- Page 1 ™ Outdoor PowerRACK User Manual TYPE 1 Indoor or TYPE 3R Rainproof TYPE 3R Rainproof TYPE 1 Indoor or TYPE 3R Rainproof TYPE 3R Rainproof LM-ODR - Rev.000...
-
Page 2: Table Of Contents
Lex Products Outdoor PowerRACK. All concepts and ideas are the sole Step 1: Placement and Inspection of the property of Lex Products and are not to Outdoor PowerRACK PDU be duplicated or utilized in any manner without written permission. -
Page 3: Introduction
Inspect for signs of damage to wiring devices, device covers or circuit breakers b. Open and close the hinged breaker windows to ensure that they open and close properly c. If there is any damage to the Outdoor PowerRACK, contact Lex Products Technical Services toll free at 800.643.4460 or email info@lexproducts.com... - Page 4 • Front and Back panels are recessed for added protection during transport and storage Outdoor Rack Base • Skid base elevates receptacles above the ground while permitting secure lifting via forklift Contact Lex Products: 800.643.4460 info@lexproducts.com...
-
Page 5: Setting Up The Outdoor Power Distribution Unit (Pdu)
Outdoor PowerRACK™ SETTING UP THE OUTDOOR POWER DISTRIBUTION UNIT (PDU) Set up of the Lex Products Outdoor Power Distribution Rack is to be performed by qualified personnel only Step 1: Placement and Inspection of the Outdoor PowerRACK PDU 1. The Lex Products Outdoor PowerRACK is cULus Listed NEMA Type 3R for outdoor use 2. -
Page 6: Step 3: Making And Breaking Connections On Outdoor Powerrack
4. Repeat steps 2 and 3 for the remaining circuit breakers NOTE: If the circuit breaker cannot be energized or trips, check the system for continuity, short circuits and overload. Make the necessary corrections before proceeding Contact Lex Products: 800.643.4460 info@lexproducts.com... -
Page 7: Adjusting The Circuit Breakers
OPEN / OFF position before being adjusted. On (I) / Off (O) Switch DIP Switches Figure 3.2: DIP Switches DIP Switch “L” Short/Instant Delay Neutral Sensing Contact Lex Products: 800.643.4460 info@lexproducts.com I1 = In x (0.4+ In x ( Σ... -
Page 8: 240 - 600 Amperage Circuit Breaker
Configuration I=6I1 240 Amps 432 Amps PR221DS 264 Amps 456 Amps 288 Amps 480 Amps 312 Amps 504 Amps 336 Amps 528 Amps 360 Amps 552 Amps 384 Amps 576 Amps 408 Amps 600 Amps Contact Lex Products: 800.643.4460 info@lexproducts.com... -
Page 9: 160 - 400 Amperage Circuit Breaker
Configuration I=6I1 160 Amps 288 Amps PR221DS 176 Amps 304 Amps 192 Amps 320 Amps 208 Amps 336 Amps 224 Amps 352 Amps 240 Amps 368 Amps 256 Amps 384 Amps 272 Amps 400 Amps Contact Lex Products: 800.643.4460 info@lexproducts.com... -
Page 10: 100 - 250 Amperage Circuit Breaker
Configuration I=6I1 PR221DS 100 Amps 180 Amps 110 Amps 190 Amps 120 Amps 200 Amps 130 Amps 210 Amps 140 Amps 220 Amps 150 Amps 230 Amps 160 Amps 240 Amps 170 Amps 250 Amps Contact Lex Products: 800.643.4460 info@lexproducts.com... -
Page 11: 60 - 150 Amperage Citrcuit Breaker
Configuration I=6I1 PR221DS 60 Amps 108 Amps 66 Amps 114 Amps 72 Amps 120 Amps 78 Amps 126 Amps 84 Amps 132 Amps 90 Amps 138 Amps 86 Amps 144 Amps 102 Amps 150 Amps Contact Lex Products: 800.643.4460 info@lexproducts.com... -
Page 12: Troubleshooting Guide
In the case that interior of the Outdoor PowerRACK needs to be accessed, do not open the top of the rack. All internal access is to be from the side panels. To maintain cULus Listing, contact Lex Products before opening the unit. -
Page 13: How To Check An Outdoor Rack For Short Circuits
(white) Cam-type connector and the other Cam-type connectors 7. If continuity is detected, there is a short circuit present a. Contact Lex Products if a short circuit is detected No Power at Receptacles: 1. Ensure that connections are in place and tight 2. -
Page 14: Replacement Labels
Replacement Labels Below are replacement labels that are consitant accros various Outdoor Rack configurations. For input, output and breaker label replacements, contact your Lex representative with the part number and serial number of the Outdoor Rack requiring replacement labels. PN: LBL-0001... - Page 15 500 lbs. Year of Development: 2023 The Lex Products Outdoor PowerRACK units can be lifted by crane or fork lift. Crane Lift • Only lift using (4) straps, (2) per side handlebar, for any crane lift • Ensure the load is free to move •...
-
Page 16: Technical Support
H: 45.337 in. x W: 30.50 in. x D: 31.50 In. TECHNICAL SUPPORT Lex Products is available to help answer any installation or operation inquiries. For any questions or technical advice, please call Technical Services 24 hours per day, 7 days per week at 800.643.4460 or email INFO@lexproducts.com.
