GP18A / GP18
18" Active/Passive Subwoofers + 24x2" Modular Column System
Thank you for choosing KGEAR!
To ensure proper operation, please carefully
read this owner's manual and safety instruction
before using the product.
After reading this manual, be sure to keep it
for future reference.
Should you have any questions about your
new device please contact K-array customer
service at info@kgear.it or contact the local
distributor in your country.
KGEAR by K-array surl
via P. Romagnoli 17 - 50038 - Scarperia e San Piero -
Firenze - Italy - www.kgear.it
KGEAR GP18A is a heavy duty 18" powered
subwoofer combined with 3 modular 8x2"
transducer array elements featuring PAT®
K-array™
technology
designed
for
performance outdoor/indoor applications.
KGEAR GP18A features Powersoft™ DSP and
power module with Ethernet remote control and
Armonia™ control software.
The active subwoofer can drive up to 3 GP18
passive systems in a stereo configuration.
Unpacking
Each KGEAR device is inspected before
leaving the factory. Upon arrival, carefully
inspect the shipping carton, then examine and
test your new device. If you find any damage,
immediately notify the shipping company.
Check that the following parts are supplied
with the product:
KGEAR GP18A
• 3x 8x2" GSC18A column loudspeakers
• 1x GS18 active subwoofer
• 1x Power cord
KGEAR GP18
• 3x 8x2" GSC18A column loudspeakers
• 1x GS18P passive subwoofer
• 1x 15m (49ft) speaker cable
high
PRESET
PRESET
SELECT
Rear Panel
GP18A
1. Status LEDs
2. Volume potentiometer
3. DSP preset selection button
4. RJ45 Ethernet port
5. XLR Combo balanced input channel 1
6. XLR Combo balanced input channel 2
7. NL4 SpeakON B speaker output 3 and 4
8. NL4 SpeakON A speaker output 1 and 2
9. powerCON TRUE AC MAIN inlet
GP18
A. NL4 SpeakON A: signal in/out
B. NL4 SpeakON B: signal in/out
USER GUIDE
1
2
3
4
5
6
7
8
9
AC MAINS Supply
GP18A
The GP18A features a powered subwoofer:
the AC Main connection is made via the
provided power cord with powerCON TRUE
flying connector.
Insert the powerCon TRUE flying connector
into the inlet and then rotate it clockwise: once
properly plugged, the amplifier will power up.
ArmoníaPlus
ArmoníaPlus is the software for fine tuning
and monitoring the KGEAR GP18A loudspeaker
system.
Download ArmoníaPlus from Powersoft
website: www.powersoft.com
A
B
Advertisement
Related Manuals for KGEAR GP18A
Summary of Contents for KGEAR GP18A
- Page 1 GP18A / GP18 USER GUIDE 18" Active/Passive Subwoofers + 24x2" Modular Column System KGEAR GP18A is a heavy duty 18” powered subwoofer combined with 3 modular 8x2” transducer array elements featuring PAT® K-array™ technology designed high PRESET performance outdoor/indoor applications.
- Page 2 • Do not defeat the safety purpose of the polarized or • KGEAR cannot be held responsible for damage caused grounding plug. A polarized plug has two blades with This symbol alerts the user to the presence of by improper use of the loudspeakers.
-
Page 3: Loudspeaker Wiring
8x2" columns) directly driven connector on rear panel of the GP18A active ammonia, or abrasives. Do not use any sprays dedicated channel of the amp module of the loudspeaker to the speakON A connector on near the product or allow liquids to spill into any 2–... - Page 4 C. go to the preset windows and click on need to download the KGEAR amplifiers presets form the ArmoníaPlus marketplace. 5. Insert «KGEAR» in the search field and add is ON. needs, the click on Add. 9. Click on the Discovery button.
-
Page 5: Mechanical Drawings
GP18A / GP18 Mechanical Drawings Technical Specifications GP18A GP18 86mm 107mm Technical specifications Technical specifications 3,38in 4,21in Type Type Powered Sub + Column line array system Passive Sub + Column line array system Transducers Transducers SUB: 18” woofer SUB: 18” woofer COLUMN: 3 modules with 8x2”...
