Thank you for purchasing this quality product. Be sure to check all packing materials carefully for
small parts that may have come loose inside the carton during shipment.
***Caution: Please read all instructions carefully before starting the assembly process. These parts
are cumbersome and heavy. Therefore, two people are recommended in order to prevent personal
injury and insure the parts are not damaged during the assembly.
STEP 2
Attach the support legs to the slats, then secure
the slats by using screw "f".
Assembly Completed
Assembly Instructions
2678-30F: King Footboard w/ 3 slats
Hardware List
Code
Allen Key 4*74*29mm
a
Bolt∮1/4"x 11.5 x 105mm
b
Spring Washer∮1/4"x∮11x 2mm T
c
Flat Washer∮1/4"x∮18 x 2mm T
d
Bolt∮1/4"x 11.5 x 38mm
e
Screw #8 x 30mm
f
STEP 1
Attach one end of the
Side Rails to Headboard
by using bolts "b" and
washers, then attach
another end of the Side
Rails to Footboard by
using bolts "e" and
washers.
Q'TY
1 PC
4 PCS
8 PCS
8 PCS
4 PCS
6PCS
