ALER-9000 CONTROLLER
GENERAL ............................................................................... 2
Trademark Information .......................................................... 2
About this Guide ....................................................................... 2
Product Documentation ........................................................ 2
Document Content .................................................................. 2
Related Documentation......................................................... 2
General Information............................................................ 2
ALER-9000 Controller ..................................................... 2
WPM-8000 ........................................................................... 3
Items Included with the Controller .................................... 3
Material and Tools Requirements...................................... 3
Precautions: ................................................................................ 4
Physical Mounting............................................................... 5
Environmental Requirements ............................................. 5
Mounting on a DIN Rail.......................................................... 5
Tab Mounting Dimensions ................................................... 6
® U.S. Registered Trademark
Copyright © 2023 Honeywell Inc. • All Rights Reserved
MOUNTING AND WIRING GUIDE
Wiring and Power Up........................................................... 7
RS485 Wiring ............................................................................. 8
RS485 bias Switches........................................................ 8
Ethernet Wiring ......................................................................... 9
Earth Ground and Power....................................................... 9
Power up and Initial Checkout ............................................ 10
Initiating a Controller Shutdown........................................ 10
ALER-9000 Status LEDs .................................................... 10
RS485 LEDs ............................................................................... 11
STAT (Status) LED.................................................................... 11
BEAT (Heartbeat) LED ........................................................... 11
PRI, SEC (Ethernet) LEDs ..................................................... 12
SHUT DOWN switch and DEBUG port............................. 12
31-00662-01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ALER-9000 and is the answer not in the manual?

Questions and answers

Related Manuals for ALERTON ALER-9000

Summary of Contents for ALERTON ALER-9000

  • Page 1: Table Of Contents

    Power up and Initial Checkout ..........10 Initiating a Controller Shutdown........10 General Information............2 ALER-9000 Controller ............. 2 ALER-9000 Status LEDs ............ 10 WPM-8000 ................3 RS485 LEDs ................11 Items Included with the Controller ........3 STAT (Status) LED..............11 Material and Tools Requirements........

  • Page 2: General

    4Mbit FRAM documents. Storage 8GB (eMMC) • Alerton ALER-9000 – Quick Start Guide - 31-00663- 8GB removable microSD (optional) • Alerton ALER-9000 – Install and Startup Guide - 31- Ethernet Two 10/100/1000 Mbit Ethernet ports 00661-01 • Niagara Platform Guide RS485...

  • Page 3: Wpm-8000

    • Two 3-position RS485 connector plugs Protocol • One 2-position power connector plug • Grounding wire Expansion Module Max Components • ALER-9000 Controller Quick Start Install Guide 31- NPB-8000–LON 00655-01 NPB-8000–232 Material and Tools Requirements NPB-8000–2X-485 The following material and tools are needed.

  • Page 4: Precautions

    ALER-9000 MOUNTING AND WIRING GUIDE Future option module types may have additional For the shutdown procedure refer to “Initiating a con- maximum limits within the 4–total option per controller troller shutdown.” Accessing the card uses the space limit. behind the mounting base.

  • Page 5: Physical Mounting

    ALER-9000 MOUNTING AND WIRING GUIDE PHYSICAL MOUNTING Mount the controller in a location that allows clearance for wiring, servicing, and module removal. Fig. 4 Mounting dimensions of controller and option modules Horizontal mounting (as shown) is required to achieve maximum heat dissipation and meet the operating temperature upper limit requirement.

  • Page 6: Tab Mounting Dimensions

    3. Push down and in on the unit, fastening it to the rail. 4. Push the locking clip up to secure the controller. 5. To mount any option module onto the DIN rail, slide Fig. 7 ALER-9000 controller tab mounting the module firmly into the controller’s connector to dimensions seat.

  • Page 7: Wiring And Power Up

    ALER-9000 MOUNTING AND WIRING GUIDE WIRING AND POWER UP When correctly mounted, the top of the controller contains the COM ports and the bottom of the controller the Ethernet ports. Fig. 9 Power and field communications ports Table 6. Power and field communications ports...

  • Page 8: Rs485 Wiring

    ALER-9000 MOUNTING AND WIRING GUIDE RS485 Wiring On the controller’s top side, two RS485 ports operate as COM1 and COM2. Each port is capable of up to 115,200 baud, and uses a three-position screw terminal connector. Fig. 10 RS–485 wiring example Table 7.

  • Page 9: Ethernet Wiring

    The factory-default IP address for PRI is 192.168.1.140. Callout Description The subnet mask is 255.255.255.0. By default, the SEC (LAN2) port is disabled. Refer to the ALER-9000 Install Ground and Startup Guide for details on the software configuration of the Ethernet ports.

  • Page 10: Power Up And Initial Checkout

    • “BEAT (Heartbeat) LED” and Receive (RX, Green). Refer to “RS485 LEDs.” For what to do next, refer to the “ALER-9000 Install and Startup Guide”, which explains how to commission a STAT (Green): Remains lit. Refer to “STAT new ALER-9000 controller, that is, how to install the (Status) LED.”...

  • Page 11: Rs485 Leds

    Niagara daemon (niagarad), and station. If the status LED does not light while power is applied, contact System Engineering for technical support. Table 11. ALER-9000 BEAT (heartbeat) LED blink pattern BEAT (Heartbeat) LED In normal operation, the yellow heartbeat BEAT LED...

  • Page 12: Pri, Sec (Ethernet) Leds

    ALER-9000 MOUNTING AND WIRING GUIDE PRI, SEC (Ethernet) LEDs 115200, 8, N, 1 (baud rate, data bits, parity, stop bits). For more details, refer to the ALER-9000 Install and Two LEDs for each of the two LAN ports flash green and Startup Guide.
  • Page 13 ALER-9000 MOUNTING AND WIRING GUIDE The material in this document is for information purposes only. The content and the product described are subject to change without notice. Honeywell makes no representations or warranties with respect to this document. In no event shall Honeywell be liable for technical or editorial omissions or mistakes in this document, nor shall it be liable for any damages, direct or incidental, arising out of or related to the use of this document.
