GE is a trademark of the General Electric Company. Manufactured under trademark license.
USING THE DRYER
WiFi Connect . . . . . . . . . . . . . . . . . . . . . . . . 5
Getting Started . . . . . . . . . . . . . . . . . . . . . . 5
Cycles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Loading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
. . . . . . . . . . . . . . . . . . 12
Stacking (Optional) . . . . . . . . . . . . . . . . . . .32
Write the model and serial
numbers here:
Model # _________________
Serial # _________________
They are on the label on the front
of the dryer behind the door.
. . . . . . . . .3
OWNER'S MANUAL &
. . . . . . . . . . 11
ENGLISH/FRANÇAIS/
. . . . . 36
. . . . . . . . . . 39
. . . . . . . . . 40
49-3000206
INSTALLATION
INSTRUCTIONS
GFD85
GFD65
GFD55
GFV55
ESPAÑOL
Rev 1
09-19 GEA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GFV55 and is the answer not in the manual?

Questions and answers

Related Manuals for GE GFV55

Summary of Contents for GE GFV55

  • Page 1: Table Of Contents

    Model # _________________ Serial # _________________ They are on the label on the front of the dryer behind the door. 49-3000206 Rev 1 GE is a trademark of the General Electric Company. Manufactured under trademark license. 09-19 GEA...
  • Page 2 THANK YOU FOR MAKING GE APPLIANCES A PART OF YOUR HOME. Whether you grew up with GE Appliances, or this is your first, we’re happy to have you in the family. We take pride in the craftsmanship, innovation and design that goes into every GE Appliances product, and we think you will too.

  • Page 3: Safety Information

    IMPORTANT SAFETY INFORMATION. READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE To reduce the risk of fire, explosion, electric shock, or injury to persons when using your WARNING appliance, follow basic precautions, including the following: • Read all instructions before using the appliance. •...
  • Page 4 IMPORTANT SAFETY INFORMATION READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE ADDITIONAL GAS DRYER WARNINGS WARNING - Fire or Explosion Hazard Failure to follow safety warnings exactly could result in serious injury, death, or property damage. - DO NOT store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.

  • Page 5: Wifi Connect

    Throughout this manual, features and appearance will vary from your model. WiFi Connect (For customers in the United States only - on some models) Your dryer is GE Appliances WiFi Connect enabled. WiFi Label Location Visit geappliances.com/connect and enter your model number to show you the proper steps to connect your appliance.
  • Page 6 Getting started Features and appearance will vary. Power Press to “wake up” the display. If the display is active, press to put the dryer into idle mode. NOTE: Pressing Power does not disconnect the appliance from the power supply. Start and Pause Press Start to begin the cycle.

  • Page 7: Cycles

    Getting started Drying Sensor cycles automatically determine fabric dryness. Cycles Timed cycles run for the selected time. MIXED LOADS For loads consisting of cottons and poly-blends. ® COTTONS For cottons and most linens. NOTE: ENERGY STAR models are tested on COTTONS cycle with default settings (Temp setting on Low, Level setting on Dry, and ecoDry default on).

  • Page 8: Settings

    Option 2 - Remote Start: Set your dryer to “AP” using the Delay Dry pad. This allows you to use the GE Appliances Laundry App via your smartphone to start your dryer remotely at the time of your choosing. If the dryer is set to AP with no activity, it will start the dryer 24 hours later.
  • Page 9 Getting started Options (cont.) Wrinkle Care Use this option to minimize the wrinkles in clothes. It provides 1 hour of no-heat tumbling after the clothes are dry. If you are using the cycle Sound and you select the Wrinkle Care option, a signal will sound at the end of the drying time and several times during the Wrinkle Care cycle.

  • Page 10: Loading

    Loading Always follow fabric manufacturer’s care label when laundering. Sorting and Loading Hints WARNING - Fire Hazard • Keep flammable materials and vapors, such as • DO NOT dry anything that has ever had any type of oil gasoline, away from dryer. on it (including cooking oils).

  • Page 11: Care And Cleaning

    Remove the cleaner residue and then dry with a clean cloth. The stainless steel used to make the dryer drum provides the highest reliability available in a GE Appliances dryer. If the dryer drum should be scratched or dented during normal use, the drum will not rust or corrode. These surface blemishes will not affect the function or durability of the drum.

  • Page 12: Installation Instructions

    Installation Dryer Instructions If you have any questions, call GE Appliances at 800.GE.CARES (800.432.2737) GEAppliances.com or visit our Website at: In Canada, call 800.561.3344 www.GEAppliances.ca or visit BEFORE YOU BEGIN WARNING Read these instructions completely and carefully. IMPORTANT - Risk of Fire •...
  • Page 13 These hoses are manufactured and tested WE25X20060 Complete Kit (hoses, Y-adapter, washers) to meet GE Appliances specifications. GE Appliances strongly recommends the use of new water WE49X25794 Kit (Short hose, Y-adapter, washers) supply hoses. Hoses degrade over time and need to be...
  • Page 14 Installation Instructions REQUIREMENTS FOR ALCOVE OR MINIMUM CLEARANCE OTHER CLOSET INSTALLATION THAN ALCOVE OR CLOSET INSTALLATION WARNING - Explosion Hazard Minimum clearance to combustible surfaces and for air opening are: 0” both sides , 0” rear and 0” top. Keep flammable materials and vapors, such as gasoline, For improved performance, a 1/2”...
  • Page 15 Installation Instructions CONNECTING INLET HOSES (for steam dryer models only) CONNECTING INLET HOSES CONNECTING INLET HOSES (cont.) To produce steam, the dryer must connect to the cold water supply. Since the washer must also connect to the cold water, a “Y” connector is inserted to allow both inlet hoses to make that connection at the same time.
  • Page 16 Installation Instructions CONNECTING A GAS DRYER (skip for electric dryers) TOOLS YOU WILL NEED • Before beginning the installation, turn off the circuit breaker(s) or remove the dryer’s circuit fuse(s) at 10” Adjustable Flat-blade the electrical box. Be sure the dryer wrenches (2) screwdriver cord is unplugged from the wall.
  • Page 17 Installation Instructions CONNECTING A GAS DRYER (cont.) GAS REQUIREMENTS GAS SUPPLY • A 1/8” National Pipe Taper thread plugged WARNING - Explosion Hazard tapping, accessible for test gauge connection, must be installed immediately upstream of the • Use a new CSA International approved flexible gas supply connection to the dryer.
  • Page 18 Installation Instructions CONNECTING A GAS DRYER (cont.) CONNECTING THE DRYER TO CONNECTING THE DRYER TO THE GAS SUPPLY (cont.) THE GAS SUPPLY Install a female 3/8” NPT elbow at the end of Install a 1/8” NPT plugged tapping to the the dryer gas inlet.
  • Page 19 Installation Instructions CONNECTING A GAS DRYER (cont.) ELECTRICAL CONNECTION TEST FOR LEAKS INFORMATION FOR GAS DRYERS Never use an open flame to test for gas leaks. (cont.) Check all connections for leaks with soapy solution or equivalent. • Dryer must be electrically grounded in accordance with local codes and ordinances, or in the absence Apply a soap solution.
  • Page 20 6 feet in 24 hours a day or by phone at 877.959.8688 during Access Panel length. normal business hours. In Canada, visit your local (Kit WE16X29317) GE Appliances parts distributor or call 800.661.1616 or (if needed) GEAppliances.ca/en/products/parts-filters-accessories. 49-3000206 Rev 1...
  • Page 21 Installation Instructions ELECTRICAL CONNECTION ELECTRICAL CONNECTION INFORMATION FOR ELECTRIC INFORMATION FOR ELECTRIC DRYERS DRYERS For electrical connections using a For direct wire connections: power cord: WARNING - Fire Hazard WARNING - Fire Hazard Use 10 gauge copper wire. Use a new UL-listed 240V 30 amp dryer power supply Use a UL-listed strain relief.
  • Page 22 Installation Instructions CONNECTING AN ELECTRIC DRYER (cont.) CONNECTING DRYER USING CONNECTING DRYER USING 3-WIRE CONNECTION 4-WIRE CONNECTION (MUST BE USED FOR MOBILE HOME If required, by local code, install external ground (not provided) to grounded metal, cold water pipe, or other INSTALLATION) established ground determined by a qualified electrician.
  • Page 23 • If rigid metal cannot be used, then UL-listed flexible transition duct, or within the dryer. metal clothes dryer transition duct (GE Appliances DO NOT use flexible metal or metal foil ducting part – PM08X10085) can be used.
  • Page 24 Installation Instructions EXHAUSTING THE DRYER (cont.) • DO cut duct as short • DO use elbows as possible and when turns are install straight into necessary. wall. Elbows • DO NOT bend • DO NOT use • DO NOT • DO NOT or collapse excessive crush duct...
  • Page 25 Installation Instructions EXHAUSTING THE DRYER (cont.) EXHAUST SYSTEM CHECKLIST STANDARD REAR EXHAUST HOOD OR WALL CAP We recommend that you install your dryer before installing your washer. This will permit direct • Terminate in a manner to prevent back drafts or entry of access for easier exhaust connection.
  • Page 26 Installation Instructions EXHAUSTING THE DRYER (cont.) SIDE VENTING SIDE VENTING (cont.) • Insert and connect the elbow/exhaust duct assembly WARNING - Fire Hazard to the blower housing and orient the elbow for either left or right venting. Disconnect dryer from electrical supply. Wear gloves and arm guards.
  • Page 27 Installation Instructions EXHAUSTING THE DRYER (cont.) SIDE VENTING (cont.) BOTTOM VENTING For LEFT venting: Dryer Exhaust to the bottom of cabinet for Gas and Electric models WITHOUT Built-In Pedestal™. • Locate the 15-1/2” exhaust duct from the kit. • Insert exhaust duct through knockout opening on WARNING - Fire Hazard the LEFT side of dryer.
  • Page 28 Installation Instructions EXHAUSTING THE DRYER (cont.) BOTTOM VENTING (cont.) BOTTOM VENTING (cont.) • Locate the 12-1/2” exhaust duct and elbow duct • Install the new access panel from the kit. from the kit and assemble together. Apply duct tape • Secure access panel with 4 screws saved from around the joint to eliminate leaks between ducts.
  • Page 29 Installation Instructions FINAL SETUP LEVEL THE DRYER DRYER START-UP Stand the dryer upright near the final location and Press the Power pad. adjust the four leveling legs at the corners to ensure that the dryer is level from side to side and front to rear.

  • Page 30: Reversing The Door Swing (Optional)

    Installation Instructions REVERSING THE DOOR SWING (Optional) BEFORE YOU START Unplug the dryer from its electrical outlet. TOOLS YOU WILL NEED Phillips-head screwdriver T-25 torx driver 1/4” nut driver IMPORTANT NOTES • Handle parts carefully to avoid scratching paint. • Once you begin, do not move the cabinet until door-swing reversal is completed.
  • Page 31 Installation Instructions REVERSING THE DOOR SWING (Optional) REMOVE, ROTATE AND REPLACE REPLACE THE INNER DOOR THE HANDLE AND HINGE INTO • Replace the inner door frame into the outer door. THE OPPOSITE SIDES • Replace the 14 screws into the inner door, using a Phillips-head screwdriver, securing it to the outer door.

  • Page 32: Stacking (Optional)

    If you are planning to stack the washer and dryer, order Stacking Kit number GFA28KITN to be used for this dryer. Kit sold separately. If you have any questions, call GE Appliances at 800.432.2737 or visit our Website at: GEAppliances.com In Canada, call 800.561.3344 or visit www.GEAppliances.ca...
  • Page 33 Installation Instructions STACKING THE WASHER AND DRYER (Optional Kit GFA28KITN) TOOLS YOU WILL NEED INSTALL SPACERS TO THE Phillips screwdriver Pliers DRYER BOTTOM Locate a spacer on the bottom side with its holes over Gloves the leveling leg holes. Attach spacer using 2 screws. Open-ended wrench Attach the second spacer on the other bottom side Level...
  • Page 34 Installation Instructions STACKING THE WASHER AND DRYER (Optional Kit GFA28KITN) INSTALL THE APPROPRIATE PREPARE THE WASHER AND BRACKETS TO THE WASHER DRYER A. Place the washer in the approximate final Washer Depth Dryer Depth Bracket Number installation location. 32" 32" B.
  • Page 35 Installation Instructions STACKING THE WASHER AND DRYER (Optional Kit GFA28KITN) INSTALL THE DRYER AND THE FINALIZE THE INSTALLATION BRACKET ON THE WASHER Do not push on the dryer once CAUTION installed to top of the washer. - Excessive Weight WARNING Pushing on the dryer may result in pinched Hazard fingers.

  • Page 36: Troubleshooting Tips

    Troubleshooting Tips... Before you call for service Problem Possible Cause What To Do Dryer shakes or Some shaking/noise is normal. Move dryer to an even floor space, or adjust leveling legs as makes noise Dryer may be sitting unevenly. necessary until even. Clothes take Improper or obstructed Check the Installation Instructions to make sure the dryer...
  • Page 37 Troubleshooting Tips... Before you call for service Problem Possible Causes What To Do Dryer doesn’t Fuse is blown/circuit breaker Check the building’s fuse/circuit breaker box and replace both heat is tripped; the dryer may fuses or reset both breakers. Your dryer may tumble if only one tumble but not heat fuse is blown or one breaker tripped.
  • Page 38 Try a fabric softener. Bounce Fabric Conditioner Dryer Sheets have been approved for ® use in all GE Appliances dryers when used in accordance with the manufacturer’s instructions. Overdrying Try a fabric softener. Adjust setting to Less Dry or Damp.

  • Page 39: Limited Warranty

    This limited warranty is extended to the original purchaser and any succeeding owner for products purchased for home use within the USA. If the product is located in an area where service by a GE Appliances Authorized Servicer is not available, you may be responsible for a trip charge or you may be required to bring the product to an Authorized GE Appliances Service location for service.

  • Page 40: Consumer Support

    Have a question or need assistance with your appliance? Try the GE Appliances Website 24 hours a day, any day of the year! You can also shop for more great GE Appliances products and take advantage of all our on-line support services designed for your convenience.
