Sennheiser I40-C Product Sheet

i40-C
Microphones |
Kit Includes:
ME 34 Capsule
MZH 3040 Gooseneck
MZT 30 XLR Table Mount
MZS 31 Shock Mount
General Description
Sennheiser's modular Installed Sound Series microphones kits for podium,
hanging, boundary layer and table stand applications facilitate all possible
installation configurations at affordable prices. At the heart of the series are
three superbly engineered capsules: the ME 34 cardioid, the ME 35 super cardioid
and the unique lobar-patterned ME 36 mini shotgun. Each capsule can interface
with three different goosenecks: the 15 cm MZH 3015 (6"), the 40 cm MZH 3040
(15.75") and the dual flex 40 cm MZH 3042 (15.75"), all designed to maintain
proper capsule placement. Each system requires 12-48 volt phantom power.
All contact points are gold plated and corrosion resistant. All components have
anti-reflective matte black surfaces.
ME 34
Polar Pattern
MZH 3040
Installed Sound
.69"
[17.53mm]
Ø.48"
[12.19mm]
1.95"
15.47"
[49.5mm]
[392.9mm]
2.96"
10.56"
[75.2mm]
[268.2mm]
Ø.74"
[18.8mm]
ME34
MZH3040
MZS31
MZT30
Cardioid patterned condenser microphone capsule. Its wide
cardioid pattern is excellent for universal miking applications.
Technical Data
Acoustic operating principle
Pick-up pattern
Frequency response
Sensitivity (free field, no load) 10 mV/Pa
Electrical impedance
Min. terminating impedance
Equivalent noise level
Power supply
Dimensions
Weight
Connector
Frequency Response Graph
The MZH 3040 is a metal gooseneck for use with the ME 34, ME
35 and ME 36 microphone capsules and is 40 cm (15.75") in
length. It features a rugged anti-reflective matte black coating
and uses a balanced floating XLR-3 connector with standard
Ø.32"
polarity.
[8.1mm]
Pressure gradient transducer
Cardioid
40–20,000 Hz
50 Ω
1 K Ω
26 dB-A
37 dB-CCIR
P 12–P 48
.47" x .71" (11.93 x 18.03 mm)
.30 oz.
XLR-3
i40-C
