Conforms to: EN 1494, ASME PALD
Description:
Service jack used to elevate cars and light trucks.
The safety signal word designates the degree or level of hazard seriousness.
dangEr: Indicates an imminently hazardous situation which, if not avoided, will result in death or
serious injury.
Warning: Indicates a potentially hazardous situation which, if not avoided, could result in death or
serious injury.
Caution: Indicates a potentially hazardous situation which, if not avoided, may result in minor or
moderate injury.
Caution: Used without the safety alert symbol indicates a potentially hazardous situation which, if not
avoided, may result in property damage.
Service Jack
Maximum Capacity: For 1505B – 4.5 tonnes (5 Ton)
For 1510B – 9 tonnes (10 Ton)
Explanation of Safety Signal Words
Parts List &
operating instructions for:
Form no. 520770
1505B
1510B
Original Instructions
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for OTC 1505B
Summary of Contents for OTC 1505B
- Page 1 1505B 1510B Original Instructions Service Jack Maximum Capacity: For 1505B – 4.5 tonnes (5 Ton) For 1510B – 9 tonnes (10 Ton) Conforms to: EN 1494, ASME PALD Description: Service jack used to elevate cars and light trucks.
-
Page 2: Safety Precautions
Parts List & operating instructions Safety Precautions Caution: to prevent personal injury and/ or property damage, • Study, understand, and follow all safety precautions and operating instructions before using this service jack. if the operator cannot read instructions, operating instructions and safety precautions must be read and discussed in the operator’s native language. - Page 3 Parts List & operating instructions Form no. 520770 Parts List 34 35...
- Page 4 Parts List & operating instructions Item No. Quantity Description Item No. Quantity Description Front Wheel Washer Steel Ball Snap Ring Steel Ball Grease Nipple Spring Rod Link Copper Washer Bolt Bolt Saddle Steel Ball Snap Ring Ball Seat Spring Spring Screw Bolt Sealing Washer...
-
Page 5: Replacement Kits
Kits include: † no. 520787* and 520788 inspection Rear Wheel Plate Kits include: Inspection Plate The following kits are used on both the 1505B and the 1510B units. Item Item Item No. Qty. Description No. Qty. Description No. Qty. Description no. - Page 6 Parts List & operating instructions Setup assemble the Handle release Knob 1. Loosen the bolt on the handle socket. 2. Insert the handle. 3. Tighten the bolt. Bleed air from the Service Jack Air can accumulate within a hydraulic system during shipment or Control rod after prolonged use.
-
Page 7: Preventive Maintenance
assembly & operating instructions Form no. 520770 Preventive Maintenance Caution: Only qualified operators may install, operate, adjust, maintain, clean, repair, inspect, or transport this service jack. Caution: dirt is the greatest single cause of failure in hydraulic units. Keep the service jack clean and well lubricated to prevent foreign matter from entering the system. if the jack is exposed to rain, snow, sand, or grit, it must be cleaned before it is used. -
Page 8: Troubleshooting Guide
1. Release valve is closed. 1. Open or clean release valve. Jack retracts slowly 1. Cylinder damaged internally. 1. Send jack to OTC authorized service center for repair. 2. Link section is binding. 2. Lubricate link section. Check out an excellent selection of garage accessories on our website.
