Wall mounted gas condensing boiler

Advertisement

Quick Links

CN-
Operating instructions
EN
WALL MOUNTED GAS CONDENSING BOILER
CGB-2-75/100
English | subject to modifications!
8616725_202108_Englishmater

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CGB-2-75 and is the answer not in the manual?

Questions and answers

Summary of Contents for Wolf CGB-2-75

  • Page 1 Operating instructions WALL MOUNTED GAS CONDENSING BOILER CGB-2-75/100 English | subject to modifications! 8616725_202108_Englishmater...
  • Page 2 注意事项 错误安装将对人、畜和财产造成损害; 请严格按照沃乐夫制造工厂的说明书及相应的国家及地方技术标准来进行安装和调试; 只有持有电工和燃气专业操作证书的授权经销商和安装商,才能存储 / 更换锅炉零件或者整个锅炉; 为保证安全标准的贯彻,请使用原厂配件; 请用沃乐夫原厂提供的烟道系统设计和配件,禁止随意更改,严格禁止将双烟道系统改为单烟道系统; 对燃气压力控制器和燃气控制进行的专业维护维修,必须由燃气专业公司或者设备制造厂家进行; 为确保安全,请在安装商处购买原厂锅炉,请勿在经销商处购买经过非授权更改过的锅炉; 应在锅炉前的燃气管道上的明显位置安装燃气截止阀; 请勿将锅炉安装在具有强电磁辐射的电器周围,如电磁炉、微波炉等等; 10 禁止拆除锅炉上的任何密封件; 11 不能使用带有腐蚀性的清洁剂来清洁锅炉; 12 禁止将锅炉安装在卧房、起居室和浴室; 13 禁止儿童和无行为能力者操作锅炉,禁止将锅炉当成玩具给儿童玩耍; 14 禁止用户独自操作供暖安全阀和供暖热水排水阀;只有专业的技术人员方可操作; 15 请勿将锅炉安装在隐蔽的位置; 16 负责维护和检查的人员在对锅炉进行维护检查后应在维护和检查结果上进行标注并留档; 17 室内的配电系统应安装地线;请勿将与锅炉相连的开关安装在带有浴缸或淋浴设备的房间;使用的插头和插座应通过中国相 关部门的认证; 18 防冻保护:锅炉安装位置的周围温度需高于 +5 度并且具有防雨保护设施; 19 用户需注意,在冬季长期停机期间,必须彻底排空锅炉内采暖和热水系统中的水,此外禁止在锅炉采暖水中加入防冻液; 20 采暖循环的水质必须满足安装手册中对水质的相关要求; 21 补水时需要操作人员一直在现场并按《使用说明书》中规定的正常工作压力范围 (1.2-1.8 bar) 内补水,若低于 1.0 bar 请补水 至正常工作压力,补水后立即关掉补水阀;...
  • Page 3: Table Of Contents

    Intended use .............................. 06 Safety measures ............................06 General safety information ......................... 06 Description ..........................08 CGB-2-75 / CGB-2-100 wall mounted gas condensing boiler layout ............08 Positioning or alteration ......................09 Installation site requirements ........................09 4.1.1 Conditions for use ............................09 4.1.2...
  • Page 4: About This Document

    Scope This document contains instructions for the CGB-2-75/100 wall mounted gas condensing boiler. Target group This document is intended for users of the CGB-2-75/100 wall mounted gas condensing boiler. Other applicable documents CGB-2-75/100 maintenance instructions for contractors CGB-2-75/100 operating instructions for contractors Hydraulic system solutions technical guide for contractors The documents for all accessory modules and other accessories also apply where relevant.
  • Page 5: Abbreviations

    About this document KEYWORD Type and source of risk! Explanation of the risk. ► Action to prevent the risk. Abbreviations HLSC High limit safety cut-out eHLSC Electronic high limit safety cut-out BM-2 Programming unit Display module 8616725_202108_Englishmater WOLF GmbH | 05...
  • Page 6: Safety

    Any faults or damage that impact or might impact safety must be remedied immediately by a qualified contractor. ► All faulty components of the heat generator must be replaced with original WOLF spare parts. General safety information...
  • Page 7 Overpressure on the water side! Risk of injury due to high overpressure in the heat generator, expansion vessels and sensors. ► Close all valves. ► Empty the heat generator if necessary. ► Use safety gloves. 8616725_202108_Englishmater WOLF GmbH | 07...
  • Page 8: Description

    Description Description CGB-2-75 / CGB-2-100 wall mounted gas condensing boiler layout Fig. 3.1 Wall mounted gas condensing boiler layout Ventilation air test point 16 Condensate trap Flue gas test point 17 Heating return Flue pipe 18 Heating flow 19 Displacement device...
  • Page 9: Positioning Or Alteration

    Improper alterations to the heat generator or other parts of the heating system. Risk of injury and damage to the system. ► Work must be performed by a contractor. DANGER Improper alterations to the balanced flue lines! Risk of asphyxiation or severe to life-threatening poisoning. ► Work must be performed by a contractor. 8616725_202108_Englishmater WOLF GmbH | 09...
  • Page 10: Maintenance

    ► Clean the casing with a damp cloth and a mild cleaning agent (must not contain chlorine). ► Dry the casing. ► Components in and directly on the heat generator may only be cleaned by a contractor. 10 | WOLF GmbH 8616725_202108_Englishmater...
  • Page 11: Overview Of Activities

    ● Take the heat generator out of service temporarily. ● ● Put the heat generator back into service. ● ● ● Take the heat generator out of service in an emergency. ● ● Take the heat generator out of service permanently. ● 8616725_202108_Englishmater WOLF GmbH | 11...
  • Page 12: Operation

    Operation Operation BM-2 programming unit operating instructions for users AM display module operating instructions for users ► Control the heat generator using the control module. 12 | WOLF GmbH 8616725_202108_Englishmater...
  • Page 13: Maintenance

    24 hours. For instance, the pump and the 3-VW shall operate 60 seconds after every 24 hours. CGB-2-75/100 wall mounted gas condensing boiler maintenance instructions for contractors WOLF recommends concluding an inspection and maintenance contract with a contractor.
  • Page 14: Fault

    If fault persists: ► Switch the heat generator off and on again with the ON/OFF switch. ► Press button 4. If fault persists: ► Switch OFF the heat generator at the ON/OFF switch. ► Contact a contractor. 14 | WOLF GmbH 8616725_202108_Englishmater...
  • Page 15: Decommissioning

    ► Switch OFF the heat generator at the ON/OFF switch. ► Notify a contractor. Taking the heat generator out of service permanently CGB-2-75/100 operating instructions for contractors ► The heat generator may only be taken out of service by a contractor. 8616725_202108_Englishmater...
  • Page 16: Recycling And Disposal

    ► Dispose of packaging made of cardboard, recyclable plastics and synthetic filler materials in an environmentally compatible manner through appropriate recycling systems or a recycling centre. ► Please observe the applicable national and local regulations. 16 | WOLF GmbH 8616725_202108_Englishmater...
  • Page 17: Energy Efficient Operation

    Fit your heating system with a weather-compensated heating controller from the WOLF range of accessories. Your contractor will be happy to advise you on optimum settings. – Use the night setback function in conjunction with WOLF control accessories.
  • Page 18: Notizen

    Notizen Notizen 18 | WOLF GmbH 8616725_202108_Englishmater...
  • Page 19 Notizen 8616725_202108_Englishmater WOLF GmbH | 19...
