- Page 1 HWP-150-EXT FIREWOOD PROCESSOR 205 COLLEGE STREET PINE RIVER, MN 56474 218-587-2065 WWW.HALVERSONWOODPRODUCTS.COM...
- Page 2 2850 PSI. It is important that the hydraulic pressure DOES NOT EXCEED 3000 PSI! The HWP-150-EXT incorporated a valve body which has a maximum pressure of 3000 PSI and the valve body could fail if operated at higher pressures.
- Page 3 6 powered buttons on your controls. Otherwise, you will need to purchase one of the Halverson Main Cab Button Harnesses. Max Log Diameter ............... 22” Max Log Length ..............12’ Min Log Length ..............6’...
- Page 4 DIAGRAM OF HWP-150-EXT MAIN PARTS 1- 4-WAY HYDRAULIC SPLITTER HEAD 2-CHAIN SAW 3-CHAIN SAW MOTOR 4-CHAIN SAW GUARD 5-GRAB ARM 6-OIL CONTAINER 7-TABLE 8-TABLE TROUGH 9-SPLITTER CYLINDER 10-LEAD HOSES 11-LEG 12-FEET DIAGRAM OF HWP-150-EXT VALVE BODY VALVES WIRE LOCATION SV1- GRAB ARM UP & DOWN 1- GRAB ARM UP...
- Page 5 GENERAL SAFETY LABELS: Your HWP-150-EXT Firewood Processor carries prominent labels as reminders for its proper and safe use. Shown below are copies of all the labels that appear on the equipment. Take a moment to study them and make note of their location on your processor before you operate the unit.
- Page 6 SAFETY (continued) OPERATOR REQUIREMENTS: -Operators must be adults and familiar with the operation of the skid steer and HWP-150-EXT. -Never operate while impaired. GENERAL SAFE OPERATING PRACTICES: -Keep all bystanders at least 50 feet away while operating processor. Do not allow bystanders directly in front of or directly behind processor.
- Page 7 General Safety-continued Chain Shot How does chain shot occur? What is chain shot? A chain shot consists of two breaks in a chain. Chain shot is the high velocity separation First, the loop of chain breaks and and ejection of a piece or pieces of cutting forms two ends.
-
Page 8: Installation
Installation Fitting the Processor to the Skid Steer ✓ Engage the upper portion of the skid steer’s quick-attach mount, and then rotate the mount into position against the processor’s main mounting plate. ✓ Lock the pins or wedges to secure the processor to the skid steer mount. Make sure the locks, pins or wedges, are fully engaged into the slots on the processor mount. - Page 9 Installation, continued Connecting the Processor to the Skid Steer With the wiring completed, the firewood processor can be reattached and the cable and hydraulic connections can be made. Connect the case drain hose to the case drain quick coupler on the skid steer, then the pressure line (“P”) and the tank/return line (“...
- Page 10 14 pin connector for a total of 8 pins. If you do not have enough functions you will need a Halverson Main Cab Harness Kit. The HWP-150 will work on a Bobcat 7-pin if skid steer has pilot controls (no foot pedals).
- Page 11 Loosen/tighten jam nut Adjustment and Control Functions, continued MEASURING DEVICE STEP 1: Locate the adjuster plate for the measuring device. STEP 2: Loosen the two 5/16 bolts with 1/2” wrench STEP 3: Adjust the plate according to what you want your length of the wood to stop at. STEP 4: Tighten the two 5/16"...
-
Page 12: Replacing The Chain
Precautions The chainsaw is equipped with an auto return features. When the control button is released, the saw will automatically return to its home position. BE WARE OF THIS FEATURE WHEN WORKING AROUND THE PROCESSOR. SHUT OFF ENGINE WHENEVER PERFORMING CLEAN-OUT OR SERVICE WORK. Attempting to go around or defeat these auto return features to gain access to an area of the machine can result in serious injury or death. - Page 13 STEP NINE: Remove Chain MOUNTING NEW CHAIN: Reverse steps to mount new chain NOTE: Chain requires a 7/32” file to sharpen. Optional Cab Harness Kit Control Diagram HWP-150-EXT LEFT BUTTON HARNESS RIGHT BUTTON HARNESS GRAB ARM DOWN TABLE FORWARD GRAB ARM UP...
-
Page 14: Operating Sequence
Operating Sequence 1) Roll processor forward until the feet at the end of the legs are parallel to the ground. 2) Drive to the log pile and place the feet under a log. 3) Roll the processor back to pick up the log and allow it to roll down the legs onto the table. -
Page 15: Warranty
This warranty applies to the HWP-150-EXT Skid Steer attachment manufactured by Halverson Wood Products, Inc. All parts and components of the HWP-150-EXT which, delivered to the original purchaser, are found to be defective in materials and/or workmanship, will be repaired or replaced as Halverson Wood Products Inc. elects... - Page 16 MERCHANTABILITY OR FITNESS otherwise provided in the Uniform Commercial Code or required by any Sale of Goods Act or any other statute. This exclusion includes fundamental terms. In no event will a Halverson Wood Products Inc. authorized dealer or a Halverson Wood Products Inc. authorized service facility, or Halverson Wood Products Inc.
-
Page 17: Troubleshooting
Trouble Shooting Problem Possible Cause Solution Saw stalls when lowered: RPM too Low…………… ……………………………….. Rev the motor Bar is not getting oil ……………………………….. Oiler will not oil Too much Down Pressure……… …………….. Adjusting Saw Feed Adjust CB clockwise Oiler will not Oil: Low Oil……………….……………………………….. - Page 18 ATTACHMENT HARNESS 14 PIN OUT PLACEMENTS *Suggested Pin Out-Please contact your skid steer dealer for specifics CAT Pre 2022 KUBOTA POWER POWER GROUND Black GROUND Black SAW DOWN Yellow SAW DOWN Yellow SPLITTER OUT Purple SPLITTER OUT Purple GRAB UP Green GRAB UP Green...
- Page 19 TEREX-ASV-TAKEUCHI JOHN DEERE POWER POWER GROUND Black Black GROUND SAW DOWN Yellow GRAB ARM UP Green SPLITTER OUT Purple SPLITTER OUT Purple GRAB UP Green GRAB UP Blue GRAB DOWN Orange SPLITTER BACK Yellow Blue Orange SPLITTER BACK GRAB ARM DOWN NEW HOLLAND JOHN DEERE 2023 &...
- Page 20 NOTES Serial #: Date Purchased: 218-587-2065 www.halversonwoodproducts.com...
-
Page 21: Warranty Registration
I have received the HWP-150-EXT Operations/Safety Manual I have read and understand the HWP-150-EXT Operations/Safety Manual Halverson Wood Products Inc. accepts no responsibility for misuse of the HWP-150- EXT Firewood Processor. Any modifications to the HWP-150-EXT Firewood Processor not performed by authorized service technicians will void Warranty.
