- Page 1 WeldingRACK ™ 6-Pack Welder Power Distribution Station Installation & User Manual • Distribute Power to Six Standard Welders • Provides 120 VAC Convenience Power • Stores & Transports Welders in a Robust, Convenient Rack • Made in the USA LM-WR6 - Rev. 001...
-
Page 2: Table Of Contents
Welcome the WR6 WeldingRACK, including welder installation. Important Safeguards The design of the Lex Products WR6 WeldingRACK enables power management of up to six welder packs and utility power. Product Components Creating a power distribution center on job side allows for... -
Page 3: Important Safeguards
- Read this first All equipment manufactured by Lex Products is designed, built and tested to strict safety regulations. Observe all precautions when installing this unit. By following the safety warnings listed below and elsewhere within this guide, you can ensure the safe and proper installation and operation of these units. -
Page 4: Product Components
Duplex Receptacles • Easy Access to Neutral Bar for Work Cable Connection Safety Interlock System is Rugged Casters and Forklift designed to prevent the input Pockets provide mobility voltages selection from being adjusted while powered Contact Lex Products: 800.643.4460 info@lexproducts.com... -
Page 5: Product Dimensions / Weight
WeldingRACK™ 6-Pack Welder Power Distribution Station Product Dimensions / Weight NOTES: • Dimension: 65 H x 48.675 W x 29.500 D • Unpopulated Rack Weight: 497 lbs. (approx.) • All dimensions in inches Contact Lex Products: 800.643.4460 info@lexproducts.com... -
Page 6: Compatible Hole Pattern For Installation
WeldingRACK™ 6-Pack Welder Power Distribution Station Compatible Hole Pattern for Installation Contact Lex Products: 800.643.4460 info@lexproducts.com... -
Page 7: Installing Welding Units
• Each unit is to be bolted to the WR6 WeldingRACK with four bolts – *(Bolts are not included) Welder Pack Mounting Pattern Miller 350 XMT Welder 8.687” W x 15.750” D Lincoln K427-1 Welder 6.00” W x 18.304” D Contact Lex Products: 800.643.4460 info@lexproducts.com... -
Page 8: Lifting The Weldingrack™ - Eyelets
• Eyelets are designed to lift a fully loaded rack. • Do not exceed the maximum load capacity when moving the rack using the four eyelets • Lifting chain or wire rope of at least 72 inches (2m) is required for lifting the rack Contact Lex Products: 800.643.4460 info@lexproducts.com... -
Page 9: Lifting The Weldingrack™ - Forklift
• Rack weight is approximately 497 lbs. not populated • Do not exceed the maximum load capacity of the fork lift when moving the rack using the fork list pockets • See page 5 for fork lift pocket dimensions Contact Lex Products: 800.643.4460 info@lexproducts.com... -
Page 10: Electrical Connections
• The serial number and rating information for this product is located on the back panel of the distribution unit • Use rating label to determine input power requirements and/or rated output • For future reference, write serial number in space provided on the back cover of this manual Contact Lex Products: 800.643.4460 info@lexproducts.com... -
Page 11: Input Power Connection
• Install to plug manufacturer’s instructions Voltage Selection • The WeldingRACK WR6 is designed to operate with a 600VAC or 480VAC input • Voltage selector switch and main breaker are located on the front of the power distribution unit under a clear protective window panel •... -
Page 12: Overload Protection
(3) 20A Branch Breakers for GFCI Duplex Receptacles Overload protection box is located on the right Remove the cover plate to access the breaker facing side of the enclosure and set breaker to ON position Contact Lex Products: 800.643.4460 info@lexproducts.com... -
Page 13: Troubleshooting
8. Transformer Selector Switch is turned to proper voltage 9. Transformer circuit breaker is in ON position (under side panel) GFCI Duplex Receptacle ‘RESET’ Button Circuit Breakers for GFCI Duplex Receptacles Transformer Selector Switch Transformer Circuit Breaker Contact Lex Products: 800.643.4460 info@lexproducts.com... - Page 14 Check for short circuits in the cabling or load device and correct as needed 5. Transformer Selector Switch is turned to proper voltage 6. Transformer circuit breaker is in ON position (under side panel 50A Twistlock Receptacle Transformer Selector Switch Transformer Circuit Breaker Contact Lex Products: 800.643.4460 info@lexproducts.com...
-
Page 15: Maintenance
SAFETY - Disconnect power before servicing Perform the following routine operation every three months: • Clean off WeldingRACK WR6 with a cloth to remove work site debris • Inspect WeldingRACK WR6 for signs of damage, rust corrosion and oxidation • Replace damaged or unreadable labels •... -
Page 16: Product Specifications
Pacoima, CA 91331 800.643.4460 Shelton CT 06484 Davie, FL 33331 203.363.3738 Suite Q Lex Products logo and lexproducts.com are 954.888.1024 818.768.4474 203.363.3742 Fax trademarks or registered trademarks of Lex Products in the United States, other countries, or both. 954.888.1026 Fax 818.768.4040 Fax...
