S P E C I F I C AT I O N S
Mounting
- Standalone
- Truss-mount (M10 or M12)
- Wall-mount
Connections - Sides
- (1) 5pin IP66 DMX In
- (1) 5pin IP66 DMX Thru
- (6) 5pin IP66 DMX/RDM optically isolated ports
- DMX Termination Button
- RDM Enable / Disable Button
Connections - Bottom
- Locking IP66 Power In/Thru
Connections - Front
- LED Port Feedback
Physical
- Length: 204mm (8 in.)
- Width: 179mm (7.1 in.)
- Height: 61mm (2.4 in.)
- Weight: 2 kg (4.41 lbs)
Electrical
- 100-240 V nominal, 50/60 Hz, 5W
Ordering
- US #: NIP101
- EU #: 1330000086
Approvals / Ratings
- cETLus / CE / UKCA / IP66
IP
66
