Press the Melody key to stop the melody. If data successfully acquired, short beeps sound continuously.
  • Page 47 Details of the SCR measurement Starting position S + C/2 [D] fixation chart measurement I STEP stimulus amount -1.0 [D] TOTAL stimulus amount -3.0 [D] or -5.0 [D] 1 STEP measurement time 10 [s] Rest time 3 [s] One eye measurement time -3.0 [D] -5.0 [D] 49 [s]...

  • Page 48: Accommodation Micro Fluctuation Mode

    Accommodation Micro Fluctuation mode Accommodation micro fluctuation status will show when stimuli are being applied during the fixation chart move towards gradually from an infinite distance. 1. Select “AMF” from “Measurement type” which is side of the ref measurement screen and proceed to SCR mode.
  • Page 49 3. After measurement for both eyes, if “PUSH JOYSTICK TO AMF STRAT” is displayed on the screen, press the Joystick button to start the measurement. ＊ You can adjust the starting position of the fixation chart by pressing the “+” or “-” keys before starting measurement.
  • Page 50 ＊ During measurement, carry out the fine adjustment with the joystick so that the bright point always stays inside the reference mark and the Mire ring comes in focus. Screen during AMF measurement Measurement step Measurement time Indicator-showing position Measurement count Data loss status ・...
  • Page 51 5. The results are displayed successively in the graph after every step of measurement. (If the amount of data is small in a measurement step, the graph may not be shown at the corresponding location.) <1 STEP> <2 STEP> <5 STEP>...
  • Page 52 7. When measuring the other eye, pull the sliding table toward the examiner before moving it to the other eye, and then start the measurement. 8. After measurement for both eyes are finished, printout is Printout example carried out automatically in the case of AUTO PRINT: ON in the 5-3-1 “PRINT setting screen.”...

  • Page 53: Addition Power Measurement Mode

    4-10 Addition Power Measurement mode In this mode, the addition power and inset amount are objectively measured based on the amount of the accommodation reaction that occurs when the fixation chart is gradually move towards to the eye from an infinitely far distance. 1.
  • Page 54 ADD measurement start screen ADD measurement REF value at the preliminary Fixation chart starting graph measurement S + C/2 position Switches ON/OFF for the melody play. Exit the ADD measurement. ＊ During measurement, carry out the fine adjustment with the joystick so that the bright point always stays inside the reference mark and the Mire ring comes in focus.
  • Page 55 4. The results are displayed successively in the graph after every STEP measurement. (If the amount of data is small in a measurement step, the graph may not be shown at the corresponding location.) After the ADD measurement, the equipment automatically shifts to the AMF ・...
  • Page 56 Details of the ADD measurement Starting position of the fixation chart for S+C/2 [D] measurement 1 STEP stimulus amount -0.5 [D] TOTAL stimulus amount -5.0 [D] <11 STEP> 1 STEP measurement time 3 [s] Intermission 3 [s] One-eye measurement time (without the AMF 63 [s] measurement) AMF measurement time...

  • Page 57: Retro Mode

    Since the ADD power must be final determined by the subjective test, it must not be determined only based on the result from the ADD measurement. 9. In case where you want to stop during half of the measurement If you need to cancel measurement after starting due to the measurement result is suspected to be presbyopia, etc, press the joystick button to stop the measurement.
  • Page 58 Function key Up or down THERESHOLD. Scaling center of bright spot Printing the binarized image Pressing the key, display the binarized image as shown in the figure below. RETRO X : 5.5 Y : 5.6 Diameter : 3.0mm OPACITY : THRESHOLD : 85/255 PUSH JOYSTICK TO RETURN Function key...

  • Page 59: Various Function

    Function key Moving the upper bar to up or down Moving the lower bar to up or down 4-12 Various function 4-12-1 Pupil size measurement function - This equipment is equipped with the pupil size measurement function that synchronize with REF. Carry out the pupil size measurement when the sequence is set to R.

  • Page 60: Alignment Direction Indication

    ・ The measurement may not be performed when the measurement light is blocked by eyelashes and/or upper lid. If the lateral and vertical values of the pupil are 3.0 mm or smaller, constriction of the pupil may have occurred, and therefore, the brightness of the fixation chart will automatically reduced.(Chart brightness will change to L) Note that this function will only work in AUTO MODE/AUTO MODE2.

  • Page 61: Auto Quick Function

    If the alignment direction indication key is displayed as shown in the figure to the right, move the body to the lower left direction to achieve the alignment. 4-12-3 Auto Quick Function Auto Quick will be useful when measuring small children, frequently moving eye or poor fixation eye’s patient.
  • Page 62 “AUTO QUICK,” will show when system switch to AUTO QUICK MODE. AUTOQUICK Display The Auto Quick function will only activate when the mode is AUTO MEASUREMENT MODE (A) or AUTO MEASUREMENT MODE2(A2). Auto Quick will not apply for Continuous Measurement Mode(C) or Manual Measurement Mode(M).

  • Page 63: Auto Retro Mode

    4-12-4 Auto Retro Mode When the measurement data are vary or cannot be acquired, it will proceed to RETRO MODE automatically to allow for the observation of the optic media. In the Auto Measurement Setting Screen in <SETUP>, set “AUTO RETRO” setting to “ON.”...
  • Page 64 2.1. If AUTO PRINT set to “ON” (Refer to 5-3-1), data will be saved after printout/output. As show on the below image, the save count will increase. Refer to “2.2 Auto Print OFF” if using C or M mode. Display of the LCD monitor during printing M 1/50 -REF- -CV-...

  • Page 65: Auto Start Function

    If save data is over 50 person, the below screen will show up. If press “YES”, all of the saved 50 person data will delete, the latest save data will count as 1. If select “NO”, the save data will keep un-touch. M50/50 -REF- -CV-...

  • Page 66: Print

    4-13 Print After the measurement is finished, the measurement data can be print out. ・The measurement cannot be perform while printing. ・Tear off the print out paper by tearing it upward. (→ Refer 4-13-3 “Cutting Procedure of Printer Paper”) 4-13-1 Auto Print Function After the measurement, data will print out automatically.

  • Page 67: Contents Of Printing

    4-13-2 Contents of printing The content of printing is that set in 5-3-1 “Print Setting Screen” in <SETUP>. The measurement results to be printed are up to 8 data sets for one eye. (For the auto measurement, it is up to 5 data sets for one eye.) Data communication setting allows the equipment to communicate with external devices in parallel while printing.
  • Page 68 –0.62 Eye Print Ref + Pupil Size Measurement x:5.7 y:5.7 value (Right Eye) –2.12 –0.62 x:5.7 y:5.7 Message ACOMOREF 2 –2.00 –0.62 x:5.8 y:5.8 Right Eye Ref Reliability value ＊ –2.12 –0.62 111 10 Ref + Pupil Size (S+C/2 = – 2.37)

  • Page 69: Cutting Procedure Of Printer Paper

    4-13-3 Cutting Procedure of Printer Paper Tear out the printer paper by holding the right edge of the paper, and cut the paper by pulling it up to the direction as shown in the figure on the right. ・ Small amount of paper dust generated when teared off the print out paper may be caused failure to print by adhering to the printer vent or thermal head.

  • Page 70: About Representative Data

    1． Once ready for measurement, fixation chart will looks blur at patient side. (Fogging Status) ↓ 2． Acquire the data. ↓ 3． Beep sound play once obtained the data. ↓ 4． The fixation chart remains blur at patient side. ↓ 5．...

  • Page 71: About Auto Power Saving

    refer 4-13-2 “Contents of printing.” ・ 8 or higher: The variation is small. ・ 7 or lower: There is a variation. The handling of the measurement result requires adequate care. Check the unstable data under C mode measurement. 4-15-4 About Auto Power Saving When there is no switch operation within the preset time while the measurement is not performed, the power of this equipment automatically goes into the power saving mode.

  • Page 72: Setting Procedures

    ・ When measuring the patient eye with a contact lens: Normally the measurement value can be obtained. However, if the contact lens does not fit completely, the correct value cannot be obtained. The measurement cannot be performed when the contact lens is dirty or damaged. , ・...

  • Page 73: Ref Setting Screen

    <MEASURE> To “5-1-1 REF Setting Screen <REF>” To “5-1-3 SCR Setting Screen <SCR>” To “5-1-4 AMF Setting Screen <AMF>” To “5-1-5 ADDITION / INSET Setting Screen ADDITION / INSET <ADD>” MEASURE TYPE To “5-1-6 MEASURE TYPE Setting Screen” 5-1-1 REF Setting Screen <REF> On the <MEASURE>...

  • Page 74: Scr Setting Screen

    Item Selection Item Description PUPIL The pupil size is measured once in a one eye measurement. The pupil size is measured after the REF measurement. No measurement CYL is converted to minus. － No CYL measurement value conversion CYL is converted to plus. ＋...

  • Page 75: Amf Setting Screen

    5-1-3 AMF Setting Screen <AMF> Select <AMF> on the <MEASURE> screen to go into the AMF Setting Screen. The settings for the measurement time and the setting for the accommodative stimulus amount can be set on this screen. The setting for each item can be set by key.

  • Page 76: Measure Type Setting Screen

    <MEASURE> ADDITION/INSET AMF TIME 10 [s] / 1step INSET d VD (12.0 [mm]) Item Selection Item Description INSET NEAR 30–50 [cm] The target near point distance is set. It can be set in an increment of 5 cm. INSET t 12–15 The center of rotation is set.

  • Page 77: Auto Measurement Setting

    Auto Measurement Setting <AUTO REF MODE> On the <SETUP> screen, press the <AUTO REF MODE> key to go into the AUTO Measurement Setting Screen. The measurement contents can be changed on this screen. The setting for each item can be set by key.

  • Page 78: Print Setting Screen Print

    5-3-1 Print Setting Screen <OUTPUT> PRINT On the <OUTPUT> screen, press the “PRINT” key to go into the Print Setting Screen. The contents for print output can be changed on this menu. The setting for each item can be set by key.
  • Page 79 Item Selection Item Description AUTO PRINT&SEND Auto print setting when the Auto Measurement mode is used: PRINT&SEND: After measurement, data will print and send automatically. SEND ONLY SEND ONLY: After measurement, only data transmission is performed automatically. OFF: After measurement, print data transmission are not performed automatically.

  • Page 80: Data Signal Setting Screen Signal

    5-3-2 Data Signal Setting Screen <OUTPUT> SIGNAL On the <OUTPUT> screen, press the “SIGNAL” key to go into the Data Signal Setting Screen. The output settings for the data transmission by infrared transmission or via cable connection can be changed on this screen. The setting for each item can be set by key.
  • Page 81 ON: The measurement value is transmitted. REF set to OFF OFF: No transmission The setting of infrared transmission is set. RT: Select this when the data is transmitted to the Righton products. RV: Select this when the data is transmitted to RV-II. CLOSE: Not transmitted...

  • Page 82: Print No. Setting

    PRINT No. Setting<PRINT No.> On the <SETUP> screen, press the “PRINT No.” key to go into the PRINT No Setting Screen. Press the number key corresponding to the desired number to input the number where the cursor is positioned (indicate in orange). ■...

  • Page 83: Time/Date Setting

    Time/Date Setting<CLOCK> On the <SETUP> screen and press the “CLOCK” key to go into the Time/Date Setting Screen. In addition to the time and date, the display formats of time and date can be set on this screen. The setting for each item can be set by key.

  • Page 84: Language Output Setting

    Language Output Setting <LANGUAGE> By selecting the language setting from the table below, the display for print out will changed. <LANGUAGE> <LANGUAGE> Content of Language Output Setting Selection Item Language RIGHT LEFT AXIS ENGLISH DANISH DUTCH FRENCH GERMAN HUNGARIAN INDONESIAN ITALIAN NORWEGIAN POLISH...

  • Page 85: Memory Management Setting

    Memory Management Setting<MEMORY> On the <SETUP> screen and press the “MEMORY” key to go into the MEMORY Output Screen. Printing, data transmission through RS-232C, or data erasing of all the past measurement values recorded in this equipment (max. 50 patients (100 eyes) is performed on this screen.

  • Page 86: Initial Setting

    Initial Setting <INITIAL> On the <SETUP> screen, press the “INITIAL” key to display a confirmation message. If “YES” key is pressed, a confirmation message will displayed. If “YES” key is pressed again, all the settings in SET UP will restored to the default settings and clear the memory.

  • Page 87: Other Setting

    5-10 Other Setting<OTHER> On the <SETUP> screen and press the “OTHER” key to go into the OTHER Setting Screen. The setting contents can be changed on this screen. The setting for each item can be set by key. <OTHER> BUZZER TOUCH SOUND ALIGN POWER SAVE...

  • Page 88: Melody Setting

    5-11 Melody Setting <MELODY> Select <MELODY> on the <SETUP> screen to go into the MELODY Setting Screen. The setting contents can be changed on this screen. By selecting the desired item using the function keys, the setting can be changed. The setting for each item can be set by key.

  • Page 89: Connection To External Devices

    Connection to External Devices The connector is used for the interfaces in conformity with EIA RS-232C. The measurement results can be transmitted to external devices, such as a PC etc. via this connector. Connection with Remote Vision RV-II Before starting the subjective examination, the REF data can be transmitted automatically for faster measurement.

  • Page 90: Connection With Pc Using Usb

    6-2-1 Connection with PC using USB Use a USB cable (A-B type connector) to connect the equipment with a PC. Connect the B type connector to the equipment. To output to a PC, set “PORT” on the Data Signal Setting Screen to “USB.” (→ Refer 5-3-2 “Data Signal Setting Screen”) and “bit/sec”...

  • Page 91: Maintenance

    Maintenance This device does not require periodic calibration. Check of Measurement Accuracy Check the measurement accuracy every time before using the equipment by using the model eye provided. For the measurement method using the model eye and the accuracy check method, Refer 4-5 “Accuracy check using the model eye”. If the value does not fall in the range after conducting measures described in 4-5 “Accuracy check using the model eye”, contact your dealer.

  • Page 92: Cleaning Of Chin Rest And Forehead Support

    The spare fuses are located in the spare fuse holder inside the printer cover. （→ Refer 2-1 “System configuration”) Cleaning of Chin rest and Forehead Support Cleaning should be done before the measurement. Clean the chin rest and forehead support with soft cloth, etc. soaked with rubbing alcohol. ex) “Schnelldesinfektion”, “Sixtan®...

  • Page 93: Cleaning Of Unit (Exterior)

    Cleaning of Unit (Exterior) When the exterior becomes dirty, wipe it with soft cloth. For severe dirt, use a soak gauze (dilate with mild detergent) to wipe it gently. We recommend the use of the dust cover provided after using the equipment for the prevention of fouling, such as dust.

  • Page 94: Troubleshooting

    Troubleshooting ● Please check the following points before you send your equipment for repair. Phenomenon Check Cause and Solution The POWER lamp does Is the AC cable not plugged Check the fuses and replace not light up after the them. power is turned ON.

  • Page 95: Main Specifications

    Main Specifications <Name> ACOMOREF 2 <Measurement Function> ▼REF measurement Measurement range: S+C: -20D to +23D (VD=12mm) 0D to ±12D 0° to 180° Measurement step: S,C: AUTO/ 0.25D/ 0.12D 1° Min. pupil size: φ2.3mm Measurement wavelength: 840 to 900nm Cornea vertex distance: 12/ 13.5/ 13.75/ 15/ 16/ 0...
  • Page 96 <Other> Main body dimension: W 254 x D 469x H 477 mm Weight: 13kg Moving range of main body: Longitudinal 38 mm or more Lateral 58 mm or more Chin rest moving range: 45 mm (86 to 131 mm from baseline to chin rest) Input power: 100 –...
  • Page 97 RIGHT MFG. CO., LTD. 1-47-3, Maeno-cho, Itabashi-ku, Tokyo, 174-8633 Japan. Tel : +81-3-3960-2275 Fax : +81-3-3960-2285 TOHOKU RIGHT MFG. CO., LTD. OPHTHALMIC SERVICE 45-1, Aza Yashikimae, Nakamura Osato-cho, Kurokawa-gun, Miyagi, 981-3521 Japan. Tel : +81-22-359-3113 Fax : +81-22-359-3213 Medical Device Safety Service GmbH Schiffgraben 41 30175 Hannover, Germany...
