BLADE
STEP 1
9 0°
Reserve a 1.6" (4 cm) long network cable on the stripping blade, press the handle and rotate
the hand tool one circle to smoothly peel off the network cable jacket.
STEP 2
Insert the network cable onto the keystone according to the color code on the keystone.
STEP 3
Place the pre pressed network cable keystone into the hand tool from top to bottom, paying
attention to the direction of the keystone.
STEP 4
Press down the handle of the hand tool to fully engage the module and wire. Lift up the
handle of the hand tool to remove the module that has already been wired and
cut.
1.6" (4 cm)
1.6" (4 cm)
1.6" (4 cm)
1.6" (4 cm)
1.6" (4 cm)
1.6" (4 cm)
9 0°
1.6" (4 cm)
9 0°
9 0°
1.6" (4 cm)
9 0°
1 8 0°
9 0°
9 0°
1.6" (4 cm)
9 0°
90°
9 0°
UTP
UTP
JACK PIN DESIGNATIONS
TIA/EIA T568A
1
White/Green
2
Green
3
White/Orange
6
Orange
4
Blue
1.6" (4 cm)
5
White/Blue
1 8 0°
1 8 0°
7
White/Brown
1 8 0°
8
1.6" (4 cm)
Brown
1 8 0°
1 8 0°
1 8 0°
1 8 0°
9 0°
1 8 0°
1 8 0°
UTP
UTP
UTP
UTP
UTP
UTP
UTP
UTP
Insert the network cable onto the keystone according to the color code on the keystone.
Place the pre pressed network cable keystone into the hand tool from top to bottom, paying
attention to the direction of the keystone.
Press down the handle of the hand tool to fully engage the keystone and wire cap.
User's Manual
TIA/EIA T568B
White/Orange
Orange
White/Green
Green
Blue
White/Blue
White/Brown
Brown
1 80°
UTP
STEP 2
STEP 3
STEP 4
