Overhead door TIMER CLOSE EXPANSION MODULE Manual page 14

STALL > UP LIMIT
5D
60 CHECK STOP BTN
61 TCM DISABLED
NO RADIO >> C/C
62
Error Codes (cont')
63 CHECK AUX OPEN
64 CHECK STOP KEY
65 CHECK N-O SAFETY
CODES DISPLAY
66 CHECK ODC STB
67 CHECK N-C SAFETY
68 CHECK MON. EDGE
69 OVERHEATED MOTOR
NO RUN > DOWN LIM
6C
NO RUN > UP LIMIT
6D
NO RUN > MID STOP
6E
Condition
DISPLAY
6F EXP MODULE FAIL
Code
70 BOARD FAILURE 70
71 BOARD FAILURE 71
74 BOARD FAILURE 74
75 BOARD FAILURE 75
76 BOARD FAILURE 76
77 BOARD FAILURE 77
80 BOARD FAILURE 80
81 BOARD FAILURE 81
82 BOARD FAILURE 82
83 BOARD FAILURE 83
84 BOARD FAILURE 84
85 EXP PORT PROBLEM
86 BOARD FAILURE 86
88 TCM FAILURE
8A AOM FAILURE
8E REV INTERRUPTED
8F LIMIT MOD. FAIL
90 DIAGNOSTIC MODE
OPEN BTN BAD > PU
A0
CLOSE BTN BAD > PU
A1
ONE BTN BAD > PU
A2
RADIO BAD > PWR UP
A3
AUX OPEN BAD > PU
A4
OPEN KEY BAD > PU
A5
CLOSE KEY BAD > PU
A6
MULT KEYS BAD > PU
A7
TCM BAD > POWER UP
AA
T M I R E L C O E S M O D U E L
GDO STOPPED BECAUSE IT COULDN'T LEAVE THE UP LIMIT DUE TO A SLIPPING CLUTCH OR OTHER PROBLEM
GDO WON'T RUN BECAUSE THE STOP BUTTON IS ACTIVE
TIMER CLOSE WON'T WORK BECAUSE NO SAFETIES ARE ENABLED
RADIO INPUT WON'T WORK WITH OPEN OR CLOSE FUNCTION IN CONSTANT CONTACT MODE
GDO WON'T CLOSE BECAUSE AUXILIARY OPEN INPUT IS ACTIVE
GDO WON'T RUN BECAUSE THE KEYPAD STOP KEY IS ACTIVE
GDO WON'T CLOSE BECAUSE THE N-O REVERSING IS ACTIVE
DESCRIPTION
GDO WON'T CLOSE BECAUSE THE ODC STB IS BLOCKED
GDO WON'T CLOSE BECAUSE THE N-C REVERSING INPUT IS ACTIVE
GDO WON'T CLOSE BECAUSE THE MONITORED EDGE SENSOR IS ACTIVE
GDO WON'T RUN BECAUSE THE MOTOR IS OVERHEATED
GDO WON'T CLOSE BECAUSE ITS ALREADY AT THE DOWN LIMIT
GDO WON'T OPEN BECAUSE ITS ALREADY AT THE UP LIMIT
GDO WON'T RUN BECAUSE ITS AT OR ABOVE THE MID-STOP LIMIT & CAN'T RUN UP & A REVERSING INPUT IS PREVENTING IT FROM CLOSING
Condition Code Description
GDO WON'T RUN BECAUSE AN EXPANSION MODULE FAILURE IS PREVENTING IT
CONTROL BOARD FAILURE 70, CONTACT FACTORY TECHNICAL SERVICE DEPT.
CONTROL BOARD FAILURE 71, CONTACT FACTORY TECHNICAL SERVICE DEPT.
CONTROL BOARD FAILURE 74, CONTACT FACTORY TECHNICAL SERVICE DEPT.
CONTROL BOARD FAILURE 75, CONTACT FACTORY TECHNICAL SERVICE DEPT.
CONTROL BOARD FAILURE 76, CONTACT FACTORY TECHNICAL SERVICE DEPT.
CONTROL BOARD FAILURE 77, CONTACT FACTORY TECHNICAL SERVICE DEPT.
CONTROL BOARD FAILURE 80, CONTACT FACTORY TECHNICAL SERVICE DEPT.
CONTROL BOARD FAILURE 81, CONTACT FACTORY TECHNICAL SERVICE DEPT.
CONTROL BOARD FAILURE 82, CONTACT FACTORY TECHNICAL SERVICE DEPT.
CONTROL BOARD FAILURE 83, CONTACT FACTORY TECHNICAL SERVICE DEPT.
CONTROL BOARD FAILURE 84, CONTACT FACTORY TECHNICAL SERVICE DEPT.
EXPANSION PORT IS SHORT CIRCUITED, TRY DISCONNECTING EXPANSION MODULES OR CONTACT FACTORY TECHNICAL SERVICE DEPT.
CONTROL BOARD FAILURE 86, DISCONNECT EXPANSION MODULES. IF NO CHANGE, CONTACT FACTORY TECHNICAL SERVICE DEPT.
TIMER CLOSE MODULE (TCM) HAS FAILED
AUXILIARY OUTPUT MODULE (AOM) HAS FAILED
GDO LOST POWER OR ENCOUNTERED ANOTHER PROBLEM DURING THE REVERSAL PROCESS, REVERSAL IS COMPLETING NOW
GDO WON'T RUN, LIMIT MODULE HAS FAILED
GDO IS IN DIAGNOSTIC MODE, NORMAL FUNCTIONS ARE NOT ALLOWED
OPEN & CLOSE BUTTONS WON'T WORK, THE OPEN BUTTON WAS ACTIVE WHEN THE GDO WAS POWERED-UP
OPEN & CLOSE BUTTONS WON'T WORK, THE CLOSE BUTTON WAS ACTIVE WHEN THE GDO WAS POWERED-UP
1 BUTTON WON'T WORK, THE 1 BUTTON WAS ACTIVE WHEN THE GDO WAS POWERED-UP
RADIO INPUT WON'T WORK, THE RADIO INPUT WAS ACTIVE WHEN THE GDO WAS POWERED-UP
AUXILIARY OPEN INPUT WON'T WORK, THE AUXILIARY OPEN INPUT WAS ACTIVE WHEN THE GDO WAS POWERED-UP
KEYPAD OPEN & CLOSE KEYS WON'T WORK, THE OPEN KEY WAS ACTIVE WHEN THE GDO WAS POWERED-UP
KEYPAD OPEN & CLOSE KEYS WON'T WORK, THE CLOSE KEY WAS ACTIVE WHEN THE GDO WAS POWERED-UP
1 OR MORE KEYPAD CALIBRATION KEYS WON'T WORK, 1 OR MORE WERE ACTIVE WHEN THE GDO WAS POWERED-UP
TIMER CLOSE MODULE WON'T CLOSE DOOR, IT WAS ACTIVE WHEN THE GDO WAS POWERED-UP
