Owner's Manual
Portable Wireless
Magnetic Charging Power
Bank - 4,000 mAh
Model: UPB-04K0-1CM
Este manual está disponible en español en la página de Tripp Lite:
tripplite.com
Ce manuel est disponible en français sur le site Web de Tripp Lite :
tripplite.com
WARRANTY REGISTRATION
Register your product today and be
automatically entered to win an ISOBAR
®
surge protector in our monthly drawing!
tripplite.com/warranty
1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support
Copyright © 2022 Tripp Lite. All rights reserved.
1
Advertisement
Table of Contents
Related Manuals for Tripp Lite UPB-04K0-1CM
Summary of Contents for Tripp Lite UPB-04K0-1CM
- Page 1 Bank - 4,000 mAh Model: UPB-04K0-1CM Este manual está disponible en español en la página de Tripp Lite: tripplite.com Ce manuel est disponible en français sur le site Web de Tripp Lite : tripplite.com WARRANTY REGISTRATION Register your product today and be automatically entered to win an ISOBAR ®...
-
Page 2: Product Features
Product Features • Wirelessly charges magnetic charging-compatible mobile devices (up to 18W) when plugged into a power source or as a 4,000 mAh portable battery pack • Magnetic charging pad is universally compatible with all wireless charging-compatible smartphones and devices, and can magnetically attach to Mag-Safe compatible devices •... -
Page 3: Package Includes
Package Includes • UPB-04K0-1CM • USB 2.0 Type-A to Type-C Charging Cable – 3 ft. (0.9 m) • Owner’s Manual Optional Accessories • U040-C03-C USB 2.0 Type-C to Type-C Cable, 3A, USB-IF Certified, 3 ft. (0.9 m) -
Page 4: Important Safety Instructions
Important Safety Instructions • Do not connect the power bank to power adapters that exceed 9V/2A • Do not place the power bank near heat sources or open flames • Do not place metal objects on top of a phone that is currently charging on the magnetic charging pad •... - Page 5 Power Bank Charging Notes: • Before charging any devices, first charge the wireless power bank to 100% capacity • When charging the power bank, the LEDs will illuminate to indicate the following battery capacity levels: LED Status Power Bank Battery Capacity ●●●● 75% to 100% ●●●○ 50% to 75% ●●○○ 25% to 50% ●○○○ 5% to 25% ○○○ 1% to 5% ○○○○ ● = LED Illuminated ○...
-
Page 6: Usb Device Charging
USB Device Charging Notes: • The Smart LED (the first LED on the power bank) will change from blue to green and blink repeatedly to indicate a device placed on the charging pad is actively being charged. • Only one charging output may be used at once. If you are using one charging output and wish to switch to the other, you must disconnect your device and wait 60 seconds before attempting to use the other output. 1. Using the included USB Type-C to Type-A cable, connect the USB-C connector to the USB-C port of the power bank and the USB-A connector to the USB-A port of a compatible power adapter (sold separately). - Page 7 USB Device Charging 2. Place a wireless charging-compatible device on the wireless magnetic charging pad. Optional: Remove the device from the charging pad, wait 60 seconds, then connect a charging cable compatible with the power bank and your device to the power bank’s USB-C port.
-
Page 8: Specifications
Specifications Input USB Type-C (5V/3A or 9V/1.67A) Output 1 Type-C PD 5V/3A, 9V/2A (including PD Charging) Output 2 Wireless Magnetic Charging Pad (5W/7.5W/10W) Unit Dimensions 4.21 x 2.74 x 0.6 in. [L x W x H] (107 x 69.7 x 15.25 mm) Unit Weight 0.3175 lb. -
Page 9: Warranty And Product Registration
PRODUCT REGISTRATION Visit tripplite.com/warranty today to register your new Tripp Lite product. You’ll be automatically entered into a drawing for a chance to win a FREE Tripp Lite product!* * No purchase necessary. Void where prohibited. Some restrictions apply. See... - Page 10 Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice. Photos and illustrations may differ slightly from actual...
- Page 12 1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support 22-07-095 934573_RevA...
