- Page 1 MATV Lanuch Amplifiers INSTRUCTION MANUAL WLA115-C1 | WLA115-C3 www.whytetechnologies.com In the interest of continuous improvement, all specifications of products within this brochure are subject to change without notice.
-
Page 2: Table Of Contents
CONTENTS Safety Precautions Guarantee General Description Product Description Technical Description Installation Instructions DC Powering Options Example Configuration Specifications... -
Page 3: Safety
SAFETY Whyte MATV Launch Amplifiers are intended for indoor use only. Do not install the Multiswitch in damp, humid, hot, or dusty areas. Switch off and remove the power supply when making connections to the Multiswitch to avoid damaging the unit. -
Page 4: Guarantee
GUARANTEE All Whyte products are guaranteed for a period of 4 years from the date of purchase against defects. Within this guarantee period, Whyte Technologies will repair or replace the faulty product. In the unlikely event of a fault, please return any faulty products through your distributor. -
Page 5: Product Description
PRODUCT DESCRIPTION 470 - 862MHz 174-230MHz 88 - 108MHz DC 12V WLA115-C3 FULL TERR MATV Compact Launch Amplifier Frequency Range 88 ~ 862MHz UHF (470 ~ 862MHz) 34dB DAB (174 ~ 230MHz) Gain 30dB FM (88 ~ 108MHz) 30dB Gain Control 20dB Noise Figure <6dB... -
Page 6: Technical Description
TECHNICAL DESCRIPTION The Whyte Series A WLA115-C1 and WLA115-C3 are compact, energy efficient, high performance MATV Launch Amplifiers. Ideal for TERR only distribution situations such as residential homes, hotels, and student accommodations. The selectable Class 1 5G LTE filter enables the rejection of unwanted interferers from mobile data services. - Page 7 Figure 2 Ideal centre core conductor length relative to the nut edge Ensure your Terrestrial Antennas provide adequate signal levels from the FM, DAB and Terrestrial transmitter being received. Keep in mind that there will be signal losses within coaxial cable and the introduction of slope over distance. Ensure that the drop cables are connected correctly in the corresponding order with respect to the Launch Amplifier input.
-
Page 8: Dc Powering Options
DC POWER OPTIONS MATV (DC Remote Power) 470 - 862MHz 174-230MHz 88 - 108MHz DC 12V WLA115-C3 FULL TERR MATV Compact Launch Amplifier Frequency Range 88 ~ 862MHz UHF (470 ~ 862MHz) 34dB DAB (174 ~ 230MHz) Gain 30dB FM (88 ~ 108MHz) 30dB Gain Control 20dB... -
Page 9: Example Configuration
EXAMPLE CONFIGURATION 96 Point Terrestrial distribution 470 - 862MHz 174-230MHz 88 - 108MHz DC 12V WLA115-C3 FULL TERR MATV Compact Launch Amplifier Frequency Range 88 ~ 862MHz UHF (470 ~ 862MHz) 34dB Gain DAB (174 ~ 230MHz) 30dB FM (88 ~ 108MHz) 30dB Gain Control 20dB... -
Page 10: Specifications
SPECIFICATIONS: WLA115-C1 MATV Lanuch Amplifier - Single Input MODEL WLA115-C1 Single Input UHF, DAB, FM (Combined signals) FM Frequency 88 ~ 108 MHz DAB, III Frequency 174 ~ 230 MHz 470 ~ 862 MHz Frequency Range 88 ~ 862 MHz Classification (filter) selector Class 0, Class 1 (Switchable 5G / Full Band) Gain... - Page 11 SPECIFICATIONS: WLA115-C3 MATV Lanuch Amplifier - Three Input MODEL WLA115-C3 Three Inputs UHF, DAB, FM (Separate signals) FM Frequency 88 ~ 108 MHz DAB, III Frequency 174 ~ 230 MHz 470 ~ 862 MHz Frequency Range 88 ~ 862 MHz Classification (filter) selector Class 0, Class 1 (Switchable 5G / Full Band) Gain...
- Page 12 Unit 1, Watermill Business Centre. Edison Road, Enfield. EN3 7XF Tel: 0330 999 1980 | info@whytetechnologies.com | www.whytetechnologies.com Copyright © Whyte Technologies. February 2024 - v1...
