- Page 1 PLN2501 LED LCD Monitor USER'S GUIDE www.planar.com...
- Page 2 The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. ENERGY STAR is a program run by the U.S. Environmental Protection Agency (EPA) and U.S. Department of Energy (DOE) that promotes energy efficiency. This product qualifies for ENERGY STAR in the “factory default”...
-
Page 3: Table Of Contents
First Setup..................................6 Front View of the Product............................Rear View of the Product............................. 8 Quick Installation................................9 Basic Operation................................10 OSD Lock Out Function..............................11 Advanced Operation—OSD Menu.........................12 Supporting Timing Modes............................1 4 Technical Information..............................15 Wall-mount instruction..............................16 Care and Maintenance..............................17 Troubleshooting................................17 Planar Support................................18... -
Page 4: Operation Instructions
Operation Instructions Thank you for purchasing the PLN2501 LED LCD monitor. Please read this guide thoroughly. before installation. FCC RADIO FREQUENCY INTERFERENCE STATEMENT WARNING: (FOR FCC CERTIFIED MODELS) This LED LCD Monitor has been tested and found compliant with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. - Page 5 COMMUNIQUE D’AVERTISSEMENT DE LA FCC CONCERNANT LES INTERFERENCE DE FREQUENCE RADIO: (SEULEMENT POUR MODELES CERTIFIE PAR LA FCC) Ce moniteur a été testé et à été trouvé conforme aux limites pour un appareil numérique de Classe B, suivant la partie 15 des règlements de la FCC. Ces limites ont été développées pour o rir une protection satisfaisante contre les interférences nuisibles dans une installation résidentielle.
-
Page 6: Unpacking Instructions
Unpacking Instructions Move the LED LCD Monitor out of the package and take o the plastic bag and Polystyrene Foam. Remove stand and base from plastic bags and attach to the monitor. Safety Precautions Follow all warnings, precautions and maintenance as recommended in this user’s manual to maximize the life of your unit. -
Page 7: Consignes De Sécurité
Consignes de sécurité Respectez tous les avertissements, les précautions et conseils d’entretien recommandés dans ce manuel de l’utilisateur pour maximiser la durée de vie de votre appareil. A faire : Éteindre le produit avant de le nettoyer. La surface de l'écran tactile peut être nettoyée avec un chi on doux et propre imprégné d’un nettoyant doux du commerce pour vitres ou d'un mélange à... -
Page 8: Package Overview
Package Overview Stand LED LCD Monitor Base HDMI Cable Power Cord User’s Guide... -
Page 9: First Setup
First Setup Installing the Stand Base 1. Lay the LED LCD Monitor at on a table with the LED screen face down. To prevent the LED LCD Monitor from being scratched, put a piece of soft cloth on the table on which the screen will be set. -
Page 10: Front View Of The Product
Front View of the Product... -
Page 11: Rear View Of The Product
Rear View of the Product LED Indicator Joystick (Power/Menu/Navigation/Enter/Exit/Hotkey button) Power input (AC input) HDMI input (HDMI 19 pin) VGA Input (D-Sub 15 pin) -
Page 12: Quick Installation
Quick Installation Connect either VGA or HDMI Video Source from the monitor to the computer. Make sure both monitor and computer are powered OFF. 2. C onnect the power cord to a properly grounded AC outlet, then to the monitor. Power-ON computer and then POWER-ON the monitor. -
Page 13: Basic Operation
Basic Operation Before using the LED LCD monitor: Connect external equipments properly. Insert the power plug, and the power LED indicator will blink orange. Power On/O To turn the LED LCD monitor on/o : Press center button of the joystick button on the back of the LED LCD monitor. The power LED indicator lights blue when the LED LCD monitor is on. -
Page 14: Osd Lock Out Function
OSD Lock Out Function When LED LCD Monitor is in normal mode, the "OSD Lock Out" function can be enabled. Option 1: OSD lock – All buttons are locked except the "POWER" key. Press and hold the button for 3 seconds to lock the OSD button. The LED LCD Monitor will show an “OSD Locked"... -
Page 15: Advanced Operation-Osd Menu
Advanced Operation—OSD Menu You can use the OSD menu to adjust various settings for your LED LCD monitor. Press the button to display the OSD Menu, and use to select the desired OSD menu. Performance Auto Config Picture adjustment: manually adjust the modes, brightness, contrast, black Picture: boost, blue light, and DCR (Dynamic Contrast Ratio) of the screen image. - Page 16 Adjust the Gamma value and Color Temp. Color: Allows you to adjust the luminance tone. The default value is 2.2 (standard Gamma: value for Windows). Press the button to adjust the Gamma value. The default setting is warm. You can adjust and select Warm, Normal, Color Temp.: Cool, or User settings by pressing the button.
-
Page 17: Supporting Timing Modes
Supporting Timing Modes Mode Resolution Remark 640x480 60Hz 640x480 72Hz 640x480 75Hz 640x480 66.66Hz VESA 720x400 70Hz 800x600 56Hz 800x600 60Hz SVGA 800x600 72Hz 800x600 75Hz 832x624 74.55Hz 1024x768 60Hz 1024x768 70Hz 1024x768 75Hz 1152x870 75Hz 1152x864 75Hz VESA 1280x960 60Hz 1280x1024 60Hz... -
Page 18: Technical Information
Technical Information Technical Spec cation 24.5” TFT (with LED backlight) Panel Normal On: 18 Watts (typical) Power Management ECO Mode 1 On: 13 Watts (typical) Standby Mode: < 0.5 Watt O : < 0.3 Watt Full HD 1920 x 1080 max. Vertical Frequency 100Hz max. Displayable Resolution 0.283(H) x0.280(V) Pixel Dimension... -
Page 19: Wall-Mount Instruction
Wall-mount instruction Preparing To Install The Optional Wall Mount Arm (not included) This LED LCD Monitor can be attached to a wall mounting arm purchased separately. Turn the power OFF then disconnect the cables from the LED LCD Monitor before performing the procedure below. 1. -
Page 20: Care And Maintenance
Care and Maintenance Care Avoid exposing your LED LCD monitor directly to sunlight or other heat source. Place your LED LCD monitor away from the sun to reduce glare. Put your LED LCD monitor in a well ventilated area. Do not place any heavy things on top of your LED LCD monitor. Make certain your LED LCD monitor is installed in a clean and moisture-free area. -
Page 21: Planar Support
Planar Support Cables and Accessories To nd cables and accessories for your Planar monitor, touch screen or other Planar products visit our online store at www.PlanarOnline.com Technical Support Visit Planar at http://www.planar.com/support for operations manuals, touchscreen drivers, warranty information and access to Planar's Technical Library for online trouble shooting. - Page 22 Hours: 24 hours a day, 7 days a week 04/2024 Planar Systems, Inc. © Planar is a registered trademark of Planar Systems, Inc. Other brands and names are the property of their respective owners. Technical information in this document is subject to change without notice.
