- Page 1 Operating Instructions Overvoltage protection B62-36G For supply and signal cables in 4 … 20 mA circuits Document ID: 40491...
-
Page 2: Table Of Contents
Environment management system ................. 16 Supplement ..........................17 Technical data ........................ 17 Dimensions B62-36G ..................... 18 Industrial property rights ....................20 Trademark ........................20 Editing status: 2024-04-22 B62-36G • For supply and signal cables in 4 … 20 mA circuits... -
Page 3: About This Document
The dot set in front indicates a list with no implied sequence. Sequence of actions Numbers set in front indicate successive steps in a procedure. Disposal This symbol indicates special instructions for disposal. B62-36G • For supply and signal cables in 4 … 20 mA circuits... -
Page 4: For Your Safety
Arbitrary conversions or modifications are explicitly forbidden. For safety reasons, only the accessory specified by us must be used. To avoid any danger, the safety approval markings and safety tips on the device must also be observed. B62-36G • For supply and signal cables in 4 … 20 mA circuits... -
Page 5: Installation And Operation In The Usa And Canada
National Electrical Code (NEC - NFPA 70) (USA). Installations in Canada shall comply with the relevant requirements of the Canadian Electrical Code (CEC Part I) (Canada). B62-36G • For supply and signal cables in 4 … 20 mA circuits... -
Page 6: Product Description
Such voltage surges can cause damage to sensors and controllers. The VEGA overvoltage arrester reduces voltage surges on the supply or signal cables to a safe level. They are designed for mounting on B62-36G • For supply and signal cables in 4 … 20 mA circuits... -
Page 7: Packaging, Transport And Storage
Avoiding mechanical shock and vibration • Storage and transport Storage and transport temperature see chapter "Technical data - temperature Ambient conditions" • Relative moisture 20 … 85 % B62-36G • For supply and signal cables in 4 … 20 mA circuits... -
Page 8: Mounting Instructions
Carrier rail Fig. 3: Mounting on carrier rail according to EN 50 035 (C-rail) 35 x 7.5 mm Carrier rail Installation procedure Proceed as follows: 1. Loosen fixing screw B62-36G • For supply and signal cables in 4 … 20 mA circuits... -
Page 9: Mounting In Housing
Make sure when mounting that the cable glands point downward. Thus avoids water ingress. Fig. 5: Mounting in Aluminium housing Overvoltage protection Pressure compensation Ground terminal B62-36G • For supply and signal cables in 4 … 20 mA circuits... - Page 10 (low impedance) with the potential equalization line (PA). The wire cross-section must be at least 2.5 mm , the cable must be as short as possible. B62-36G • For supply and signal cables in 4 … 20 mA circuits...
-
Page 11: Connecting To Power Supply
6. Tighten the compression nuts of the cable entry glands. The seal ring must completely encircle the cable 7. Tighten screws of the housing cover The electrical connection is finished. B62-36G • For supply and signal cables in 4 … 20 mA circuits... -
Page 12: Wiring Plan
Potential equalisation Wiring plan - Sensor protection A1+A2- IP 20 E1+E2- Fig. 8: Wiring plan B62-36G - Sensor protection (non-Ex applications) Sensor Overvoltage protection Controller/PLC Potential equalisation B62-36G • For supply and signal cables in 4 … 20 mA circuits... - Page 13 5 Connecting to power supply Wiring plan - controller protection A1+A2- IP 20 E1+E2- Fig. 9: Wiring plan B62-36G - Controller protection (non-Ex applications) Sensor Overvoltage protection Controller/PLC Potential equalisation B62-36G • For supply and signal cables in 4 … 20 mA circuits...
-
Page 14: Diagnostics And Servicing
Print the generated instrument return form. Clean the instrument and pack it damage-proof. Send the printed instrument return form and possibly a safety data sheet together with the device. You will find the address for the return on the generated instrument return form. B62-36G • For supply and signal cables in 4 … 20 mA circuits... -
Page 15: Dismount
If personal data is stored on the old device to be disposed of, delete it before disposal. If you have no way to dispose of the old instrument properly, please contact us concerning return and disposal. B62-36G • For supply and signal cables in 4 … 20 mA circuits... -
Page 16: Certificates And Approvals
DIN EN ISO 14001. Help us to meet these requirements and observe the environmental instructions in the chapters "Packaging, transport and storage", "Dis- posal" of this instructions manual. B62-36G • For supply and signal cables in 4 … 20 mA circuits... -
Page 17: Supplement
Moisture 5 … 95 % (non-condensing) Electrical protective measures Protection rating Ʋ unassembled IP20 Ʋ In Aluminium or plastic housing IP65 Reference temperature 25 °C (77 °F). B62-36G • For supply and signal cables in 4 … 20 mA circuits... -
Page 18: Dimensions B62-36G
9 Supplement Dimensions B62-36G Overvoltage protection 52 mm 25 mm (2.05") (0.98") Fig. 10: Dimensions B62-36G B62-36G • For supply and signal cables in 4 … 20 mA circuits... - Page 19 77 mm 160 mm (3.03") (6.30") 130 mm (5.12") 72 mm 116 mm (2.84") (4.57") M 20 x 1,5 Fig. 11: Dimensions B62-36G Plastic housing Aluminium housing B62-36G • For supply and signal cables in 4 … 20 mA circuits...
-
Page 20: Industrial Property Rights
Les lignes de produits VEGA sont globalement protégées par des droits de propriété intellec- tuelle. Pour plus d'informations, on pourra se référer au site www.vega.com. VEGA lineas de productos están protegidas por los derechos en el campo de la propiedad indus- trial. Para mayor información revise la pagina web www.vega.com. - Page 21 Notes B62-36G • For supply and signal cables in 4 … 20 mA circuits...
- Page 22 Notes B62-36G • For supply and signal cables in 4 … 20 mA circuits...
- Page 23 Notes B62-36G • For supply and signal cables in 4 … 20 mA circuits...
- Page 24 Subject to change without prior notice © VEGA Grieshaber KG, Schiltach/Germany 2024 VEGA Grieshaber KG Am Hohenstein 113 Phone +49 7836 50-0 77761 Schiltach E-mail: info.de@vega.com...
