Sennheiser ME 64 Technical Data

ME 64
Microphones |

General Description

The ME 64 is a cardioid microphone head designed for use with the K6 and
K6P powering modules. It has a very wide range of applications in cluding
reporting, interviews, dubbing, live sound reinforcement and recording
applications. Matt black, anodised, scratch-resistant finish.
Pictured with K6 powering module and cable (available separately)

Features

Cardioid pick-up pattern
Excellent directivity across whole frequency range
Very good feedback rejection
Effective rejection of incidental rear noise
High speech clarity
High maximum sound pressure level
Wide frequency range
Integrated pop filter
Delivery includes: ME 64

Recommended Accessories

MZW 64 foam windshield
MZW 64 pro foam windshield
Back-Electret Microphone Head Suitable
for K6 and K6P Powering Modules
Cat. No. 003703
Cat. No. 003711
Technical Data
Pick-up pattern ...................................................................... cardioid
Frequency response .................................40 – 20,000 Hz ± 2.5 dB
Sensitivity
(free field, no load) (1 kHz) ............................ 31 mV/Pa ± 2.5 dB
Nominal impedance ............................................... 200 Ω (with K6)
Min. terminating impedance ...................................1 kΩ (with K6)
Equivalent noise level
A-weighted (DIN IEC 651)........................................................ 16 dB
CCIR-weighted (CCIR 468-3).................................................... 25 dB
Max. SPL (1 kHz)...............................................130 dB (THD = 1 %)
Dimensions .............................................................Ø 22.5 x 106 mm
Weight ............................................................................................35 g

Profile

Cardioid microphone head suitable for K6 and K6P powering
modules. Frequency response 40 – 20,000 Hz ± 2.5 dB, sensi-
tivity (free field, no load) 31 mV/Pa ± 2.5 dB at 1 kHz, nomi-
nal impedance 200 Ω (with K6), min. terminating impedance
1 kΩ (with K6), equivalent noise level A-weighted 16 dB,
CCIR-weighted 25 dB, max. SPL 130 dB at 1 kHz (THD = 1 %),
dimensions Ø 22.5 x 106 mm, weight 35 g.
Cat. No. 003282
