Assembly Instructions
CM4914-3PK
ASSEMBLY RATING
Tools Required for Assembly:
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
Allen Wrench
(Included)
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
DIFFICULT
EASY
Page 1 of 5
Rev.18-10-12
Advertisement
Related Manuals for Furniture of America CM4914-3PK
Summary of Contents for Furniture of America CM4914-3PK
- Page 1 Assembly Instructions CM4914-3PK ASSEMBLY RATING Tools Required for Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench (Included) assembling a specific product (with 1 being easy and 5 being difficult). For some products, two persons are recommended.
- Page 2 Page 2 of 5...
- Page 3 Before you begin, please read Page 2 of “Assembly and Care Advice”. And remember, do not tighten until each step is completed or instructed. Parts List Hardware List #1 x 1 pc #A x 8 pcs Coffee Table Top Bolt 5/16”x 2” #2 x 4 pcs #B x 16 pcs Coffee Table Leg...
- Page 4 Carefully place the end table top (#3) facing down on a protected surface. Align the legs (#4) with the pre-drilled holes on the bottom corners of the end table top (#3). Prepare 8 bolt assemblies by inserting FIRST the lock washer (#C) onto the bolt (#B) and then the flat washer (#D) onto the SAME bolt (#B), in that order.
- Page 5 Carefully place the coffee table top (#1) facing down on a protected surface. Align the legs (#2) with the pre-drilled holes on the bottom corners of the coffee table top (#1). Prepare 8 bolt assemblies by inserting FIRST the lock washer (#C) onto the bolt (#A) and then the flat washer (#D) onto the SAME bolt (#A), in that order.
