Huntron Access USB
Huntron Access 2 USB
USER'S MANUAL
P/N 21-1352
Rev. P
Version 1.1
November, 2021
Copyright  2018 Huntron, Inc. All rights reserved.
Huntron, Tracker, ProTrack, and Huntron Access are registered trademarks of Huntron, Inc. All
other names are trademarks or registered trademarks of their respective companies.
This document may not be copied in whole or in part, or otherwise reproduced except as specifically
permitted under U.S. copyright law, without the prior written consent of Huntron, Inc.,
15720 Main Street, Suite#100, Mill Creek, WA, 98012, USA.
