Sennheiser ME 35 Product Sheet

ME 34 (Nx)/ME 35 (Nx)/ME 36 (Nx)
Microphones |

General Description

The versatile ME 34, ME 35 and ME 36 back-electret condenser micro-
phone heads can be combined with MZH goosenecks and various other
accessories. They are suitable for a wide range of applications including
conference, public address, studio, broadcast, churches and other places
of worship and television production. New variants Nextel: ME 34 Nx, ME
35 Nx and ME 36 Nx.
ME 34 ME 35
ME 36
MZW 34*
MZW 34 Pro**
* standard, included in the delivery

Features ME 34 and ME 35

ME 34: cardioid
�
ME 35: super-cardioid
�
Rugged, matt black metal housing with a special anti-reflective coating
�
High sound quality
�
Low equivalent noise level
�

Features ME 36

Super-cardioid/lobar pick-up pattern
�
Rugged, matt black metal housing with a special anti-reflective coating
�
High rejection of lateral sounds
�
Excellent sound quality
�
Exceptionally low equivalent noise level
�
Installed Sound
MZW 36*
MZW 36 Pro**
** optional velourised windshield
Cat. No. 005060
Cat. No. 005063
Cat. No. 005065
Cat. No. 500816
Cat. No. 500817
Cat. No. 500818

Technical Data

(measured with MZH gooseneck)
Acoustic principle
ME 34 / ME 35 ....................................... pressure gradient receiver
ME 36 .................................................... pressure gradient receiver/
Pick-up pattern
ME 34 ........................................................................................cardioid
ME 35 ............................................................................super-cardioid
ME 36 .................................................................super-cardioid/lobar
Frequency response
ME 34 / ME 36 ........................................................... 40 – 20,000 Hz
ME 35 .......................................................................... 50 – 20,000 Hz
Sensitivity (free field, no load)
ME 34 / ME 35 .....................................................................10 mV/Pa
ME 36 ....................................................................................18 mV/Pa
Electrical impedance ...................................................................50 �
Min. terminating impedance ..................................................... 1 k�
Equivalent noise level
ME 34 / ME 35 .................................................. 26 dB-A, 37 dB-CCIR
ME 36 ................................................................. 23 dB-A, 34 dB-CCIR
Power supply ........................................... 12–48 V phantom power
Dimensions
ME 34 / ME 35 ..............................................................Ø 12 x 18 mm
ME 36 ...........................................................................Ø 8.2 x 96 mm
Weight
ME 34 .............................................................................................8.5 g
ME 35 .............................................................................................9.5 g
ME 36 .............................................................................................17 g
Connector .................................................. special coaxial connector

Accessories

MZW 34
�
MZW 36
�
MZW 34 Pro
�
MZW 36 Pro
�
ME 34/ME 35
ME 34
ME 35
ME 36
ME 34 Nx
ME 35 Nx
ME 36 Nx
interference tube
Cat. No. 086740
Cat. No. 083297
Cat. No. 005067
Cat. No. 005069
/ME 36
