INSTRUCTION MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the cardo SHOCK WAVE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ruroc cardo SHOCK WAVE

Summary of Contents for Ruroc cardo SHOCK WAVE

  • Page 1 INSTRUCTION MANUAL...
  • Page 2 2. If local law prohibits the use of headphones while riding, do not use. If you do not comply with this warning, Ruroc does not accept any liability. 3. Use of this product at a high volume for a long time may cause damage to your ears &...

  • Page 3: Warranty Information

    If a Ruroc product fails due to defects 2. Safe startup: be sure to use your in craftsmanship or materials, within product in a safe environment as...
  • Page 4 FITTING YOUR SHOCKWAVE 1. Remove the Snap-Fit Bluetooth cover on both sides of the helmet. Keep these covers stored securely should you wish to re-use them in the future. REMOVE 2. Insert Battery into side [A] by lining up the locators with slots in the battery cavity, press until it ‘CLICKS’.

  • Page 5: Connecting Your Speakers

    CONNECTING YOUR SPEAKERS Gently release the poppers on the cheek pads and remove them from the helmet. 2. Plug the Mic+Speaker cable [C] into the AUX jack port on the helmets left side (right side of below diagrams). 3. Plug the Speaker-only cable [D] into the AUX jack port on the helmets right side (left side of below diagrams)
  • Page 6 FITTING YOUR SPEAKERS Attach each of the Shockwave speakers where Velcro [E] is located (in the orientation shown in the diagram) 2. Attach the Shockwave Mic where Velcro [F] is located to the side of the chin vent (in the orientation shown in the diagram) 3.
  • Page 7 SHOCKWAVE CONTROLS SHOCKWAVE UNIT SELECT/ LED INDICATOR PHONE MEDIA VOLUME INTERCOM VOLUME UP DOWN BATTERY USB-C CHARGING PORT...
  • Page 8 ON/OFF Press both the Intercom Button and Media Button once to switch on the Shockwave system, you will hear a “Power On” message. OFF: Press both the Intercom Button and Media Button once to switch off the Shockwave system, you will hear a “Power Off”...

  • Page 9: Factory Reset

    FACTORY RESET To Factory Rest the Shockwave hold the Intercom Button and Media Button and Select/Phone Button for 5+ seconds, a voice message of ‘Reset’ will sound, and turn the system back onz as normal. CHARGING USB-C CHARGING PORT Plug the USB-C cable into the charging port, the LED will light up RED and stay static to indicate it is charging.

  • Page 10: Bluetooth Connection

    BLUETOOTH CONNECTION When connecting the Shockwave system to your device for the first time*, hold the SELECT/PHONE BUTTON** for 5 seconds until you hear ‘phone pairing’ 2. The LED will flash RED & BLUE as the Shockwave looks for a connection to the device. LED Red &...
  • Page 11 CARDO CONNECT APP Download Herunterladen Télécharger Downloaden Register Registrieren S'enregistrer Registreren Choose Language Sprache Auswählen Choisir Langue Taal Kiezen Update Software Software Aktualisieren Actualisation Du Logiciel Software Bijwerken...

  • Page 12: Volume Down

    GENERAL VOLUME UP VOLUME DOWN MUTE/UNMUTE MICROPHONE...

  • Page 13: Voice Assistant

    VOICE ASSISTANT...
  • Page 14 PAIRING PHONE 2 PAIRING *PHONE PAIRING MODE MUST BE INITIATED* GPS PAIRING *PHONE PAIRING MODE MUST BE INITIATED* BIKE PAIRING *PHONE PAIRING MODE MUST BE INITIATED*...
  • Page 15 CYCLE BACK TO PHONE PAIRING *PHONE PAIRING MODE MUST BE INITIATED* STOP DEVICE PAIRING...

  • Page 16: Radio Off

    RADIO Set Presets Voreinstellungen Festlegen Definir Les Prereglages Voorkeuzezenders Instellen RADIO ON RADIO OFF...
  • Page 17 NEXT PRESET PREVIOUS PRESET AUTO-TUNE x6 PRESETS...

  • Page 18: Next Track

    MUSIC MUSIC ON MUSIC OFF/PAUSE NEXT TRACK...

  • Page 19: Previous Track

    PREVIOUS TRACK START/STOP MUSIC SHARING SWITCH SOURCE RADIO/MUSIC...

  • Page 20: Answer Call

    PHONE ANSWER CALL ANY OF THESE 3 BUTTONS IGNORE CALL EITHER OF THESE 2 BUTTONS END CALL ANY OF THESE 3 BUTTONS...

  • Page 21: Redial Last Number

    REDIAL LAST NUMBER SPEED DIAL...
  • Page 22 DMC (DYNAMIC MESH COMMUNICATION) OPEN PUBLIC MODE INTERCOM GROUPING SUCCESS CLOSE PUBLIC MODE INTERCOM START DMC GROUPING...
  • Page 23 STOP DMC GROUPING MUTE DMC GROUP PRESS BOTH BUTTONS AT THE SAME TIME SHARE PHONE CALL WITH GROUP...
  • Page 24 START/STOP PASSENGER BLUETOOTH TO DMC GROUP PRESS BOTH BUTTONS AT THE SAME TIME START/STOP PRIVATE CHAT (PREDEFINED PARTNER) PRESS BOTH BUTTONS AT THE SAME TIME...

  • Page 25: Bluetooth Intercom

    BLUETOOTH INTERCOM SWITCH SOURCE DMC/BLUETOOTH START INTERCOM RIDER ‘A’ PAIRING START INTERCOM RIDER ‘B’ PAIRING...
  • Page 26 RETURN TO RIDER ‘A’ PAIRING STOP INTERCOM PAIRING START/SHOP SHARE PHONE CALL WITH BLUETOOTH INTERCOM CHANNEL (‘A’ OR ‘B’)
  • Page 27 BLUETOOTH INTERCOM – OPEN/CLOSE CHANNEL (A&B)
  • Page 28 Voice Commands - Always On! English • Answer • Ignore • "Hey Cardo, call" • "Hey Cardo, speed dial" • "Hey Cardo, redial number" • "Hey Cardo, music on" • "Hey Cardo, music off" • "Hey Cardo, next track" • "Hey Cardo, previous track"...
  • Page 29 Sprachbefehle - Immer An! Deutsch • Antworten • lgnorieren • "Hey Cardo, anruf beenden" • "Hey Cardo, kurzwahl" • "Hey Cardo, wahlwiederholung" • "Hey Cardo, musik an" • "Hey Cardo, music aus" • "Hey Cardo, titel vor" • "Hey Cardo, titel zurück"...
  • Page 30 Commandes vocales - Toujours activé! Français • Réponds • lgnore • "Hey Cardo, raccroche" • "Hey Cardo, numéro favori" • "Hey Cardo, rappelle le numéro" • "Hey Cardo, allume la musique" • "Hey Cardo, éteins la musique" • "Hey Cardo, morceau suivant"...
  • Page 31 Comandi vocali - sempre attivi! Italiano • Pronto • lgnora • "Ciao Cardo, termina chiamata" • "Ciao Cardo, selezione rapida" • "Ciao Cardo, ricomponi il numero" • "Ciao Cardo, accendi la musica" • "Ciao Cardo, spegni la musica" • "Ciao Cardo, traccia successiva"...

  • Page 32: Fcc Regulatory Compliance

    Class B digital device, pursuant to Part 15 of the FCC Rules. Hereby Ruroc Ltd declares that this product is in compliance with essential These limits are designed to provide requirements and other relevant reasonable protection against harmful provisions of Directive 2014/53/EU.

  • Page 33: Specification

    ATTENTION SPECIFICATION Installing equipment on the helmet is BLUETOOTH® VERSION: DUAL-MODE BT 5.3 WITH LE AUDIO a modification of the helmet, which may cause the helmet’s warranty to SUPPORT: fail or hinder the helmet's function. STAR-MC1 PROCESSOR, BECO This may cause danger in the event of COPROCESSOR accidents.
  • Page 34 CARDO CONNECT APP CARDOSYSTEMS.COM/UPDATE CARDOSYSTEMS.COM/SUPPORT RUROC.COM/SUPPORT...
