Summary of Contents for PITSOS WUP1401G9
- Page 1 User manual and installation instructions WUP1401G9 Washing machine...
-
Page 2: Table Of Contents
Futher information and explanations are available online: Table of contents 1 Safety .......... 4 7 Display ........ 19 1.1 General information.... 4 8 Buttons ........ 21 1.2 Intended use....... 4 1.3 Restriction on user group... 4 9 Programmes ....... 23 1.4 Safe installation ...... 5 10 Accessories...... - Page 3 16.2 Cleaning the detergent drawer........ 30 16.3 Cleaning the drain pump.. 31 17 Troubleshooting....... 35 17.1 Emergency release .... 44 18 Transportation, storage and disposal ........ 44 18.1 Removing the appliance .. 44 18.2 Inserting the transit bolts.. 44 18.3 Using the appliance again .. 44 18.4 Disposing of old appliance .. 45 19 Customer Service.....
-
Page 4: Safety
en Safety 1 Safety Observe the following safety instructions. 1.1 General information Read this instruction manual carefully. ¡ Keep the instruction manual and the product information safe ¡ for future reference or for the next owner. Do not connect the appliance if it has been damaged in transit. ¡... -
Page 5: Safe Installation
Safety en 1.4 Safe installation Take note of the safety instructions when installing the appliance. WARNING ‒ Risk of electric shock! Improper installation is dangerous. Connect and operate the appliance only in accordance with the ▶ specifications on the rating plate. Connect the appliance to a power supply with alternating cur- ▶... - Page 6 en Safety WARNING ‒ Risk of injury! The high weight of the appliance may result in injury when lifted. Do not lift the appliance on your own. ▶ If this appliance is not correctly installed in a washer-dryer stack, the installed appliance may fall. Only stack the dryer on a washing machine using the connec- ▶...
-
Page 7: Safe Use
Safety en Wear protective gloves when installing and transporting the ap- ▶ pliance. 1.5 Safe use WARNING ‒ Risk of electric shock! If the appliance or the power cord is damaged, this is dangerous. Never operate a damaged appliance. ▶ Never pull on the power cord to unplug the appliance. Always ▶... - Page 8 en Safety WARNING ‒ Risk of poisoning! Detergents and care products may result in poisoning if con- sumed. If accidentally swallowed, seek medical advice. ▶ Keep detergents and care products out of the reach of children. ▶ WARNING ‒ Risk of explosion! Laundry that has been pretreated with cleaning agents that con- tain solvents may cause an explosion in the appliance.
-
Page 9: Safe Cleaning And Maintenance
Safety en 1.6 Safe cleaning and maintenance Take note of the safety instructions when cleaning and performing maintenance work on the appliance. WARNING ‒ Risk of electric shock! Incorrect repairs are dangerous. Repairs to the appliance should only be carried out by trained ▶ specialist staff. -
Page 10: Preventing Material Damage
en Preventing material damage Make sure that the length of the ▶ 2 Preventing material thread on the connection to the water tap is at least 10 mm. damage If the water pressure is too high or too low, the appliance may not be Follow these instructions to avoid ma- able to operate properly. -
Page 11: Environmental Protection And Saving Energy
Environmental protection and saving energy en Remove all detergent residue, Set the maximum spin speed if you ▶ spray residue or other residues im- want to dry the laundry in the tumble mediately if they come into contact dryer afterwards. with the appliance. a The drier the laundry, the shorter the programme duration when dry- ing which, in turn, reduces energy... -
Page 12: Contents Of Package
en Installation and connection Remove any packaging and pro- Water inlet hose ¡ tective covers completely from the → "Connecting the water inlet appliance. hose", Page 14 → "Disposing of packaging", 4.3 Requirements for the in- Page 11 stallation location Check the appliance for visible damage. Open the appliance door. -
Page 13: Removing The Transit Bolts
Installation and connection en Unscrew and remove Installation loca- Requirements screws for the 4 transit bolts with a tion WAF 13 wrench. Kitchen unit Only install the appliance under- neath a continu- ous worktop that is securely con- nected to adja- cent cabinets. -
Page 14: Connecting The Appliance
en Installation and connection Put on the 4 cover caps. Connect the water inlet hose to a tap (26.4 mm = 3/4"). Press down on the 4 cover caps. Open the water tap carefully and check that the connection points are tight. Water outlet connection types This information is intended to help you to connect this appliance to the water outlet. -
Page 15: Aligning The Appliance
Installation and connection en Screw the lock nuts tightly against Plastic pipe with Fix and secure the housing using a WAF 17 rubber sleeve or the water outlet wrench. gully hose with an el- → Page 27. 4.6 Aligning the appliance In order to reduce noise and vibra- tion and to prevent the appliance from moving, align the appliance cor- In doing so, hold the foot tight and... - Page 16 en Familiarising yourself with your appliance 5 Familiarising yourself with your appliance 5.1 Appliance You can find an overview of the parts of your appliance here. On certain models, specific details such as the colour and shape may differ from those pictured. Maintenance flap for the drain pump → Page 31 Door Detergent drawer → Page 17...
-
Page 17: Detergent Drawer
Familiarising yourself with your appliance en 5.2 Detergent drawer Compartment II: Detergent for main wash ¡ Water softener ¡ Bleach ¡ Stain remover ¡ Compartment Fabric softener ¡ Liquid starch ¡ Waterproofing agent ¡ Compartment I: Detergent for prewash ¡ Hygiene detergent ¡... -
Page 18: Before Using For The First Time
en first time Pour standard washing powder first time 6 Before using for the into compartment II. first time Prepare the appliance for use. first time 6.1 Starting an empty wash- ing cycle Your appliance was inspected thor- oughly before leaving the factory. To remove any residual water, run the first wash cycle without any laundry. -
Page 19: Display
Display en 7 Display The display shows the current settings, options or relevant information. Example: Display display Designation More information 0:40 Programme dura- Approximate expected programme dura- tion/programme tion or programme time remaining. time remaining "Ready in" time → "Buttons", Page 21 9,0 kg Recommended The maximum load capacity for the selec- load... - Page 20 en Display display Designation More information Adding laundry μούλιασμα πρόπλυση is activated and the soaking has finished. The programme pauses for 15 minutes. You can add more laundry within this 15-minute window. Options: Add laundry and press to start the ¡ programme immediately.
- Page 21 Buttons en 8 Buttons The selection of programme settings depends on the programme that is set. You can see the selection options for each programme in the overview for → "Programmes", Page 23. Button Selection More information (Start / Reload) Start Start, cancel or pause the pro- ¡...
- Page 22 en Buttons Button Selection More information μούλιασμα (Prewash) Selecting activates the Prewash ¡ πρόπλυση (Pre- programme. (Soaking) ¡ treatment) Prewash for washing heavily soiled laundry. Selecting activates the Soaking programme. Before the main wash cycle starts, the laundry remains in the water for longer.
- Page 23 Programmes en 9 Programmes Note: The laundry's care labels provide you with additional information on pro- gramme selection. Programme Description Max. load (kg) Βαμβακερά Wash hard-wearing items made from cotton, linen (Cotton) or blended fabrics. Also suitable as a short programme for normally soiled laundry when you activate extra γρήγορο.
- Page 24 en Programmes Programme Description Max. load (kg) Max. 1400 rpm ¡ Ευπαθή/ Wash delicate, washable items made from silk, vis- Μεταξωτά cose and synthetic fabrics. (Delicate/Silk) Use a detergent that is suitable for delicates or silk. Note: Wash especially delicate items or items with hooks, eyelets or clips in a mesh laundry bag.
- Page 25 Programmes en Programme Description Max. load (kg) Programme setting: Max. 60 °C ¡ Max. 800 rpm ¡ Αδιάβροχα Wash all-weather and outdoor clothing with mem- υφάσματα brane technology and water-resistant equipment. (Outdoor) Use a detergent for outdoor fabrics. Do not use fabric softener. Programme setting: Max.
- Page 26 en Programmes Programme Description Max. load (kg) Programme setting: Max. 40 °C ¡ Max. 1000 rpm ¡ extra γρήγορο activated...
-
Page 27: Accessories
QR code in the table of contents or on www.pitsos.gr. – Remove curtain hooks and lead strips or use a mesh laundry 11.1 Preparing the laundry –... -
Page 28: Detergents And Care
Notes ted. More detailed instructions for use ¡ → "Installation and connection", can be found on www.pitsos.gr or Page 11 by scanning the QR code on the title page of this user manual. Turn the programme selector to a ▶... -
Page 29: Adding Detergent And Care Product
operation en Open the appliance door. 13.5 Adding detergent and The appliance door remains care product locked for safety reasons if the Note: Observe the information about temperature and water levels are detergents and care products high. → Page 28. – If the temperature is high, start the Ξέβγαλμα... -
Page 30: Childproof Lock
QR code in the table of Press and hold the two 3 δευτ. ▶ contents or on www.pitsos.gr. buttons for approx. 3 seconds. The display shows 16.1 Cleaning the drum The controls are locked. -
Page 31: Cleaning The Drain Pump
Cleaning and servicing en Press down on the insert and re- Fit the insert and click it into place. move the detergent drawer. Clean the opening for the deter- Pull out the insert upwards. gent drawer. Clean the detergent drawer and in- Push in the detergent drawer. - Page 32 en Cleaning and servicing Open and remove the service flap. CAUTION - Risk of scalding! When you wash at high temperat- ures, the detergent solution gets hot. Do not touch the hot detergent ▶ solution. To allow the detergent solution to flow out into the container, remove the sealing cap.
- Page 33 Cleaning and servicing en Insert the pump cap. Cleaning the drain pump Ensure that the parts of the Requirement: The drain pump is ‒ pump cap are correctly as- empty. → Page 31 sembled. Since water may remain in the drain pump, unscrew the pump cap carefully.
- Page 34 en Cleaning and servicing Before the next wash To prevent unused detergent from flowing straight into the outlet in the next wash, run the Άντληση pro- gramme after you have emptied the drain pump. Turn on the water tap. Insert the mains plug. Switch on the appliance.
-
Page 35: Troubleshooting
Troubleshooting en 17 Troubleshooting You can rectify minor faults on your appliance yourself. Read the troubleshoot- ing information before contacting after-sales service. This will avoid unneces- sary costs. WARNING Risk of electric shock! Incorrect repairs are dangerous. Repairs to the appliance should only be carried out by trained specialist ▶... - Page 36 en Troubleshooting Fault Cause and troubleshooting "E:30 / -80" Remove any unapproved extensions from the water ▶ hose. → "Connecting the appliance", Page 14 The pump cap is not fully screwed in. Ensure that the pump cap is screwed in all the way ▶...
- Page 37 Troubleshooting en Fault Cause and troubleshooting flashes. Voltage under-usage may cause extension of a pro- gramme. No remedial action possible. lights up. The temperature is too high. Wait until the temperature has dropped. ▶ → "Cancelling the programme", Page 29 ▶ Water level is too high. Select a suitable programme for draining.
- Page 38 en Troubleshooting Fault Cause and troubleshooting The programme does Close the door. not start. Press to start the programme. Childproof lock is activated. → "Deactivating the childproof lock", Page 30 ▶ λήξη σε is activated. Check whether λήξη σε is activated. ▶ → "Buttons", Page 21 Laundry is caught in the door.
- Page 39 Troubleshooting en Fault Cause and troubleshooting The water is not drain- Reduce the amount of detergent for the next wash- ▶ ing. ing cycle with the same load. Unapproved extension installed on the water drain hose. Remove any unapproved extensions from the water ▶...
- Page 40 en Troubleshooting Fault Cause and troubleshooting No water is visible in Water is below the visible area. the drum. Not a fault – no action required. ▶ Do not add any extra water to the appliance while it ▶ is operating. Drum jerks after the This is caused by an internal motor test.
- Page 41 Troubleshooting en Fault Cause and troubleshooting The spin programme Ensure that the drain pipe and water drain hose are ▶ does not start. not kinked or trapped. The unbalanced load detection system has interrupted the spin cycle because the laundry is unevenly distrib- uted.
- Page 42 en Troubleshooting Fault Cause and troubleshooting The spin result is not A low spin speed is selected. satisfactory. The laun- The next time you run a wash cycle, set a higher ▶ dry is too wet/too spin speed. damp. Start the Στύψιμο programme. ▶...
- Page 43 Troubleshooting en Fault Cause and troubleshooting Odours have formed Humidity and detergent residue may promote the in the appliance. formation of bacteria. → "Cleaning the drum", Page 30 ▶ If you are not using the appliance, leave the door ▶ and detergent drawer open so that residual water can evaporate.
-
Page 44: Emergency Release
→ "Before using for the first time", Note: You can find further information Page 18. in the digital instruction manual by scanning the QR code in the table of contents or on www.pitsos.gr. Turn off the tap. Empty the water inlet hose. Switch off the appliance. -
Page 45: Disposing Of Old Appliance
Customer Service en 18.4 Disposing of old appli- 19 Customer Service ance If you have any queries on use, are Valuable raw materials can be re- unable to rectify faults on the appli- used by recycling. ance yourself or if your appliance needs to be repaired, contact Cus- WARNING tomer Service. - Page 46 en Customer Service Make a note of your appliance's de- tails and the Customer Service tele- phone number to find them again quickly.
-
Page 47: Consumption Values
Consumption values en 20 Consumption values The following information is provided in accordance with the EU Ecodesign Regulation. The values given for programs other than the Eco 40-60 are indicat- ive only and were determined in accordance with the applicable standard EN60456. Programme Load Pro-... - Page 48 en Technical data Minimum in- stallation protec- tion Nominal power 2300 W Power consump- Off mode: ¡ tion 0,15 W Left-on mode: ¡ 0,50 W Water pressure Minimum: ¡ 100 kPa (1 bar) Maximum: ¡ 1000 kPa (10 bar) Length of the wa- 150 cm ter inlet hose Length of the wa- 150 cm ter outlet hose...
- Page 52 9001709503 *9001709503* 020126...
