Technical Specifications (Other Details See Insert) (R600A/R290); Electrical Wiring - Koldbox KXR200 Instruction Manual

Fault Probable Cause
The drip tray is overflowing
The appliance is Loose nut/screw
unusually loud
The appliance has not been installed in a
level or stable position
Technical Specifications (Other details see insert)
Model Voltage
220-240V 50Hz
KXR200
KXF200 220-240V 50Hz

Electrical Wiring

Appliance are supplied with a 3 pin, moulded, BS1363 plug and lead, with a 13 amp fuse as standard. The plug is to be
connected to a suitable mains socket. Appliances are wired as follows:
• Live wire (coloured brown) to terminal marked L
Current Temperature
Range
0.55A
0°C ~ 10°C
0.5A -10°C ~ -22°C
Action
Empty the drip tray (if applicable)
High humidity/ too cold ambient temperature (resite unit)
Check and tighten all nuts and screws
Check installation position and change if necessary
(R600a/R290)
Capacity Dimensions
(liters) W×D×H (mm)
113
113
Weight
(Kg)
595×650×830 41
595×650×830 43
