Summary of Contents for MTX PS65C-BP
- Page 2 Congratulations on the purchase of your new MTX Audio • Please read and follow these instructions to prevent product. At MTX, we strive to create products that deliver injury and damage to the unit. musical reproduc tion at its best, and we are happy that •...
- Page 3 • ISO 16750-4 Salt Spray Testing - 500 Hours • For Tightening the Bracket Strap to the Base: • IP67 Rated (2) M6-1.0x50mm Stainless Steel Hex Bolts • Mounting Assembly Shock tested to 16G (2) M6 Stainless Steel Serrated Flange Lock Nuts • CEA-2031 Compliant MTX.COM...
- Page 4 1. Choose appropriate bracket clamp, 1.75", 1.85", and 2", bracket is tight. The nut is serrated and will lock in for the application. If using the PS65C-BP with a ProFit or Profile style cage, use optional MUDPFC brackets place. The speaker will not rotate on the bar if it is mounted when these are fully tightened.
- Page 5 7 . Attach the MTX badge to the rear recess of the enclosure with the included double stick tape. Customize the Look If you wish to customize the look of your speaker cans, the grille insert, and speaker spacer ring as highlighted in Figure 3 can be painted to match your vehicle color scheme.
- Page 6 WIRING 1. Connect the pigtail harness to the can. Note: If Color Wiring Options installing as part of an MTX Audio UTV kit, the pigtail Grounded Wire(s) LED Color Output will not be used. Green Green 2. Connect the speaker wires to your amplifier ensuring...
- Page 7 SPECIFICATIONS Power Power Nominal Speaker Sensitivity Frequency Model Handling Handling Impedance Size Type (2.83V/1m) Response (RMS) (Peak) 110Hz - " PS65C-BP Coaxial 85-Watts 170-Watts 90dB 4Ω (165mm) 20kHz DIAGRAMS Speaker Screw Mounting Overall Overall Model Diameter Diameter Height Depth "...
- Page 8 We’re here to help! If you experience an issue with any of our products , please contact our customer service technical line at 1-800-CALL-MTX to help troubleshoot your issue. If after speaking with our technical experts it is determined that your product is defective, the technician will provide you with a Return Authorization number and all relevant details you’ll need to process your claim quickly.
