Modular installed sound series microphones kits

Advertisement

i42-L
Microphones |
Kit Includes:
ME 36 Capsule
MZH 3042 Gooseneck
Mzt 30 Xlr Table Mount
Mzs 31 Shockmount

General Description

Sennheiser's modular Installed Sound Series microphones kits for podium,
hanging, boundary layer and table stand applications facilitate all possible
installation configurations at affordable prices. At the heart of the series are
three superbly engineered capsules: the ME 34 cardioid, the ME 35 super cardioid
and the unique lobar-patterned ME 36 mini shotgun. Each capsule can interface
with three different goosenecks: the 15 cm MZH 3015 (6"), the 40 cm MZH 3040
(15.75") and the dual flex 40 cm MZH 3042 (15.75"), all designed to maintain
proper capsule placement. Each system requires 12-48 volt phantom power.
All contact points are gold plated and corrosion resistant. All components have
anti-reflective matte black surfaces.
ME 36
Ø.33"
[8.4mm]
Polar Pattern

MZH 3042

Ø.74"
[18.8mm]
Installed Sound
3.78"
[96.0mm]
"
.39
[9.9mm]
15.47"
[392.9mm]
2.96"
7.94"
[75.2mm]
[201.7mm]
1.95"
[49.5mm]
[49.5mm]
Lobar patterned mini shotgun condenser microphone capsule.
Provides added "reach"in miking applications.

Technical Data

Acoustic operating principle
Pick-up pattern
Frequency response
Ø.26"
Sensitivity (free field, no load) @1kHz 18 mV/Pa
[6.6mm]
Electrical impedance
Min. terminating impedance
Equivalent noise level
Power supply
Dimensions
Weight
Connector
Frequency Response Graph
The MZH 3042 is a dual bend metal gooseneck for use with the
.68"
ME 34, ME 35 and ME 36 microphone capsules and is 40 cm
[17.3mm]
(15.75") in length. It features a rugged anti-reflective matte
Ø.32"
[8.1mm]
1.95"
black coating and uses a balanced floating XLR-3 connector
with standard polarity.
ME36
MZH3042
MZS31
MZT30
Pressure gradient transducer/
interference tube transducer
Super-cardioid/lobar
40–20,000 Hz
50 Ω
1 KΩ
26 dB-A
37 dB-CCIR
P 12–P 48
.322" x 3.78" (8.178mm x 96.01mm)
.6 oz
XLR-3
i42-L
