- Page 1 Installation Instructions Fresh Air Intake Kit for Wood Stove on legs and pedestal AC01421 Printed in Canada 46257A 2021-06-04...
-
Page 3: Kit Contents
1. Application This fresh air intake kit is designed to be installed on a wood stove with legs or pedestal. The vent termination must be installed outside the building. 2. Kit Contents Air Intake Housing 5" Self-adhesive gasket Air control cover for round hatch rod (A) 1x (B) (C) 36"... -
Page 4: Suggested Tools
4. Suggested Tools Powered Driver Robertson or Phillips screwdriver... -
Page 5: Installation Instructions
5. Installation Instructions The following images are showing a generic wood stove model. Even if your stove is different, the installation steps are identical. Step 1. Cut two strips of self-adhesive gasket, one of 17 ½" (444 mm) (B) and one of 19 5/8" (499 mm) (C) 17 1/2"... - Page 6 Step 3. Position the air intake (A) underneath the stove. Step 4. Fix the air intake at the back of the stove with two screws (G, 2x).
- Page 7 Step 5. Fix the air intake on the front of the stove with two screws (G, 2x). Step 6. Fold the air control cover as shown (D or E).
- Page 8 Step 7. Fix the air control cover (D or E) with two screws (G, 2x). The example show the air control cover for a round hatch rod (D).
- Page 9 Step 8. Make a 6" x 6" (150 mm x 150 mm) opening in the outside wall behind the unit. Install a 5" insulated flexible duct (K) to the air intake adapter using a clamp (H). Attach the other end of the flexible duct to the air intake grille (F) with another clamp (H).
- Page 10 For a mobile home installation, secure the stove to the floor with the appropriate hardware (J) for the flooring.
- Page 12 SBI HEATING ACCESSORIES 255 De Copenhague Street Saint-Augustin-de-Desmaures Québec, Canada G3A 2H3 418-908-8002...
