Summary of Contents for Integra DTM-7.4

Page 1 Instruction Manual Network Stereo Receiver / Network Stereo Amplifier DTM-7.4...
Page 2 OPTICAL Supplementary Information Initial Setup Initial Setup Reducing the Power Consumption in Standby DTM-7.4(192.168.XXX.XXX) State DTM-7.4 When the following functions are enabled, the power consumption in standby state increases. To reduce the power consumption in standby state, check each setting and set the functions to "Off".
Page 3: Table Of Contents
Before starting the procedure Connecting a Blu-ray/DVD Disc player and Game console Firmware Update Connecting an Audio Component Update Information of the firmware Connecting an Integrated Amplifier in Checking the Firmware Version of the Unit a separate room (Multi-zone) Firmware Update Procedure Connecting Antennas (North American Part Names models only)
Page 4 Player 12 settings ® Amazon Music Playing Back Registering This Unit with Amazon Music Play Queue Playing Amazon Music using the Integra Control Pro 55 Adding Play Queue Information Playing Amazon Music using the remote controller Sort and Delete TIDAL Playing Back...
Page 5 Setup Setup Menu Menu list 1. Audio 2. Control 3. Network 4. Bluetooth 5. Works with SONOS 6. 12V Trigger A 7. 12V Trigger B 8. Firmware Update 9. Lock 10. Factory Reset Web Setup Menu operations Troubleshooting Before starting the procedure When the unit is operating erratically Turning off Initial Setup which appears when you turn the power on...
Page 6: Before Starting The Procedure
Before starting the procedure „ What's in the box * This is an online user manual. This is not supplied with the product. „ Note • Connect speakers with an impedance of 4 Ω to 16 Ω. • The power cord must be connected only after all other connections are completed.
Page 7: Firmware Update
Firmware Update Firmware Update Procedure Disclaimer: The program and accompanying online documentation are furnished to you for use at your own risk. Our company will not be liable and you will have no remedy for damages for Updating can take about 20 minutes. Furthermore, existing settings are any claim of any kind whatsoever concerning your use of the program or the maintained regardless of the method used for update.
Page 8 Updating via USB 4. Press On/Standby on the main unit to turn the unit into standby mode. The process is completed, and your firmware is updated to the latest version. • While updating the firmware, do not do the following: •...
Page 9 4. Connect the USB storage device to the USB port of this unit. firmware file. • If an AC adapter is supplied with the USB storage device, connect the AC • Others: adapter, and use it with a household outlet. After removing the power plug once, insert it to the outlet, and then start the •...
Page 10: Part Names
Part Names Front Panel H Bass dial: Adjusts the bass. I Treble dial: Adjusts the treble. J Balance dial: Adjusts the balance of the sounds output from the left and right speakers. K Menu button: Used to display the menu. Memory button (North American models only): Used to register AM/FM radio stations.
Page 11 Front Panel P Remote control sensor: Receives signals from the remote controller. • The reception range of the remote controller is within a distance of approx. 16´/5 m, and an angle of 20° in vertical direction and 30° to right and left. Q Display ( →p12) R Cursor buttons ( / ) and Enter...
Page 12: Display
Display SPEAKERS B terminals AB: When audio is being output from both the SPEAKERS A and SPEAKERS B terminals F Displays various information of the input signals. G Cursors ( / ): These may light when performing operations while "NET" is selected with the input selector.
Page 13: Rear Panel
Rear Panel C ETHERNET port: Connect to the network with an Ethernet cable. D USB port: Connect a USB storage device to play music files ( →p65). You can also supply power (5 V/1 A) to USB devices with a USB cable.
Page 14 Rear Panel N TUNER AM/FM terminal (*North American models only): Connect the supplied antennas. TUNER OOFER L M N 75 Ω O RS232 port: Connect a home control system equipped with an RS-232C port. For installing AUDI O I N AC INLET a home control system, contact the specialized HDMI OUT...
Page 15: Remote Controller
Remote Controller On/Standby button L Remote Mode Main/Zone 2 buttons: Controls B Input Selector buttons: Switches the input to the multi-zone function ( →p61). be played. M Random button: Used for random play C Play buttons: Used for playback operations operations when playing Music Server or USB.
Page 16: Inputting Characters
Inputting Characters You can use the keyboard displayed on the TV to enter the password in Wi-Fi • Select "A/a" to switch between upper and lower cases. Setup ( →p80). • To enter a space, select " ". 1. Select a character or symbol with the cursors UP/DOWN/LEFT/ •...
Page 17: Connections
Connections (Before starting the procedure) Speakers you can use with this unit and cable connections 4-16 Connections Speaker layout Connecting speakers Connecting the Subwoofer Connecting a Power Amplifier Notes regarding connections with HDMI cables Connecting the TV Connecting Playback Devices Connecting an Integrated Amplifier in a separate room (Multi-zone) Connecting Antennas (North American models...
Page 18: Speakers You Can Use With This Unit And Cable Connections
Connections Speakers you can use with this unit and cable connections „ Speakers you can use with this unit This unit supports speakers with 4 Ω to 16 Ω impedance. For speaker impedance, check the speaker instruction manual. „ (Note) Speaker Impedance If any of the connected speakers have 4 Ω...
Page 19: Speaker Layout
Connections Speaker layout A SPEAKER A Speakers to be connected to the SPEAKERS A terminals. Install in the main Main Room room (where this unit is located). B SPEAKER B You can connect another speaker system to this unit. Connect these speakers to the SPEAKERS B terminals.
Page 20: Connecting Speakers
Connections Connecting speakers Connect the speakers to the unit with speaker cable. • You can connect two sets of speakers to this unit. You can select which set to AC INLET listen to when enjoying music. You can also choose to listen to sounds from HDMI IN ETHERNET HDCP 2.3...
Page 21: Connecting The Subwoofer
Connections Connecting the Subwoofer Connect a powered subwoofer with this unit using a subwoofer cable. A U D IO I N HDMI OUT HDMI IN ETHERNET HDCP 2.3 P H O N O BD/DVD CBL/SAT GAME A R C 5V/1A DIGITAL IN AUDIO IN PRE/LINE OUT...
Page 22: Connecting A Power Amplifier
Connections Connecting a Power Amplifier You can connect a power amplifier to the unit and use the unit as a pre-amplifier. PRE/LINE OUT PRE OUT TUNER SPEAKERS RS232 This enables you to playback at high volumes that the unit by itself cannot produce.
Page 23: Notes Regarding Connections With Hdmi Cables
Connections Notes regarding connections with HDMI cables „ (Note) Placement of cables HDMI (High-Definition Multimedia Interface) is a digital interface standard for connecting TVs, projectors, Blu-ray Disc players, game consoles, and other Putting a load on HDMI cables can lead to poor operational performance. Place video components.
Page 24: Connecting The Tv
Connections Connecting the TV By connecting a TV to this unit, you can show the video from AV devices connected to this unit on the TV and also play the sound from the TV through this unit. To ARC TV AU DI O I N If the TV supports the ARC (Audio Return Channel) function(*), use only the HDMI OUT...
Page 25 Connections • Use an HDMI cable that supports 4K or 8K high-quality video when these are to be played. • Be sure to insert the HDMI cable all the way in.
Page 26: Connecting Playback Devices
Connections Connecting Playback Devices Connecting a Blu-ray/DVD Disc player and Game console This is a connection example of an AV component equipped with an HDMI jack. When connecting with an AV component that conforms to the CEC (Consumer A UD I O I N Electronics Control) standard, you can use the HDMI CEC function (*) that HDMI OUT HDMI IN...
Page 27: Connecting An Audio Component
Connections Connecting an Audio Component This is a connection example of an audio component. Connect a CD player using an analog audio cable. You can also connect a turntable that has an MM- type or MC type cartridge to the PHONO jack. AU D IO IN HDMI OUT HDMI IN...
Page 28: Connecting An Integrated Amplifier In A Separate Room (Multi-Zone)
Connections Connecting an Integrated Amplifier in a separate room (Multi-zone) You can enjoy 2 ch audio in the separate room (ZONE 2) while performing playback in the main room (where this unit is located). Use an analog audio cable to connect the ZONE 2 PRE/LINE OUT jacks on this unit to the input jack HDMI OUT HDMI IN ETHERNET...
Page 29: Connecting Antennas (North American Models Only)
Connections Connecting Antennas (North American models only) Connect the antenna to this unit, and set up the antenna at the best position for SPEAKERS RS232 PRE/LINE OUT PRE OUT TUNER listening while receiving radio signals. • Attach the indoor FM antenna to the wall using push pins or adhesive tape. ZONE 2 MAIN 75Ω...
Page 30: Network Connection
Connections Network Connection This unit can be connected to the network using a wired LAN or Wi-Fi (wireless LAN). You can enjoy network functions such as Internet radio by network connection. If connection is made by the wired LAN, connect the router and AC INLET HDMI IN ETHERNET...
Page 31: Connecting External Control Devices
Connections Connecting External Control Devices IR IN/OUT port When connecting a remote control receiver unit consisting of an IR Receiver, etc. to this unit, operation using the remote controller is possible even if the AC INLET remote control signal is difficult to reach (due to installation in the cabinet, ETHERNET etc.).
Page 32: Trigger Out Jack
Connections 12V TRIGGER OUT jack When connecting a device equipped with a 12V TRIGGER IN jack such as a Blu-ray/DVD Disc player to this unit, the device can be turned on or set to standby by interlocking the operation on this unit. When the desired input is AC INLET HDMI IN ETHERNET...
Page 33: Connecting The Power Cord
Connections Connecting the Power Cord Connect the power cord after all the connections are completed. • This model includes a removable power cord. Be sure to connect the power AC INLET cord to the AC INLET of the unit first, and then connect it to the outlet. Always HDMI IN ETHERNET HDCP 2.3...
Page 34: Initial Setup
Initial Setup Before starting the procedure 1. Install the app 2. Connect the unit to Wi-Fi Set the impedance Initial Setup...
Page 35: Before Starting The Procedure
• Play the music files saved on the mobile device via Wi-Fi. • Play Amazon Music (compatible models only) ( →p54) 1. Download the Integra Control Pro from the App Store or Google Play Store. If it has already been downloaded, then it is updated to the latest version.
Page 36: Connect The Unit To Wi-Fi
If any of the connected speakers have 4 Ω or more to less than 6 Ω impedance, 2. Start Integra Control Pro. The search for this unit starts automatically when and it is anticipated that they will be used continuously at full power, you have to you start the app.
Page 37: Playback
Playback Basic Operations Basic Operations Bluetooth Playback ® Listening To the Radio (North American models only) Network Services Spotify AirPlay ® Playback Amazon Alexa Amazon Music TIDAL Connecting the Sonos System for Playback Internet Radio Convenience functions Multi-zone Playing different audio and video Playing music files saved on a USB storage device Music Server Play Queue...
Page 38: Basic Operations
You can also turn on the power of the unit with the following operations: – Pressing On/Standby on the main unit. – Using the Integra Control Pro app ( →p35) You can also select a source to play with the following operations: – Using the linking function (HDMI CEC) ( →p40) –...
Page 39: Adjusting The Volume
You can also adjust the volume with the following operations: – Using the Master Volume dial on the main unit – Using the Integra Control Pro app ( →p35) – Using the linking function (HDMI CEC) ( →p40) *1 It cannot be set if the listening mode is Direct.
Page 40: Switching Speakers
Playback Switching speakers Using the linking function (HDMI CEC) When you have connected two sets of speakers to this unit, you can select By using an HDMI cable and connecting to a TV that is compatible with the which set to output the sound. HDMI CEC (Consumer Electronics Control) function, you are able to perform 1.
Page 41: Switching The Display
Playback Switching the display Repeatedly pressing the Display button on the remote controller switches the display of the main unit in the following order. • The content displayed depends on the source, Bluetooth, etc., being played. • Not all the information is necessarily displayed. Input source and volume BD/DVD 4 0 .
Page 42: Bluetooth Playback
If a password is requested, enter "0000". • This unit is displayed as "Integra DTM-7.4 XXXXXX". This display can be changed using the Friendly Name function ( →p81) or Integra Control Pro ( →p35) (available on iOS or Android™).
Page 43 Playback Playing Back 1. Perform the connection procedure on the Bluetooth enabled device. 2. Playing the music file. The input on this unit automatically switches to "BLUETOOTH". Turn up the volume of the Bluetooth enabled device to an appropriate level. •...
Page 44: Transmitting Audio From This Unit To Bluetooth Wireless Technology Enabled Devices
Playback Transmitting audio from this unit to Bluetooth wireless technology enabled devices Pairing 1. Press the input selector you want to play. • Select a source other than "BLUETOOTH". This function does not work if you select "BLUETOOTH". 2. Press the Setup button on the remote controller, select "4. Bluetooth" - "Bluetooth Transmitter", and select either "On (Tx)"...
Page 45 Playback Playing Back 1. Do the play operations on the AV component connected to this unit. Do the play operations on this unit when the input is TUNER or NET. • If "Variable" has been selected for the "Output Level", the volume can be adjusted on this unit.
Page 46: Listening To The Radio (North American Models Only)
Playback Listening To the Radio (North American models only) „ Tuning Manually Note that if you tune manually, the reception for FM broadcasts will be monaural rather than stereo, irrespective of the sensitivity of the reception. 1. Press the Tuner button on the remote controller repeatedly to select either "AM"...
Page 47 Playback „ Frequency step setting (North American models) Press the Setup button, and using the cursors and Enter, select "1. Audio" - "AM/ FM Frequency Step", and then select the frequency step for your area. Note that when this setting is changed, all radio presets are deleted. ‰...
Page 48: Presetting A Radio Station
When the station is registered, the preset number stops flashing. Repeat this procedure for all of your favorite radio stations. You can also register radio stations with the following operations: – Pressing Memory on the main unit. – Using the Integra Control Pro app ( →p35)
Page 49: Spotify
Playback Spotify Use your phone, tablet or computer as a remote control for Spotify. Go to https://connect.spotify.com/ to learn how. • The services may not be available, depending on your area of residence.
Page 50: Airplay
Confirm that this unit and the PC are connected to the same network beforehand. Then, press NET on the remote controller. Next, click the AirPlay icon in iTunes, select this unit from the displayed devices, and start play of a music file. iPhone Integra DTM-7 e.g., iOS 10...
Page 51: Playing Back On Multiple Devices (Airplay2)
• Due to the characteristics of AirPlay wireless technology, the sound produced iPhone on this unit may slightly be behind the sound played on the AirPlay-enabled Integra DTM-7.4 device. Integra XXXXXXXX You can also play the music files on a PC with iTunes (Ver. 12.8 or later) Integra XXXXXXXX equipped.
Page 52: Amazon Alexa
1. Register with the Amazon account on Integra Control Pro. This cannot be set • You need an Amazon account to use Amazon Alexa. For more information, with operations on this unit.
Page 53: Operating This Unit
(*1) Log in using the same account as other terminals with Amazon Alexa. music, and skip music up or down. 8. When registration is finished, the screen returns to the one for Integra 1. With the unit on, speak at the terminal with Amazon Alexa (an Amazon Echo, Control Pro.
Page 54: Amazon Music
Amazon Music Registering This Unit with Amazon Music 1. Register with the Amazon account on Integra Control Pro. This cannot be set with operations on this unit. Refer to "1. Install the app" ( →p35) for information about the app.
Page 55: Playing Amazon Music Using The Integra Control Pro
Playing Amazon Music using the Integra Control Pro 1. Start up Integra Control Pro. This unit is automatically displayed after startup. Then, tap and select this unit displayed. 2. Tap "NET" or "NETWORK" on the upper part of the screen to switch to the network screen.
Page 56: Tidal
Registering this unit with TIDAL allows you to enjoy the music distribution service provided by TIDAL. You can register this unit on the screen of Integra Control Pro by downloading Integra Control Pro (available on iOS or Android™) to mobile devices such as a smartphone and tablet.
Page 57: Connecting The Sonos System For Playback
Playback Connecting the Sonos System for Playback How to Connect This Unit and Sonos Port 1. Connect the Sonos Port to the AUDIO IN jack of this unit with the RCA audio cable supplied with the Sonos Port. Any input jacks other than the PHONO jack can be used.
Page 58: Playing Sonos On This Unit
Playback Output Zone: With the cursors LEFT/RIGHT, select the ZONE where you want to listen to the music. "Main": Outputs audio only to the main room (where this unit is located). "Zone 2": Outputs audio only to the separate room (ZONE 2). "Main/Zone 2": Outputs audio to both the main room and separate room (ZONE 2).
Page 59: Internet Radio
Playback Internet Radio By connecting this unit to an Internet-connected network, you can enjoy Internet radio services such as TuneIn Radio. • To play Internet radio services, the network needs to be connected to the Internet. • Depending on the Internet radio service, a user registration may be required on your PC beforehand. For details of each service, visit the website of each service. Playing Back Perform the following procedure when this unit is on.
Page 60 Playback Internet Radio Service Menu You can bookmark specific stations, or delete stations that have been bookmarked. The displayed menu varies according to the service being selected. The menu icon is displayed while a station is being played. When only this icon is displayed, pressing Enter will display the menu on the screen.
Page 61: Multi-Zone
Playback Multi-zone Using Integra Control Pro ( →p35) is convenient for operations of multi-zone You can enjoy 2 ch audio in the separate room (ZONE 2) while performing playback in the main room (where this unit is located). The same source can be playback.
Page 62: Playing Back (Zone 2)
Playback Playing Back (ZONE 2) Turning ZONE 2 On/Off 1. Press Remote Mode Zone 2 once on the remote controller. • The remote controller switches to the mode for controlling ZONE 2. Note 2. Press On/Standby on the remote controller. "Z2" lights in the main unit display when ZONE 2 turns on.
Page 63 Playback Selecting a source to play in ZONE 2 Adjusting the volume in ZONE 2 1. Press Remote Mode Zone 2 once on the remote controller. When using an integrated amplifier that has a volume control • The remote controller switches to the mode for controlling ZONE 2. Use the volume control on the integrated amplifier to adjust the volume.
Page 64: Playing Different Audio And Video
Playback Playing different audio and video Displaying Your Favorite Video on TV While Playing Music While listening to the music from a CD or Bluetooth enabled device, you can display video on TV from an AV component such as a Blu-ray Disc player. •...
Page 65: Playing Music Files Saved On A Usb Storage Device
• The USB port of this unit complies with the USB 2.0 standard. The transfer tablet to which you have downloaded Integra Control Pro (for use on iOS and speed may be insufficient for some content you play, and sound interruptions, Android™).
Page 66: Usb Storage Device Requirements
Playback USB Storage Device Requirements • To display an artist name, album title and album art of a file in WAV format, make the folder structure and file names as shown below when saving music files. The album art can be displayed by saving a .jpg file to display on the •...
Page 67: Music Server
• Integra Control Pro ( →p35) is convenient for controlling the playback of music stored on a PC or NAS. It can be used on a smartphone or tablet to which you have downloaded Integra Control Pro (for use on iOS and Android™).
Page 68: Playing Back
Playback Playing Back 6. Select the target server with the cursors, and press Enter to display the items list screen. • This unit cannot access pictures and videos stored on servers. Perform the following procedure when this unit is on. •...
Page 69 Playback Controlling Remote Playback from a PC You can use this unit to play music files stored on your PC by operating the PC in your home network. The unit supports remote playback via Windows Media ® Player 12. To use the remote playback function of this unit with Windows Media ®...
Page 70: Play Queue
2. Tapping the "+" icon of the track you want to add will open the pop-up to add the Play Queue information. When downloading Integra Control Pro (available on iOS or Android™) to mobile devices, such as a smartphone and tablet, you can save your favorite playlist...
Page 71: Playing Back
Playback 2. To reorder the tracks, tap the " " editing icon, then tap the “ ” icon of the 4. Tap the " " icon next to the track you want to delete to put in a " ", then track and drag it to the destination.
Page 72 Setup Setup Menu Menu list 1. Audio 2. Control 3. Network 4. Bluetooth 5. Works with SONOS Setup 6. 12V Trigger A 7. 12V Trigger B 8. Firmware Update 9. Lock 10. Factory Reset Web Setup...
Page 73: Setup Menu
Setup Setup Menu Press the Setup button on the remote controller to display the Setup menu. Select the item with the cursors UP/DOWN of the remote controller, and press the Enter button to confirm your selection. Use the cursors LEFT/RIGHT to change the default values. •...
Page 74 Setup TV screen (OSD) Main unit display 2. Control OSD Language [ 2.Control [ Lang : English ] HDMI CEC [ HDMI CEC : On ] HDMI Standby Through [ Thru:Auto(Eco) ] Auto Standby [ Auto Stby :Off ] Auto Standby in HDMI Standby Through [ ASb(Thru) :Off ] Audio Return Channel [ ARC:...
Page 75 Setup TV screen (OSD) Main unit display 4. Bluetooth Bluetooth Receiver [ 4.Bluetooth [ Rx : On ] Auto Input Change [ AutoChange: On ] Auto Reconnect [ Reconnect : On ] Pairing Information [ Pairing Info Device [ Device: Status [ Stat: Bluetooth Transmitter...
Page 76 Setup TV screen (OSD) Main unit display 6. 12V Trigger A Delay [ 6.12V Trigger A ] [ Delay :0sec ] BD/DVD [ BD/DVD :Main ] GAME [ GAME :Main ] CBL/SAT [ CBL/SAT :Main ] [ PC :Main ] [ CD :Main ] TV/TAPE...
Page 77: Audio
Setup Setup 1. Audio 1. Audio ‰ Speaker Impedance (Default Value: 6 ohms or above) ‰ Zone 2 Power On Volume (Default Value：Last) Set the impedance (Ω) of the connected speakers. Set the Zone 2 volume level of when this unit is turned on. Select a value from •...
Page 78: Control
Setup Setup 2. Control 2. Control ‰ OSD Language (Default Value: English) ‰ HDMI Standby Through (Default Value: Auto (Eco)) When this is set to anything other than "Off", you can play the video and audio of Select the on-screen display language from the following. an HDMI-connected player on the TV even if the unit is in standby mode.
Page 79 • Default values vary depending on the regions. application such as Integra Control Pro that can control this unit. The unit will automatically enter standby mode ("AUTO STBY"...
Page 80: Network
Setup Setup 3. Network 3. Network Change the settings of the Network function. ‰ DHCP (Default Value: Enable) • When LAN is configured with a DHCP, set "DHCP" to "Enable" to configure the setting automatically. ("Enable" is set by default) To assign fixed IP Enable Auto configuration by DHCP addresses to each components, you must set "DHCP"...
Page 81 3. Network ‰ Friendly Name (Default Value: Integra DTM-7.4 XXXXXX) ‰ AirPlay Device Name (Default Value: Integra DTM-7.4 XXXXXX) Change the model name of this unit which is displayed on the device Change the model name of this unit which is displayed on the AirPlay- connected to the network to an easily recognized name.
Page 82 Setup Setup 3. Network ‰ AirPlay Password (Default Value: -) ‰ Privacy Statement (Default Value: Not Accepted) You can set a password of up to 31 characters so that only users that have When using a network service that requires a login name, email address, input can use AirPlay.
Page 83: Bluetooth
Setup Setup 4. Bluetooth 4. Bluetooth Change the settings for the Bluetooth function. ‰ Pairing Information (Default Value: -) • Wait for a while if "4. Bluetooth" cannot be selected. It can be selected when You can initialize the pairing information stored on this unit. If you are no longer the Bluetooth function is activated.
Page 84 Setup Setup 4. Bluetooth (Bluetooth Transmitter) ‰ Low Latency Mode (Default Value: Off) ‰ Bluetooth Transmitter (Default Value: Off) If the audio from a device connected via Bluetooth is delayed compared to the video on the TV when watching a gaming screen, etc., you can reduce the audio Select whether or not to use the function that transmits audio from this unit to delay.
Page 85: Works With Sonos
Setup Setup 5. Works with SONOS 5. Works with SONOS Change the settings to connect with the Sonos Port. ‰ Output Zone (Default Value: Main) Select the zone where you want to listen to the music. (SONOS-1/SONOS-2) • To use this function, set "Input Selector" beforehand. ‰...
Page 86: Trigger A
Setup 6. 12V Trigger A 7. 12V Trigger B Set when outputting the control signal (maximum 12 V/100 mA) through the 12V Set when outputting the control signal (maximum 12 V/25 mA) through the 12V TRIGGER OUT A jack. You can enable power link operation when you connect TRIGGER OUT B jack.
Page 87: Firmware Update
Setup 8. Firmware Update 9. Lock Lock the Setup menu so that the settings cannot be changed. ‰ Update Notice (Default Value: Disable) ‰ Setup Parameter (Default Value: Unlocked) Availability of a firmware update is notified via network. Lock the Setup menu so that the settings cannot be changed. Enable Notify updates Locked...
Page 88: Factory Reset
Setup 10. Factory Reset All the settings are restored to factory defaults. Select "Start" and press Enter. • If "Factory Reset" is performed, your settings are restored to the default values. Be sure to note down your setting contents beforehand.
Page 89: Web Setup
Setup Web Setup Menu operations Device Information You can make the settings for the network function of this unit using an Internet browser on a PC, smartphone, etc. You can change the Friendly Name or AirPlay Device Name, set an AirPlay Password, etc.
Page 90 Troubleshooting Before starting the procedure When the unit is operating erratically Try restarting the unit Resetting the unit (this resets the unit settings to the default) Turning off Initial Setup which appears when you turn the power on Troubleshooting Troubleshooting „...
Page 91: Before Starting The Procedure
Troubleshooting Before starting the procedure Problems may be solved by simply turning the power on/off or disconnecting/ connecting the power cord, which is easier than working on the connection, setting and operating procedure. Try the simple measures on both the unit and the connected device.
Page 92: When The Unit Is Operating Erratically
Troubleshooting When the unit is operating erratically ‰ Try restarting the unit ‰ Resetting the unit (this resets the unit settings to the default) Restarting this unit may solve the problem. Set the main unit to standby, then after waiting for 5 seconds or more, press and hold the On/Standby button of If the restart of the unit does not solve the problem, reset the unit, and restore the main unit for at least 5 seconds, and then restart the unit.
Page 93: Turning Off Initial Setup Which Appears When You Turn The Power On
Troubleshooting Turning off Initial Setup which appears when you turn the power on If a Wi-Fi connection is not established, or if a wired LAN connection is not made, Initial Setup is displayed when you turn the power on. To stop Initial Setup from being displayed, press and hold the Return button for 5 or more seconds while it is being displayed.
Page 94: Troubleshooting
Troubleshooting Troubleshooting „ Power ‰ The unit turns off unexpectedly • If "2. Control" - "Auto Standby" on the Setup menu is activated, the unit automatically enters the standby mode. ( →p79) • The protection circuit function may have operated due to an abnormal rise in temperature of the unit. In such a case, the power turns off repeatedly even if the power is turned on each time.
Page 95: X84; Video
Troubleshooting ‰ Noise can be heard • Using cable ties to bundle analog audio cables, power cords, speaker cables, etc. may degrade the audio performance. Do not bundle the cords. • An audio cable may be picking up interference. Change the position of the cables. ‰...
Page 96: X84; Linked Operation
Troubleshooting „ Linked operation ‰ HDMI linked operation does not work with CEC-compliant devices, such as a TV • In the Setup menu of the unit, set "2. Control" - "HDMI CEC" to "On". ( →p78) • It is also necessary to set HDMI linking on the CEC-compliant device. Check the instruction manual. „...
Page 97 Troubleshooting ‰ Cannot connect a Bluetooth wireless technology enabled device (PC, smartphone, etc.) to this unit • Initialize the pairing information and perform pairing again. Firstly delete all the pairing information saved on this unit. In the Setup menu, select "4. Bluetooth" - "Bluetooth Receiver" - "Pairing Information", then press Enter while "Clear"...
Page 98: X84; Network Function
Troubleshooting „ Network function • If you cannot select a network service, start up the network function to select it. It may take approx. 1 minute to start it up. • When the NET indicator is blinking, this unit is not properly connected to the home network. •...
Page 99: X84; Usb Storage Device
Troubleshooting „ USB storage device ‰ USB storage device is not displayed • Check if the USB storage device or USB cable is securely inserted to the USB port of the unit. ( →p65) • Disconnect the USB storage device once from the unit, and then reconnect it. •...
Page 100: X84; Multi-Zone Function
Troubleshooting „ Multi-zone function ‰ Cannot ZONE-output the audio of externally connected AV components • To output audio from an externally connected AV component to ZONE 2, use an analog audio cable for connection. Note that ZONE 2 output is not possible with the connection using an HDMI cable, digital coaxial cable, or digital optical cable.
Page 101 Appendix General Specifications Appendix...
Page 102: General Specifications
Appendix General Specifications Amplifier Section North American models Middle East, Australian and Asian models With 8 ohm loads, both channels driven, from 20 Hz-20 kHz; rated 110 watts per channel Rated Output Power * minimum RMS power, with no more than 0.08% 2 ch ×...
Page 103 Appendix Tuner Section North American models Middle East, Australian and Asian models FM Tuning Frequency Range 87.5 MHz - 107.9 MHz 50 dB quieting sensitivity (FM MONO) 2.8 μV, 20.2 dBf (IHF, 1 kHz, 100% MOD) AM Tuning Frequency Range 530 kHz - 1710 kHz Preset Channel Bluetooth Section...
Page 104 Appendix HDMI North American models Middle East, Australian and Asian models Input Output HDMI IN *1 HDMI OUT BD/DVD CBL/SAT GAME bandwidth 40Gbps 40Gbps 40Gbps 40Gbps 40Gbps ALLM Gaming-VRR SBTM Uncompressed 8K/60p 8K/60p 8K/60p 8K/60p 8K/60p 4:2:0 4:2:0 4:2:0 4:2:0 4:2:0 Compressed 8K/60p...
Page 105 Appendix Corresponding Frame rate Color space Color depth HDMI Input input resolutions 24/25/30 Hz YCbCr4:2:2 12 bit (3840x2160p) YCbCr4:4:4/RGB 8 bit 10/12 bit 4K SMPTE 48/50/60 Hz YCbCr4:2:0 8 bit (4096x2160p) 10/12 bit YCbCr4:2:2 12 bit YCbCr4:4:4/RGB 8 bit 10/12 bit 100/120 Hz YCbCr4:2:0 8/10/12 bit...
Page 106 Appendix Network Section North American models Middle East, Australian and Asian models Ethernet LAN 1 (10BASE-T/100BASE-TX) Wireless LAN IEEE 802.11 a/b/g/n/ac standard (Wi-Fi standard) 5 GHz/2.4 GHz band ® MP3 (.mp3) • MPEG-1/MPEG-2 Audio Layer-3/44.1 kHz, 48 kHz/Between 8 kbps and 320 kbps, and VBR/2 ch WMA (.wma) •...
Page 107 Appendix USB Section North American models Middle East, Australian and Asian models 2 (Front: Ver.2.0, 5 V/0.5 A, Rear: Ver.2.0, 5 V/1 A) MP3 (.mp3) • MPEG-1/MPEG-2 Audio Layer-3/44.1 kHz, 48 kHz/Between 8 kbps and 320 kbps, and VBR/2 ch WMA (.wma) •...
Page 108 Appendix General North American models Middle East, Australian and Asian models Power Supply AC 120 V, 60 Hz AC 220 - 240 V, 50/60 Hz Power Consumption 265 W 275 W Full Standby mode 0.2 W 0.2 W Network Standby (wired) 1.7 W 1.8 W Network Standby (wireless)
Page 109 Appendix Audio Outputs North American models Middle East, Australian and Asian models MAIN PRE OUT L/R × 1, Analog SUBWOOFER PRE OUT × 1, ZONE 2 PRE/LINE OUT × 1 SPEAKERS A L/R × 1 (Ready to receive banana plugs), SPEAKERS A L/R ×...
Page 110 SN 29404149_EN © Copyright 2024 Premium Audio Company Technology Center K.K. All rights reserved. ©2024 Premium Audio Company Technology Center K.K. Tous droits de reproduction et de traduction réservés. Privacy Policy, available at [https://www.onkyo.com/privacy/]. F2402-0...
