  • Page 1 m680 Moto Cam User Manual...
  • Page 2 This product is designed with waterproof. However, it is forbidden to use a strong jet of water to rinse or flush the product. The warranty will be invalid if the damage is caused by this reason. Use the attached power cable and wires for installation only. Please do not use other brand of power cable or wires to avoid equipment burn or explosion.

  • Page 3: Table Of Contents

    Contents About this Guide ......................... 3 Regulatory Notice ......................3 Notes on Installation ......................3 Introduction ....................6 Feature ........................6 Package Contents ....................6 Product Overview....................7 Getting Started ..................... 9 Setting Go Moto Plus App ................... 10 Download and Install ................10 1.5.1 1.5.2 Wi-Fi Connection ..................

  • Page 4: About This Guide

    About this Guide The content in this document is for information purpose and is subject to change without prior notice. We have made every effort to ensure that this User Guide is accurate and complete. However, no liability is assumed for any errors or omissions that may have occurred. The manufacturer reserves the right to change the technical specifications or accessories without prior notice.
  • Page 5 4. Use the attached power cable and wires for installation only. Please do not use other brand of power cable or wires to avoid equipment burn or explosion. 5. Please seek for professional shops and technicians for installation. 6. Keep the installation space of the host clean and tidy, and avoid sharp objects or heavy objects crushing the screen or other cables.
  • Page 6 Explosion Area or in a zone with a “Switch Off 2-way Radios” sign by switching off camcorders that may interfere with the radio frequency. HP Inc. is NOT responsible for the loss of any data/content during operation.  When you start using the system, it is assumed that you agree to the...

  • Page 7: Introduction

    1 Introduction Thank you for purchasing this advanced Moto Cam. This product is specifically designed for real time video recording when riding scooter. 1.1 Feature  Dual waterproof camera, super high resolution  2MP Sony Starvis sensor  2” Color LCD ...

  • Page 8: Product Overview

    1.3 Product Overview 1.3.1 Host Item Item Reset White: to connect Remote Control microSD slot Black: to connect front camera 5in1 connector MENU/Return button Red: to connect power cable Up/Switch Cam button USB-A: to connect power bank to Down/Add Speed Cam button activate parking mode Green: to connect GPS OK/HUD button...
  • Page 9 1.3.2 Remote Control Item Function -LED solid: power on (standby) -LED flash one sec one time: in recording LED indicator -LED flash rapidly: emergency record / speed cam alert. *Note -LED flash slowly: front or rear cam abnormal working Beep 1 time: start recording / manually emergency recording Beep 3 times: speed cam alert *Note Buzzer Beep 5 times: card error or not insert card...

  • Page 10: Getting Started

    1.4 Getting Started 1.4.1 Insert the Memory Card Insert memory card with the gold pins facing forward, and the display of the host is toward up, see the picture as below, 1.4.2 Remove the Memory Card Turn off the scooter’s engine, and the camera will power off accordingly. Once the camera is completely powered off, you can remove the memory card from memory slot.

  • Page 11: Setting Go Moto Plus App

    1.5 Setting Go Moto Plus App 1.5.1 Download and Install The camcorder allows you to connect to the smart phone via the app. When using for the first time, install the [Go Moto Plus] app for your smart phone. 1. Scan below QR code or download Go Moto Plus app from Google Play or App Store. 2.

  • Page 12: Wi-Fi Connection

    1.5.2 Wi-Fi Connection 1. When the host is power on, Wi-Fi will be valid for 3 minutes. 2. The host screen will display Wi-Fi Device ID and Password. Using the Wi-Fi function of your smart phone, search for the camcorder ID “hp_m680_xxxxxx” from the list (last 6 numbers are system random numbers).

  • Page 13: Installation

    2 Installation Below installation is for reference only. Please contact professional shops and technician for installation. 2.1 Connect Host and Accessories Connect host with power cable, front camera, rear camera, GPS and Remote Control according to connector’s colors. Note: 1. The power installation can be assembled by ACC cable or USB cable. 2.

  • Page 14: Installation Position

    2.2 Installation Position Item Installation position To be fixed on scooter’s head or the central of front case. Or Front camera use rear-view-mirror mount and fix it on the scooter’s rear- view-mirror. Remote control To be fixed on the front handle. To be fixed on a good reception of front handle.

  • Page 15: Power Cable

    2.3 Power Cable Riding Mode: Choose either power ACC cable or power USB cable for installation. When installation is completed, the host will power on and automatically start recording once the engine starts. When the engine shuts down, the host will be powered off. Some of motorcycles still supply power to USB port after engine is turned off, and the host keeps recording.

  • Page 16: Install Power Acc Cable

    2.3.1 Install Power ACC Cable Plug the red terminal of power ACC cable into red terminal of the host. See the rendering as below. The other end of ACC wire must connected with ACC gate of motorcycle. DO NOT connect with the battery directly. This installation is required professional skill and highly suggested to do so through the technician in the shop.

  • Page 17: Install Power Usb Cable

    2.3.2 Install Power USB Cable Plug the red terminal of power USB cable into red terminal of the host. The other end of USB connector plugs into USB port of motorcycle. NOTE: Some of motorcycles still supply power to USB port after engine is turned off, and the host keeps recording.

  • Page 18: Install Front Cam On Rear-View Mirror

    2.4 Install Front Cam on Rear-View Mirror The front camera(with black terminal) can be assembled on the front shell or the handle of motorcycle. Use “rear-view mirror mount”, it can be assembled on the rear-view mirror bar, too. Suggest mounting it on the right side of rear-view mirror bar. Dissemble the original mount from the camera.
  • Page 19 Insert A of the Mount in the middle of metal ring, and confirm the white mark on camera is always positioned up. This is to make sure the capture image is in correct angle. Use screw driver to fix to the Mount. Take out the rear-view-mirror from the motorcycle.

  • Page 20: Install The Host On Rear-View Mirror

    It’s highly recommended to install the Rear-view-mirror Mount on the right side of the motorcycle. If install in the left side, below image for reference. 2.5 Install the Host on Rear-View Mirror The host can be assembled inside the cabinet. Use “light shield mount”, it can be assembled on the rear-view mirror bar, too.
  • Page 21 Assemble the rear-view mirror back to the handle. Use hexagon spanner to loose the screw in the central of light shield mount. The screw will be rose, but it won’t be dropped out. Use hands to pull out the clickers on two sides.
  • Page 22 Insert the memory card into the host. Put the host in the light shield mount. Close the mount until a “click” sound heard. Screw the mount tightly. Generate the wires. Starts the engine. After the host turns on, use adjustable mount and Z type mount to adjust the screen position.

  • Page 23: Adjust View Angle

    2.6 Adjust View Angle Use screen or Go Moto Plus app to preview and adjust the view angle. 2.7 Calibration and Format After adjusting your viewing angle, tap in the Go Moto Plus app to enter “Camera Setting”. On first use, be sure to calibrate “Tilt Sensor” and “Format” microSD card. Calibrate the Tilt Sensor: Hold your motorcycle upright, straight and still as possible, then tap on “Tilt Sensor”...

  • Page 24: Use Moto Cam

    3 Use Moto Cam 3.1 Recording In the normal recording mode, the LED on remote control will flash slowly. The recorded files will be saved in the “Video” folder. If the LED flashes rapidly, it is in emergency recording mode. The recorded files will be saved in the “Emergency” folder.
  • Page 25 Icon Item Description settings. Switch Camera Switch front and rear cam preview Button image. Add Speed Cam In recording mode, press this button to Button manually add speed cam. In recording mode, press this button to HUD button enter HUD mode. GPS status Voice Record Voice record is off.
  • Page 26 3.3 Emergency Recording There are two ways to activate emergency recordings. 1. Automatically After calibration is done, turn on the “Emergency Recording” option from Settings. If an accident happens and the motorcycle is toppled over, the host will trigger emergency recording. The screen will keep flashing yellow and white triangle warning icon.
  • Page 27 3.4 Speed Cam Alert If the Speed Cam Alert function is enabled, once your location is determined by GPS and approaches a speed cam, the remote control produces audible alert and the host will pop-up screen message. To enable the Speed Cam Alert, do the following: 1.
  • Page 28 3.5 Add Speed Cam Point You may customize speed cam positions in this product. 1. When the GPS positioning is completed , press to update speed camera points. 2. This product features a capacity of 50 speed cam positions. In case you are trying to add more than that the system prompts with message "Speed Position is full".
  • Page 29 [Disable] When the engine starts again, the screen will show “Start Normal Recording”. The host will stop parking mode, and resume to normal recording and stop obtaining power from this external power bank. [Re-enter] When the engine shuts down again, the screen will show “Enter parking mode after 10 sec.”...
  • Page 30 3.7 Playback Video and Photo To playback the file, perform the following steps, Press button to stop recording and enter menu settings. Press button to select Playback, and press button to enter. button to select Video / Emergency / Picture, and press Press button to enter.
  • Page 31 3.9 HUD The HUD function can check current riding speed, date/time and heading direction. The HUD mode won’t disturb the recording, nor the speed cam alert. There are two ways to enter HUD mode. 1. Manually In the preview screen, press button to enter.

  • Page 32: Use Go Moto Plus App

    4. Use Go Moto Plus App Tap [Go Moto Plus] icon to activate the application. The main screen will pop up. Follow the below instruction to operate this application.
  • Page 33 4.1 Camera preview, record, snapshot You can use this feature to preview, record or take snapshot. icon Description Go Moto Plus logo / memory card message Preview Switch front and rear camcorder preview Full screen display...
  • Page 34 Start/Stop Record Snapshot Camera File. Recorded files in microSD card. Camera Setting Note: The emergency videos folder in microSD reaches capacity, and will be overwritten by new recordings. Please back up important files. This message icon will eliminate after backup. Map and riding track Note: 1.
  • Page 35 4.2 Playback, delete, download You can use this feature to playback or delete the file saved in camcorder, or to download the file from camcorder to your mobile device. 1. Touch the icon [Camera File]. 2. The files saved in the camcorder will be displayed on your smart phone. Camcorder will stop recording for a few seconds until your smart phone finishes reading the saved files from camcorder.
  • Page 36 3. Tap the right top corner “Select” and pick up the files that you want to delete or download and tap below icon to execute. Icon Description Download the file to smartphone. Delete file from microSD card. Downloaded file will mark as “Downloaded” on preview thumbnail.
  • Page 37 4.3 Local Album You can use this feature to playback or delete the file that you download in your smart phone. The file can be opened and reviewed without Wi-Fi connection to the camera. Tap the icon [Album] below the home page. The camera will stop recording if it’s connected with app.
  • Page 38 Tap the file from preview thumbnail to playback, delete or edit. Icon Description Edit the video or photo. (refer to next step for details.) Share the video or photo to social media. Video screenshot. Save the video or photo to smartphone’s album. When the file is saved, the screen will show a message of “Save to smartphone's album successfully.”...
  • Page 39 4.4 Edit Video or Picture Open the downloaded file in “Album”, then, tap Edit icon. The video or picture can be edited. Edit video: Remove original audio/voice, and embed favorite music from the recommendations. Edit picture: Crop the picture, or change the color of picture from recommendations.
  • Page 40 4.5 Camera Setting You can use this feature to set up your car camcorder. Tap icon [Camera Setting]. Refer to the below table for details of menu items and available menu options. Menu Option Description Available options To set up time zone in order to auto sync date/time Set Time Zone GMT -12 ~ GMT +12 once GPS is positioned.
  • Page 41 Rear Cam Set up Exposure Value of rear camera. +3, +2, +1, 0, -1, -2, -3 EV Setting Set LCD off time or HUD mode. On/ Turn off after 7 sec / *Recording is not affected when screen is in HUD mode. LCD Setting Turn off after 1min / HUD *Recording is not affected when screen is off.

  • Page 42: Specification

    5. Specification Item Description Image sensor Sony Starvis Sensor Effective pixels 1920 (H) x 1080 (V) 2” Color Displayer Displayer Supports microSD 16GB above and class V30 speed or greate Storage media Wide Angle Fixed Focus lens Lens Aperture: F/1.8 Focus range 1.5m~Infinity Satellite System...
  • Page 43 Operating Humidity 20 ~ 70% RH Storage Temperature -20° ~ 70° C Host Dimensions 80 x 50 x 22 mm Host Weight Approx. 148g Built-in IEEE 802.11g/n(HT20) Wi-Fi chip: RTL8188FTV Frequency range 2412~2462MHz Wi-Fi Channel Ch1~Ch11...
