1
Appearance and Interface
Dimensions
Analog Cabinet Speaker
Quick Start Guide
UD36270B
Bottom Interfaces
6-Ø8 mm (0.32")
Constant Voltage Input Interface
Note
When the
constant voltage input interface is
connected to the 100 V input and the power
knob 2 is adjusted to 70 V, the power knob 1 cannot be adjusted to 20 W.
When the power knob 1 is adjusted to 8 Ω, the power knob 2 can only be adjusted to 8 Ω.
When the power knob 2 is adjusted to 8 Ω, the power knob 1 can only be adjusted to 8 Ω.
268.4 mm (10.57")
4-40 mm (1.57")
Bracket
2
Preparation Before Installation
Power Knob 1
Power Knob 2
Switch the power off before installation.
A drill template is required for device installation. It is recommended to install the device at
a distance of 3.24 m~6.24 m from the ground and ≥ 0.69 m from the ceiling.
Connect the analog speaker to amplifier by
detailed information.
100 mm
Note
constant voltage input interface
. See Chapter 1 for
