Introduction Instruction Manual This manual is intended as a reference guide for operating and correctly installing the Simrad FU50 Follow-up Steering Lever. Please take time to read the manual to get a thorough understanding of the follow-up steering lever and its relationship to a complete autopilot system.
Page 4
Simrad FU50 Follow-up Steering Lever Document revisions Date Written by Checked by Approved by 11.06.02 27.09.02 Document history Rev. A Original issue Rev. B Updated to FU50 software version V1R2 20221065B...
General Information GENERAL INFORMATION The FU50 Follow-up steering lever features a dial (scale), with 5° markings. This enables the operator to command a wanted rudder angle by moving the follow-up lever/knob to the required rudder angle in FU mode. The rudder will move and stop at the set angle.
Simrad FU50 Steering Lever OPERATION When operating an autopilot system of multiple control units and steering levers, control is accessible from every control station connected to the system. One station (control unit or FU50) is "active" and provides the user with access to the respective mode functions.
Operation Press the AUTO/NAV to select AUTO mode (AUTO AUTO indicator is lit). The autopilot automatically selects the current boat heading as the set course. NAV mode can not be selected from the FU50. This is a AUTO safety feature to avoid hazardous rudder commands. When NAV mode is selected on an autopilot control unit, the NAV mode indicator on the FU50 is pulsating.
Simrad FU50 Steering Lever For AP50 system only: If a continuous/proportional thruster is selected it will push in the same direction as the rotary knob is turned with a % force between 0 and max (100%). If an On/off thruster is selected, FU steering is activated by...
Operation The only way to change from AUTO mode to (AUTO-) WORK mode and vice versa is on the AP35/AP50 Control Unit or on the AP51 Remote Contol. Nav-, Turn-, Dodge, and Wind Modes If NAV-, TURN-, DODGE, or WIND modes have been selected on the autopilot control unit, it will change to ordinary AUTO mode when the AUTO/NAV button is pressed on FU50.
Simrad FU50 Steering Lever To reopen the locked remote units, you have to take control from the master control unit, and again make a quick STBY double press on the master control unit (STBY) button. System Disengaged The “System select” (Sys. Sel.) input signal of the J50 can be used to alternate between the boat’s own steering and the...
Operation 2.12 Self Test and Calibration Note ! Under normal circumstances, the self-test should not be necessary. Pressing and holding AUTO/NAV push button while switching on by pressing FU/STBY button, will activate the self test function in the following sequence: 1.
Installation INSTALLATION The unit is mounted to bulkhead or panel by three Allen screws (2) from the front. See Figure 4-1. The head of the screws may be covered with the three enclosed caps (1). 1 - Cover for screw head 2 - Screw M6x40 3 - Washer M6 4 - Nut M6...
Simrad FU50 Steering Lever The cable gland can also be mounted in the back cover. The unit is opened by removing the four screws on the back cover. Inside are a potentiometer and a printed circuit board with plug-in terminals. Internal wire connection is shown on Figure 4-3.
Maintenance MAINTENANCE Under normal use, the FU50 Steering Lever will require little maintenance. If the unit requires any form of cleaning, use fresh water and a mild soap solution (not a detergent). It is important to avoid using chemical cleaners and hydrocarbons such as diesel, petrol, etc.
Simrad FU50 Steering Lever SERVICE How to Replace a Defective Potentiometer: Refer to Figure 7-1. 1. Remove the center cover (1) with the o-ring (2) on top of the FU50 Head (7). 2. Loosen the nut (3) a couple of turns. Use a flat screwdriver, min 6, max 10 mm wide.
Spare Parts List SPARE PARTS LIST 20212460 FU50 Follow-up Steering lever with accessories 20212304 FU50 Controller (complete unit without handle and mounting kit) 22083562 Mounting kit consisting of: 44154458 Screw M6x40 Hex 44148823 Washer M6 44150068 Nut M6 44165819 Cover for screw head 20212353 Center cover 44165397...
