Mission:
Build your Motion Ball
SIDE A
Assembly
Front View
INVENTORY
1 Center Base
2 O-Ring
1 4-Pin Cable
4 Sides
2 Screws
2 Caps
1 Sensor
GETTING STARTED
Gather and organize your supplies
Center Base x 1
1
2
Install
2 Screws
through
the holes
Align holes
Side View
Base
Connect 4-Pin
Cable to Sensor
Caps x 2
O-Ring x 2
4-Pin Cable x 1
3
Orient
the + of
Z-axes
upwards
Sides x 4
Screws x 2
Sensor x 1
ASSEMBLY
Attach
O-Rings
COMPLETE!
Head to
Piper Make
to continue
your mission
make.playpiper.com
