Sennheiser ME 62 Datasheet

ME 62
Microphones |

General Description

The ME 62 is an omni-directional microphone head suitable for K6 and
K6P powering modules. It can be used for reporting, discussions and inter-
views. The ME 62 is particularly suitable for good reproduction of 'room'
ambience and 'spaced omni' stereo recording. Matt black, anodised,
scratch-resistant finish.
Pictured with K6 powering module and cable (available separately)

Features

Omni-directional pick-up pattern
Minimal inherent self-noise
Excellent rejection of rumble, wind and handling noise
Wide frequency response
High maximum sound pressure level
Integral pop filter
Delivery includes: 1 ME 62

Recommended Accessories

MZW 64 foam windshield
MZW 64 pro foam windshield
Back-Electret Microphone Head Suitable
for K6 and K6P Powering Modules
Cat. No. 003703
Cat. No. 003711

Technical Data

Pick-up pattern ....................................................... omni-directional
Frequency response .................................20 – 20,000 Hz ± 2.5 dB
Sensitivity
(free field, no load) (1 kHz) ............................ 31 mV/Pa ± 2.5 dB
Nominal impedance ............................................... 200 Ω (with K6)
Min. terminating impedance ...................................1 kΩ (with K6)
Equivalent noise level
A-weighted (DIN IEC 651)........................................................ 15 dB
CCIR-weighted (CCIR 468-3).................................................... 27 dB
Max. SPL (1 kHz)...............................................130 dB (THD = 1 %)
Dimensions ............................................................... Ø 22.5 x 94 mm
Weight ............................................................................................30 g

Profile

Omni-directional microphone head suitable for K6 and K6P
powering modules. Frequency response 20 Hz – 20,000 Hz
± 2.5 dB, sensitivity (free field, no load) 31 mV/Pa ± 2.5 dB at
1 kHz, nominal impedance 200 Ω (with K6), min. terminating
impedance 1 kΩ (with K6), equivalent noise level A-weighted
15 dB, CCIR-weighted 27 dB, max. SPL 130 dB at 1 kHz (THD =
1 %), dimensions Ø 22.5 x 94 mm, weight 30 g.
Cat. No. 003281
