  • Page 1 YUKI SYSTEM ASSEMBLY MANUAL v1.0 | February 2024...

  • Page 2: Table Of Contents

    Information is supplied upon the condition that the persons receiving the information will make their own determination as to its suitability for their purposes prior to use. Rollease Acmeda assumes no liability whatsoever for any damages incurred by you resulting from errors in or omissions from the information included herein.

  • Page 3: Section 1 | Warranty

    SECTION 1 | WARRANTY WARRANTY Rollease Acmeda provide a 5 year hardware warranty against defects to the original purchaser [the fabricator/manufacturer]. The hardware warranty is not to be transferred to the end consumer. The hardware warranty is limited to the repair or resupply of defective hardware components to the fabricator/manufacturer only.

  • Page 4: Section 2 | Guidelines

    To ensure the correct assembly of the entire system and for optimum operation of the finished product, it is necessary to be in possession of the following: • Awning assembly frame for testing & adjustment. • Complete set of tools. Page. 4 YUKI | Assembly Manual | v1.0 | February 2024 ©Copyright All Rights Reserved Rollease Acmeda...

  • Page 5: Section 3 | System Details

    7. Arms (x2) 8. Terminal Bar Connectors (x2) 9. Convoyer 10. Plate with Pin 11. Cap with Hole 12. Motor with Crown and Drive Page. 5 YUKI | Assembly Manual | v1.0 | February 2024 ©Copyright All Rights Reserved Rollease Acmeda...

  • Page 6: Section 4 | Specifications

    Minimum Width (cm) NOTE: Add 20cm to minimum width when attaching a Motion Sensor. SYSTEM WEIGHT CHART (KG) WIDTH (cm) FABRIC EXCLUDED Page. 6 YUKI | Assembly Manual | v1.0 | February 2024 ©Copyright All Rights Reserved Rollease Acmeda YUKI v1.01...
  • Page 7 Projection: 3.09m AWNING DIMENSIONS WITH ARMS FOLDED WALL MOUNTING ROOF MOUNTING 3⁰ incline 11⁰ incline 250mm 197mm 70⁰ incline 90⁰ incline 215mm 133mm Page. 7 YUKI | Assembly Manual | v1.0 | February 2024 ©Copyright All Rights Reserved Rollease Acmeda...

  • Page 8: Section 5 | Awning Assembly

    Before starting, extrusion lengths must be cut to size as per BOM deductions. Please read manual instructions carefully before assembly. The following tools must be used to assemble the YUKI awning: Allen keys: 3, 4, 5, 6, 10 Combination spanner: 10...
  • Page 9 The roller tube must be inserted with the rolling direction facing upwards. STEP 5 - PREPARE THE END BRACKETS Insert the caps on the end plates Page. 9 YUKI | Assembly Manual | v1.0 | February 2024 ©Copyright All Rights Reserved Rollease Acmeda...
  • Page 10 Use straps to assist in keeping arms secure. NOTE Arm End Do NOT over tighten the terminal bar connector in the arm socket. Page. 10 YUKI | Assembly Manual | v1.0 | February 2024 ©Copyright All Rights Reserved Rollease Acmeda...
  • Page 11 Mount the supports vertically. (Q) in the hole provided using Allen key 10mm. The square nut is inserted in the slot from the top (R). Page. 11 YUKI | Assembly Manual | v1.0 | February 2024 ©Copyright All Rights Reserved Rollease Acmeda...
  • Page 12 Assemble the terminal bar inserting the fabric into the relevant ogive. Sliding the terminal bar check that the 2 plates of the terminal bar connectors are properly To ensure correct operation of the YUKI awning, the positioned. terminal bar connector must be located correctly.
  • Page 13 • Complete 2-3 test cycles of opening/closing the awning. • Adjust any components that prevent the correct and unimpeded opening and closing movement of the awning. Page. 13 YUKI | Assembly Manual | v1.0 | February 2024 ©Copyright All Rights Reserved Rollease Acmeda...

  • Page 14: Section 6 | Adjusting The Awning

    If they are not parallel, tighten or slacken the dowel (C) in the lever using Allen wrench 3. Always support the weight of the arms and terminal bar when adjusting the arms. Page. 14 YUKI | Assembly Manual | v1.0 | February 2024 ©Copyright All Rights Reserved Rollease Acmeda...

  • Page 15: Section 7 | Removing And Packing The Awning

    During packing it is necessary to pay particular attention to the delicate parts of the awning (for example, the heads); these must be well protected with good packaging. Page. 15 YUKI | Assembly Manual | v1.0 | February 2024 ©Copyright All Rights Reserved Rollease Acmeda...
