Azeron Cyborg Manual

Hide thumbs Also See for Cyborg:
Table of Contents

Advertisement

Quick Links

Download this manual
Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Cyborg and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Azeron Cyborg

Summary of Contents for Azeron Cyborg

  • Page 1 Manual...

  • Page 2: Table Of Contents

    PACKAGE CONTENTS ........................ 4 DEVICE LAYOUT ......................... 5 ADJUST YOUR AZERON KEYPAD ..................6 4. INSTALLING SOFTWARE ......................8 HOW TO USE AZERON SOFTWARE ................. 16 5.1. INTERFACE OVERVIEW ....................16 5.2. KEYBIND SETUP ......................17 5.2.1. Keyboard mode ....................18 5.2.2.
  • Page 3 USB chime when connecting ....................48 No USB chime when connecting ..................51 7.2 BUTTON ISSUES ......................53 7.2.1 Button physically stuck ....................53 7.2.2 Not registering any input in PC ................. 53 7.2.3 Ghost clicks (chattering) .................... 54 7.3 THUMBSTICK ISSUES ..................... 55 7.3.1 Xbox 360 mode doesn’t work ...................
  • Page 4 The main advantage of the Azeron keypad is the ability to move in game character with one finger – the thumb (either in 360° mode or in WASD...

  • Page 5: Features

     Omron micro switches  On-board memory for your favorite keybinds PACKAGE CONTENTS  Azeron Cyborg  Azeron Screwdriver for adjustments  2 thumbstick replacement caps  Metal restrictor ring  Spare screws (including one for the little tower)  Braided USB cable (2m / 6ft 7in) ...

  • Page 6: Device Layout

    2. DEVICE LAYOUT Page | 5 | Manual...

  • Page 7: Adjust Your Azeron Keypad

    3. ADJUST YOUR AZERON KEYPAD Page | 6 | Manual...
  • Page 8 By using the included Hex screwdriver, it is possible to adjust key and thumb module positions for your hand. You can swap included thumbstick caps just by pulling them off with a little force: Or if you have chosen the Elite thumbstick, you can swap the magnetic caps easily and adjust the thumbstick tension with the included tool.

  • Page 9: Installing Software

    4. INSTALLING SOFTWARE First you need to check if your computer recognizes Azeron keypad. Plug in USB cable in PC. Go to Start – Control Panel – Devices and Printers, and see if under Devices shows up Azeron keypad. If it doesn’t, and the LED lights are not turning on, make sure the USB cable is connected to the keypad properly.
  • Page 10 We are constantly working on new features and improvements, so make sure to go to our website (https://www.azeron.eu/downloads/) and download the latest Azeron software. When shipping out the keypad to you, it has already pre-installed latest firmware. So you need to install new firmware only if the software asks you to do it.
  • Page 11 After the installation is done, plug in the USB cable of the keypad in PC and then launch the Azeron software. If you are not sure if your PC has the USB3.0 motherboard drivers installed, then we would suggest to use USB 2.0 port to avoid unpredictable behavior of the keypad...
  • Page 12 When opening Azeron software, there are 4 options what could show up: A) When opening software, it may show this screen: It means that the keypad requires firmware update. Click on “Update” at the bottom right corner. There will be a loading animation as it downloads the newest version.
  • Page 13 After firmware installation the keypad will restart. Wait until software connects with your keypad. When the firmware update is complete the software will ask you to calibrate the thumbstick. Follow the directions on screen to complete the calibration. Page | 12 | Manual...
  • Page 14 B) The second possible option when software opens up will look like this: This means that everything is ready, the software and PC recognizes the keypad and everything is up to date. You are ready to configure your keypad to your liking and start gaming. Page | 13 | Manual...
  • Page 15 C) Another option when opening software, it may be empty It means, that the software cannot see the Azeron keypad. First of all, make sure you have plugged in the USB cable fully in the keypad. It should look like this:...
  • Page 16 D) Another option is when software is asking to choose the device you want to setup, if you have plugged in multiple Azeron devices. Choose the Device you wish to configure.

  • Page 17: How To Use Azeron Software

    On-board profiles are saved in the keypad memory (so you can use the keypad on other PC or consoles and it will work with the saved settings). If you are using only on-board profiles, then Azeron software doesn’t need to be opened while gaming, it is used just to setup buttons.

  • Page 18: Keybind Setup

    5.2. KEYBIND SETUP When pressing button on the keypad, the corresponding button will light up in the Azeron software and execute the keybind. To setup buttons, with your mouse click on the button you wish to setup, then on the popup window choose between several modes.

  • Page 19: Keyboard Mode

    5.2.1. Keyboard mode For keyboard mode you can setup a keyboard button to be used on Azeron keypad. It is also possible to setup button combinations on one key press (for example, Shift + Ctrl + Alt + E). Only buttons not possible to setup currently are Right side modification buttons, they will always default to the Left side Shift, Ctrl or Alt.

  • Page 20: Mouse Mode

    XIM device (or similar adapter), then you need to setup all buttons as joystick buttons. Upon receiving your Azeron keypad or after reinstalling firmware by default the second profile in on-board memory will have all buttons setup as generic joystick buttons. So you can use Azeron on console via XIM adapter straight out of box.

  • Page 21: Joystick D-Pad Mode

    5.2.5. Joystick D-pad mode In Joystick D-Pad mode the button can be setup as any function of the D- Pad (Up, Right, Down Left, Left, and also diagonally, for example Right Up or Left Down). This also will act as direct input of generic gaming controllers.

  • Page 22: Mouse Wheel

    If you enable mode Toggle only on hold, then the second thumbstick settings will work only while the button on the keypad is held down. 5.2.7. Mouse wheel Any of the buttons can function as a mouse wheel (either horizontal or vertical).

  • Page 23: Input Sequence

     Next  Previous  Stop  Play / Pause  Mute  Volume Up  Volume Down 5.2.9. Input sequence This mode is not available in On-board memory profile! It is possible to setup several keybinds on one button which are changing in sequence.
  • Page 24 For example, in the picture above, we are editing button #1 as a profile switch button and we will set it up to switch to another software profile, which is called “ED2”. Now when pressing button #1 on the keypad, the keypad will switch to profile named “ED2”...
  • Page 25 How to setup layering step by step: 1. Create 2 profiles in software section (layering will not work in on- board memory). We will name them Profile 1 and Profile 2: 2. Activate Profile 1, select on the button you wish to use as layer shift.

  • Page 26: Macro

    5.2.11. Macro This mode is not available in On-board memory profile! It is possible to setup macros on keypad buttons. When choosing Macro mode for the button, it is possible to program several sequential keyboard keypresses, mouse buttons and delays in the sequence you wish. You can also choose how long is the keypress and delays in milliseconds (avoid using too small values for delays and keypresses, otherwise it may not register).

  • Page 27: No Action Mode

    You can also change the default macro duration in the settings: 5.2.12. No action mode Right click on the button to delete any keybind on it and make it “empty” and do nothing. Or press “Unbind All” at the top to remove all keybinds and labels in current profile.

  • Page 28: Button Labels

    5.2.13. Button labels You can setup custom names for each button for easier overview of your keybinds. Similar to this (white color is keybinds, darker color is custom button names): To setup custom name - click on the button and then write the name in field “Custom name”: In the software Settings under Appearance you can choose to:...

  • Page 29: Advanced Settings - Release Behavior

    5.2.14. Advanced settings – Release behavior By opening the advanced section, it is possible to specify how the button will be released after it is pressed down. On second press – if this is activated then the keybind will be pressed down and held until you press the button for 2 time.

  • Page 30: Calibrating Thumbstick

    Here is steps on how to do it: Plugin the USB cable of keypad to your PC. Open the Azeron software. Go to Settings. Make sure the restrictor ring is removed from the thumbstick! (If you are using software version 1.5 and up, then you...

  • Page 31: Restrictor Ring

    3. Remove the thumbstick cap 4. Put on the restrictor ring, make sure the concave part is on the thumbstick side. 5. Put back on the thumbstick cap 6. In the Azeron software go in the thumbstick settings: Page | 30 | Manual...
  • Page 32 7. Take the upper deadzone and lower it to ~120 (or around 60% in newer software versions). Make sure the thumbstick makes perfect circle at the edge when moved around. If not, then lower the deadzone even more. If you wish to setup restrictor ring for all your profiles simultaneously, then instead of adjusting the thumbstick setting for each individual profile you need to go to Settings ->...

  • Page 33: Thumbstick Setup

    If a game doesn’t support simultaneous input or is supported only partially, then the game user interface may flicker between Xbox controller and keyboard&mouse interface when trying to use Azeron keypad together with mouse. In that case you can setup analog stick with keyboard keybinds, such as WASD to have a better gaming experience.
  • Page 34 In Keyboard mode analog stick will work in 8 directions with keybinds provided for 4 directions, such as WASD or similar. If you move the thumbstick in diagonal between W and D, then it will work as W+D at the same time (if it does not, you need to calibrate the thumbstick).
  • Page 35 (even your cat sneezing) and it may have a flickering motion in Azeron software and a character in video game may move around even if you are not touching the thumbstick. In that case you need to set the lower deadzone value higher until it stops moving by itself (for example something between 2%-13% is a good value or 10 –...
  • Page 36 here the settings you change for the thumbstick will add up to the settings that were applied via calibration tool. Upper deadzone determines how far is the outer diameter of the thumbstick travel zone. The higher the value the smaller the outer circle. So the higher the value, the less movement you will need with your thumb for...

  • Page 37: Profiles

    To work with software profiles, you need to turn them on by pressing ON button near “Profiles:”. Note! When using software profiles, the Azeron software must be running in the background while playing the game. If you are using Software profiles, it is possible to choose 2 profiles as favorite and then switch between them with Profile switch similar as on- board memory profiles.
  • Page 38 The list of profiles can be reordered by drag & dropping with your mouse. Any software profile can also be sent to On-board memory, by pressing OBM#1 or OBM#2. Note that Macros or layers will not work in on-board memory profiles. At the bottom of the profile list is button + Copy Profile, which will create a new profile by copying currently selected profile.

  • Page 39: Profile Import / Export

    PC and you can choose a game or software from that list. In the Settings you can turn on an option that, when launching Azeron software, it checks what software/games are already opened. Page | 38...

  • Page 40: System Tray Icon

    Software mode – switch the keypad to software profile mode Visit Azeron – open Azeron.eu download site Exit – close the Azeron software completely You can double click on the Azeron icon in the system tray to open the software window. Page | 39...

  • Page 41: Settings

    6. SETTINGS At the left side of the software you can select Settings button to access all the software and keypad settings: APPEARANCE Under Theme section you can choose the color theme for whole software. Under Button mapper you can change size of the buttons and keybind font size.
  • Page 42 Lefty layout must be turned on if you are using Azeron device in your right hand, to flip the button keybind interface. Hide custom labels will hide the labels for each button you have created, only keybinds will be visible.
  • Page 43 UPDATE SETTINGS Version information. Here you can see what software and firmware you are using. And check out what have been changed in Release Notes. Update settings. By turning On the “Auto update enabled” it will offer to install the newest software version as soon as it is released. If you are ok to use beta version of the newest release and test new features before they are “polished”, you can turn On the “Beta Version Opt in”...
  • Page 44 If you enable Start with Windows, then whenever you turn on your PC, the Azeron software will open automatically at the startup. It is possible to minimize the Azeron software to Windows system tray (at the bottom near the clock) by enabling option Close button minimizes software to the tray.
  • Page 45 IMPORT / EXPORT At the Import/Export option it is possible to Export and Import all your profiles. You can back up all of your profiles in .JSON file, to prevent any accidental deletion when reinstalling software or Windows, updating firmware, etc. You can also export/import individual profiles – see how to here: 5.6.1 PROFILE IMPORT/EXPORT Note! Profiles that are in on-board memory will not be exported! Only software...
  • Page 46 And the other option at the bottom is for changing the default macro duration for each macro step. With analog throttle it is possible to control how often inputs are sent from your thumbstick (only in keyboard mode). The higher the number, the more milliseconds are between each input sent.

  • Page 47: Troubleshooting

    7. TROUBLESHOOTING 7.1 KEYPAD IS NOT RECOGNIZED If your PC or Azeron software doesn’t see your keypad or firmware update failed, please follow these troubleshooting steps: At the side of the keypad is LED lights on? Yes -> Go to LED lights on No ->...
  • Page 48 If none of the above works, try reinstalling software and firmware. First you need to remove the palmrest to see which main board your keypad has: Unscrew these 3 screws and then remove the palmrest. See if the mainboard is in green or black color.

  • Page 49: Led Lights Off

    Azeron directly to the motherboard USB port using the original cable. Step 3 – check if USB cable is working by plugging the Azeron keypad in other PC or device that can recognize standard keyboard. Step 4 – if you have a spare mini USB cable, please try plugging in...
  • Page 50 Step 5 – See if the Azeron keypad is recognized in the device manager. If there shows up more than one controller, unplug Azeron, delete the other controller. Restart PC and plug in the Azeron. If none of the above works, try reinstalling software and firmware. First...
  • Page 51 If you are experiencing further issues, please export the log file from software Settings tab -> Troubleshooting -> Export logs and email it to us on info@azeron.eu and tell us about the issue. If your keypad has black color...

  • Page 52: No Usb Chime When Connecting

    Azeron directly to the motherboard USB port using the original cable. Step 3 – check if USB cable is working by plugging the Azeron keypad in other PC or device that can recognize standard keyboard. Step 4 – if you have a spare mini USB cable, please try plugging in...
  • Page 53 If you are experiencing further issues, please export the log file from software Settings tab -> Troubleshooting -> Export logs and email it to us on info@azeron.eu and tell us about the issue. If your keypad has black color...

  • Page 54: Button Issues

    7.2.2 Not registering any input in PC Step 1 – in Azeron software go to Settings -> Troubleshooting -> Utilities and try any of the reset buttons. Step 2 – if that doesn’t help, then we will need to check if the wire is properly connected to the button with input issue.

  • Page 55: Ghost Clicks (Chattering)

    If the issue doesn’t occur, it was caused by a bad / corrupted profile Step 3 – in Azeron software go to Settings -> Advanced -> adjust the button throttle slider to higher numbers until the ghost clicks disappear.

  • Page 56: Thumbstick Issues

     Open the game, then on Azeron switch to profile with the thumbstick set to keyboard mode and then switch back to xbox 360 mode.  Make sure no other controllers are connected (or any device that works with Xinput, analog buttons etc.).
  • Page 57 To turn it off for a specific game: open the game page, click on Gear icon choose Properties, in Controller tab from drop down choose “Disable Steam Input”: Or to turn it off in general Steam settings for all games: Click on Steam ->...
  • Page 58 Page | 57 | Manual...

  • Page 59: Thumbstick Is Jittering Or Drifting

    5.3 CALIBRATING THUMBSTICK Step 2 – then need to reinstall Azeron software / firmware. Make sure you are installing the correct device firmware (for example, do not install Classic keypad firmware on Cyborg keypad). See this section after Step 5 on how to reset.

  • Page 60: Thumbstick Is Going In Diagonal Line Or In One Corner

    Another fix could be to re-seat the wires that are coming from thumbstick to Azeron mainboard – disconnect the thumbstick wires (X, Y, 5v and ground) and re-connect them again, making sure the wire is making a clean contact and no insulation is in the way.

  • Page 61: Thumbstick Is Physically Getting Stuck

    You can plug in the USB again while the palmrest is open to test the thumbstick, just make sure you are not touching any of the wires or board while your Azeron is plugged in!!! If you are experiencing further issues, please email us on info@azeron.eu 7.3.4 Thumbstick is physically getting stuck...

  • Page 62: Thumbstick Is Acting As Right Stick

    If any part is broken on your keypad, it is possible to fix it. The keypad is made modular, so that it is possible to change parts. There is a spare parts section in our shop https://store.azeron.eu/service-parts But if you cannot find the part you need, let us know what you need via emailing us info@azeron.eu...

  • Page 63: Tips And Tricks

    There is also a bunch of community made mods for the keypad.  Azeron keypads are compatible with 3 party softwares, such as reWASD and JoyToKey.
