EN
BA30115-2-2 (10.22)
superrollo ST110-2 / ST115-2
Operating manual
This manual does not replace the enclosed manual for the tubular motor. Before
you begin, please read this manual through completely and follow all the safety
instructions.
Safety instructions
Incorrect use leads to an increased risk of
injury.
Never use defective or damaged devices.
◆
controllers with radio technology
Never use
◆
devices and systems with increased safety-relevant requirements or where
there is an increased accident risk. Applications of this kind require additional
Observe the respective statutory regulations for the
safety equipment.
installation of such systems.
Risk of fire and
explosion
Throwing a battery into a fire or hot oven or mechanically crushing
◆
or cutting a battery can lead to an explosion.
If the battery is placed in an environment with extremely high
◆
temperatures, this can lead to an explosion or a spill of flammable
liquid or flammable gas.
A battery exposed to extremely low air pressure can cause an explo-
◆
sion or the release of flammable liquids or gases.
Intended use
Only use the radio transmitters for the remote control of roller shutters.
Operating conditions
Only use the radio transmitters in dry rooms.
◆
The installation and operation of the radio system is only permitted
◆
for systems and devices where a malfunction in the transmitter or
receiver would not cause a danger to persons or property or where
this risk is already covered by other safety equipment.
Radio systems which transmit on the same frequency can cause
◆
interference.
Improper use
Using the radio transmitters for any other purpose than previously men-
tioned is not permissible.
for the remote control of
Determining the compatibility during initial commissioning
The ST110-2 and ST115-2 radio transmitters are compatible with two versions
of the superrollo radio tubular motors:
A) Use with superrollo RMxxM S/M B tubular motors
1.
Insert the batteries
2.
The control LED on the front flashes once
B) Use with superrollo RMxxM S/M F tubular motors
1.
Press the P2 button when inserting
the batteries
2.
The control LED on the
front flashes once
Changing the compatibility during operation
1.
Remove the batteries.
2.
Press the P2 button when inserting the batteries.
Information regarding use with superrollo RMXXM S/M B tubular motors
Unlike with the initial commissioning, the control LED then flashes twice.
Inserting/changing batteries
Only use the following battery type:
2 x 1.5 V - type AAA
Incorrect or leaking batteries can cause damage to the radio
transmitter.
An incorrectly inserted battery can cause damage to the radio transmitter.
◆
Never use two different battery types.
◆
Never use new and old batteries together.
◆
Take the batteries out of the remote control if it is not used for a longer
◆
period of time.
If a battery leaks, carefully wipe off the fluid in the battery compartment and
◆
insert new batteries.
1.
Remove the protective cover in the
direction of the arrow.
2.
If necessary, determine the compatibili-
ty with the tubular motor, see above.
3.
Insert the batteries into the battery
compartment with the right polarity.
4.
Insert the protective cover again.
P2
ATTENTION!
