Holland House HOUS 2769-22H Assembly Instruction

HOUS
Thank you for purchasing this quality product. Be sure to check all packing material carefully for small parts, which may
have come loose inside the carton during shipment. Identify and count all parts and compare with the part list below.
Step
Code
A
1&2 B
5
C
TOOLS REQUIRED ( NOT PROVIDED )
PHILLIPS SCREWDRIVER
OPTION 1: Low Mattress Position
Hardware Pack Location:
KG PANEL HDBD, SKU NO.: 32427696
KG PANEL FTBD, SKU NO.: 32827694
Assembly Instruction
2769-22H
2769-22F
2769-21R
Hardware
Allen Key 4mm x 74mm x 29mm
Bolt 1/4" x 45mm x 12mm
Spring Washer 1/4" x 11mm x 2mm
Flat Washer 1/4" x 18mm x 2mm
Captured Hardware 1/4" x 19mm x 10mm
Screw
KG PANEL HDBD
KG PANEL FTBD
QN / KG RAILS
Q'TY Step
Code
1Pc
2 1
8Pcs
2
1&2
8Pcs
3
1&2
8Pcs
4
1
8Pcs
10Pcs
3
5
6
3
4 7
4 8
5 9
OPTION 2: High Mattress Position
SKU NO.: 32427696
SKU NO.: 32827694
SKU NO.: 32927696
Parts List
Headboard
Headboard post right
Headboard post left
Stretcher
Footboard
Side rails
Long support leg
Short support leg
Slat
MADE IN VIETNAM
Q'TY
1Pc
1Pc
1Pc
1Pc
1Pc
2Pcs
10Pcs
10Pcs
5Pcs
