QUICK START GUIDE

Advertisement

loading
Need help?

Need help?

Do you have a question about the TONEX ONE and is the answer not in the manual?

Questions and answers

Related Manuals for IK Multimedia TONEX ONE

Summary of Contents for IK Multimedia TONEX ONE

  • Page 1 QUICK START GUIDE...

  • Page 2: Main Operation

    MAIN OPERATION Edit main parameters Edit BASS, MID, TREBLE and VOLUME* by rotating the micro and main knobs. *The volume knob edits the model volume or the compressor’s make-up gain when the compressor is set to post.
  • Page 3 MAIN OPERATION Edit alternative parameters 1. Press ALT (the micro knobs and ALT LED start blinking). 2. Edit GATE threshold, Compression, Reverb and GAIN by rotating the micro and main knobs.
  • Page 4 MAIN OPERATION Footswitch Press the footswitch to toggle between preset A and B or to bypass the pedal, depending on the play mode. Hold the footswitch to enable the Tuner.
  • Page 5 The dual mode (default) allows to switch between Preset A and Preset B by pressing the footswitch. Stomp mode The stomp mode is perfect if you need to use TONEX ONE as a stomp. Use it as a boost/overdrive/distortion/fuzz pedal and bypass it using the footswitch.

  • Page 6: Global Setup

    GLOBAL SETUP To access the global setup, hold ALT for 6 seconds. Changing mode Rotate the BASS micro knob fully counter-clockwise to set the pedal in dual mode. Rotate the BASS micro knob fully clockwise to set the pedal in stomp mode.
  • Page 7 GLOBAL SETUP Global cabinet bypass Rotate the MID micro knob fully counter- clockwise to have the cabinet active on all presets. Rotate the MID micro knob fully clockwise to bypass the cabinet on all presets. Input trim Use the TREBLE micro knob to set your input level using its LED color as metering.
  • Page 8 GLOBAL SETUP Global volume Rotate the main knob while in global setup to set the pedal’s global volume.
  • Page 9 20 PRESETS INSIDE Browsing mode Press the footswitch + ALT to access the browsing mode. When in browsing mode, the 3 micro knobs refer to the three presets slots. BASS – Dual mode, preset A MID – Dual mode, preset B TREBLE – Stomp mode preset After the first blink, each knob will display the color of each related preset.
  • Page 10 20 PRESETS INSIDE Once in browsing mode, the blinking micro knob indicates the selected preset slot. To change the preset loaded in the selected slot, turn the corresponding micro knob. The micro knob will change color according to the selected preset. You can also use the volume/gain knob to adjust the selected preset volume/ gain using ALT to toggle between the...

  • Page 11: Other Features

    OTHER FEATURES Safe mode Hold ALT for 3 seconds to access the safe mode. In this mode, the pedal is protected from unwanted editing while performing. Hold ALT for 3 seconds to disable the safe mode. Tuning modes Hold the footswitch to access the tuner. While the tuner is active, press ALT to toggle between mute and thru tuning modes.
  • Page 12 ToneNET TONEX for Mac/PC lets you browse among 25,000+ free Tone Models and Premium Collections to transfer to TONEX ONE and expand your Tone Model locker. Edit, transfer and backup The librarian function inside TONEX for Mac/PC lets you edit all advanced...
  • Page 14 REGISTER Register now TONEX ONE to: • Activate your warranty • Get enhanced app features • Get JamPoints discount on IK products Register here: ikregister.com...
  • Page 15 Latest revision: 2024/04/12 Version: 1.0 Revision: 4 IK Multimedia Production srl Via dell’Industria, 46 - 41122 Modena, Italy Phone: +39 059 285496 - CF/PI: IT02359550361 - SDI: M5UXCR1 IK Multimedia US, LLC 590 Sawgrass Corporate Pkwy. - Sunrise, FL 33325...
