1. Stud 1/2in. scan: Locates the center and edges of wood and metal studs
up to 1/2 in.(13mm) deep
2. Stud 1 in. scan: Locates the center and edges of wood and metal studs
up to 1in. (25 mm) deep
3. Stud 1 1/2 in. scan: Locates the center and edges of wood and metal
studs up to 1 1/2 in. (38 mm) deep
4. Metal Scan: Detects metal up to 2.36 in. (60 mm) deep
5. AC Scan: Detects live unshielded AC wires up to 2 in. (50mm) deep
Advertisement
Related Manuals for Benchmark 1010-501
Summary of Contents for Benchmark 1010-501
- Page 1 1. Stud 1/2in. scan: Locates the center and edges of wood and metal studs up to 1/2 in.(13mm) deep 2. Stud 1 in. scan: Locates the center and edges of wood and metal studs up to 1in. (25 mm) deep 3.
- Page 2 11. Depending on the proximity of electrical wiring or pipes to the wall surface, The Multi-Purpose Stud Finder cannot be used as a depth gauge. The the scanner may detect them in the same manner as studs. Caution should detector will not detect water or gas pipes shielded by metal materials; it may always be used when nailing, cutting, or drilling in walls, floors, and ceilings detect them in the same manner as metal only.
- Page 3 WARNING: FINDING A STUD DO not rely exclusively on the detector to locate items behind the scanned surface. Use other information sources to help locate items before penetrating Always scan with the scanner placed flat against the wall. the surface. Such additional sources include construction plans, visible points ...
- Page 4 AC WIRE WARNING 2. (Figure A) While holding the Scan button, press the tool flat against the wall The AC WARNING detection feature works continuously in Stud 1/2 in., Stud and slowly slide the scanner across the surface. Mark the point where you get 1 in.
- Page 5 If this Benchmark tool fails due to a defect in material or workmanship within five the centerline or audio tone. In this case, use the highest indication to years from the date of purchase, return it to any Home Hardware store with the determine the metal position.
