1111 W. 35th Street
Chicago, IL 60609 USA
Customer Support: (773) 869-1234
www.tripplite.com
Español: p. 5
Français: p. 9
This manual contains important information regarding the safe
installation and operation of the BP48V60RT3U Battery Pack.
Please read this manual and save it for later reference.
INTRODUCTION
The Tripp Lite BP48V60RT3U External Battery Pack has an output voltage of 48 VDC and is designed
for use with various Tripp Lite UPS systems equipped with 48 VDC external battery pack connectors.
When used with appropriate Tripp Lite UPS systems, this Battery Pack meets UL standard 1778. The
BP48V60RT3U may also be suitable for use with 48V DC input telecommunications equipment.

PACKING LIST

• Battery Pack
• 2 Mounting Ears
• 2 Adjustable Side Supports
• 2 Support Brackets
SAFETY
• Use caution when lifting Battery Pack. Because of the Battery Pack's considerable weight, at least
two people should assist in lifting and installing it. If rackmounting the Battery Pack, mount it in
the lowest rack space possible.
• Suggested mounting procedures are for common rack types and may not be appropriate for all rack
configurations. User must determine the fitness of mounting hardware and procedures before
mounting.
• When connecting multiple Battery Packs to a single UPS, the Battery Packs should be
approximately the same age.
• It is normal for sparks to occur inside external battery connectors during final battery connection.
• Do not unplug external batteries from the UPS while the UPS is operating on battery power, due
to the possibility of dangerous arcing.
• There are no user-serviceable parts inside the Battery Pack. Do not open the Battery Pack for any
reason.
• Do not attempt to replace internal batteries.
BP48V60RT3U
48 Volt DC Input/Output
• Screws
• Wing Bolts
• Locking Nuts
• Flat Washers
Copyright © 2001 Tripp Lite. All rights reserved.
Owner's Manual
External Battery Pack
Rack/Stack/Tower Mount
1
