The Atom comes shipped in Sleep mode. To
install the Atom, it must first be placed into
Install mode.
To reboot the Atom and place it in Install
mode, hold the button for 8 seconds.
During the first 30 seconds of a reboot, the
operation modes can be changed by pressing
the button 5 times. The device will flash
multiple times to indicate the current mode.
Install mode is indicated by 2 white LED
flashes.
In Install mode, the Bluetooth radio will turn on
more often so a device pairing can be made.
If a connection is made, the unit will
automatically change to Ready mode, and stay
in that state.
If no connections are made 30 minutes after
changing to Install mode, the Atom will go
back to low-power mode to save battery.
Pressing the button once causes the Atom to
wake up and send collected data to its parent
device.
Bluetooth will automatically turn on at set
intervals to transmit collected data to the
parent device.
Atom Quick Start Guide
Atom
LED Color and Flash Patterns
Green Blink - Your Atom is actively collecting
data.
Blue Blink - The Bluetooth radio is on and
waiting for a parent to retrieve its data.
Blue Blink (x2) - Parent device has connected
to the Atom and data is being transferred.
Aqua - Parent device has recently connected in
the past 6 minutes to the Atom, but has not
connected since then. Data continues to
accumulate.
Yellow - Waiting for date & time to be set. The
Atom should transition out of this state after
pairing with a device.
Magenta - Firmware update is in progress.
White - Operational mode indicator.
Operational Modes
Low-Power - 3 White flashes.
Install - 2 White flashes.
Ready - 1 White flash.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for PMI Atom
Summary of Contents for PMI Atom
- Page 1 Atom Quick Start Guide Atom LED Color and Flash Patterns The Atom comes shipped in Sleep mode. To Green Blink - Your Atom is actively collecting install the Atom, it must first be placed into data. Install mode. Blue Blink - The Bluetooth radio is on and To reboot the Atom and place it in Install waiting for a parent to retrieve its data. mode, hold the button for 8 seconds. Blue Blink (x2) - Parent device has connected During the first 30 seconds of a reboot, the to the Atom and data is being transferred. operation modes can be changed by pressing the button 5 times. The device will flash Aqua - Parent device has recently connected in multiple times to indicate the current mode. the past 6 minutes to the Atom, but has not Install mode is indicated by 2 white LED connected since then. Data continues to flashes. accumulate. In Install mode, the Bluetooth radio will turn on more often so a device pairing can be made. Yellow - Waiting for date & time to be set. The Atom should transition out of this state after If a connection is made, the unit will pairing with a device. automatically change to Ready mode, and stay in that state. Magenta - Firmware update is in progress. If no connections are made 30 minutes after White - Operational mode indicator. changing to Install mode, the Atom will go back to low-power mode to save battery. ...
- Page 2 PQ Canvass Atom iOS App ● Log in to pqcanvass.powermonitors.com ● Log into the iOS application with your PQ Canvass username and password. ● Click devices icon in the bottom dock. Make sure Bluetooth is on. You can verify ● ● Select the Tensor to pair with. this by going to Settings > Bluetooth and making sure the toggle is ON. ● Select Actions, then Atom Discovery. ● You will see the Bluetooth scanner ● Nearby Atoms will show up. animating in the top left-hand corner of the app, indicating that it is scanning for nearby Atoms. ● Atoms that are in range will turn blue and ● If the Atom does not appear, tap the button display their RSSI in dBm. Atoms only on the Atom to place it in pairing mode. wake up every few minutes, so they may not appear quickly ● Click the associate icon . ...
