  • Page 1 C575U LED BIKE Owner’s Manual...

  • Page 2: Table Of Contents

    STEP 7 Level the Bike ................ STEP 8 Seat Fore and Aft Adjustment ..........STEP 9 Seat Height Adjustment............STEP 10 How to Connect the Ground Wire ......... 5. UNDERSTAND THE C575U DISPLAY ........... DISPLAY Overview ................DISPLAY Specifications ............... DISPLAY Windows ................20 DISPLAY Keys ..................

  • Page 3: Introduction

    1. INTRODUCTION Congratulations on your purchase of one of the finest exercise products on the market today, the C575U upright exercise cycle. Constructed of high quality materials and designed for years of reliable usage, this product was made to become an integral part of your commercial fitness venue.

  • Page 4: Safety Precautions

    2. SAfETy PRECAUTIONS Your SportsArt bike was designed and built for optimum safety. However certain precautions apply whenever you use your bike. Please read the entire manual before assembly and operation. Also, please note the following safety precautions: ● Please read the instructions carefully and install the bike as instructed. ●...
  • Page 5 2. SAfETy PRECAUTIONS (CONTINUED) Caution If you feel any pain or abnormal sensation, STOP YOUR WORKOUT and consult your physician immediately. Work within your recommended exer- cise level. DO NOT work to exhaustion. Before beginning any exercise program, you should consult with your doc- tor.
  • Page 6 2. CONSIgNES DE SéCURITé • Votre vélo SportsArt a été conçu et fabriqué afin d’assurer une sécurité optimale. Cependant certaines précautions s’appliquent chaque fois que vous utilisez votre vélo de course. • Lisez entièrement le manuel avant l’assemblage et l’utilisation. Veuillez aussi noter les consignes de sécurité...
  • Page 7 2. CONSIgNES DE SéCURITé (SUITE) Ce vélo n’est pas destiné à être utilisé par des personnes (y compris des enfants) dont les capacités physiques, sensorielles ou mentales sont réduites ou qui ne disposent pas de l’expérience ou du savoir nécessaires, sauf si celles-ci ont au préalable été...

  • Page 8: List Of Parts

    3. LIST Of PARTS Assembly Parts Qty. No. Qty. Name Name Pedestal assembly Rear support Bottle holder Seat bottom Main frame Hardware kit Pedal set...
  • Page 9 3. LIST Of PARTS (CONTINUED) Components in the Hardware Kit Name Qty. Specification Notes L-shaped Allen wrench L-shaped Allen wrench Double open-end wrench (12*15) Screwdriver handle Green Screwdriver bit Flat and Phillips Components on the Product Name Specification Notes Mushroom top inner hex screw M8*L20 and washer Inner hex screw...

  • Page 10: Assemble The Product

    4. ASSEMBLE THE PRODUCT Follow instructions below to assemble this product. Note that in this manual the words “left” and “right” are used to refer to the product and its parts. As such, these designations correspond to the “left” and “right” sides of a person in position to exercise on this product.

  • Page 11: Step 2 Install The Rear Support

    STEP 2 Install the Rear Support Please follow steps (a) through (c) to install the rear support. (a) Remove screws (21) from the rear support (A5). (b) Insert the stem of the rear support (A5) into the rear tube of the main frame (A3).

  • Page 12: Step 3 Install The Bottle Holder

    STEP 3 Install the Bottle Holder Please follow steps (a) through (b) below to install the bottle holder. (a) First remove screws (24) from the pedestal assembly(A1). (b) Use these screws (24) to secure the bottle holder (A2) onto the pedestal assembly (A1).

  • Page 13: Step 4 Install The Pedestal

    STEP 4 Install the Pedestal Please follow steps (a) through (c) below to install the pedestal assembly. (a) First pull the front cover (25) off the main frame (A3) and then remove screws (22) from the main frame (A3). (b) Connect the cable in the pedestal assembly (A1) to the cable in the main frame (A3).

  • Page 14: Step 5 Install The Seat Bottom And Pedals

    STEP 5 Install the Seat Bottom and Pedals Please follow steps (a) through (c) to install the seat bottom and the pedals. (a) First remove screws (23) from the seat bottom (A6). (b) Place the seat bottom (A6) onto its mount on the main frame (A3). Then use screws (23) to secure the seat bottom (A6) to the main frame (A3).

  • Page 15: Step 6 Move The Product

    STEP 6 Move the Product Lift the rear support and push, rolling the bike into place for use. (a) Stand in front of the bike, press one foot on the roller. (b) Put both hands onto the handlebars. (c) Title the bike and roll it into place.

  • Page 16: Step 7 Level The Bike

    STEP 7 Level the Bike For the user’s safety and the proper functioning of the product, this bike must sit level on a flat floor. If necessary, adjust the levelers by following instructions (a) through (c) below. (a) Loosen the leveler nut. (b) Rotate the leveler foot downward so it firmly touches the floor.

  • Page 17: Step 8 Seat Fore And Aft Adjustment

    STEP 8 Seat fore and Aft Adjustment (a) Push the seat adjustment level down to loosen the seat. (b) Push the seat to a suitable position toward the front or toward the back of the unit. The lift the lever up to secure the seat into place.

  • Page 18: Step 9 Seat Height Adjustment

    STEP 9 Seat Height Adjustment (a) To adjust the seat upward, simply pull the seat upward. (b) To adjust the seat downward, lift the seat adjustment knob and push the seat downward to a suitable position. Then release the knob to secure the seat in place.

  • Page 19: Step 10 How To Connect The Ground Wire

    STEP 10 How to Connect the ground Wire Note: A ground wire and the following instructions are required by European safety standards. The ground wire is not required by North American safety standards. Installation instructions: Please use screws and washers to secure one end of the ground wire to the product frame as shown and the other end to the building electrical ground.

  • Page 20: Understand The C575U Display

    5. UNDERSTAND THE C575U DISPLAy DISPLAy Overview The C575U upright cycle is designed for user convenience. With better feedback about your workout, you get better results. The following explains the display key and window functions. Please read this manual, understand the display functions, and thereby get optimum enjoyment and benefit from this product.

  • Page 21: Display Specifications

    DISPLAy Specifications ● Workout level (resistance level): 1 - 40 ● METS: 0.0 - 99.0 ● Time: 0:00 - 300:00 ● Distance: 0.00 - 9999 km or mile ● Calories: 0.0 - 9999 kcal ● RPM: 5 – 150 (Range shown) ●...
  • Page 22 DISPLAy Keys (Continued) fAT BURN – This workout program provides 1 - 20 different difficulties to select from. fIT TEST – Press this key to enter a FIT TEST program and start the fitness test. CUSTOM HR – This heart rate control program allows you to set your own target heart rate.

  • Page 23: Operate The Product

    DISPLAy Keys (Continued) CHANgE DISPLAy – This key controls the exercise feedback window, which has two rows: The top row shows CALORIES, LEVEL, TIME, DISTANCE; the bottom row shows RPM, METS, SPEED, HUMAN WATTS. Corresponding LEDs light to indicate the active row of exercise feedback. Press the CHANGE DISPLAY key to toggle between top and bottom feedback row views.

  • Page 24: Operation Display

    OPERATION Start a Workout Program (Continued) ● The TIME setting range is from 5:00 to 300:00, with a default value of 30:00. If the program time limit is activated in engineering mode, the max time can be entered will change accordingly.. Use ▲/▼ keys or numeric keys (0-9) to make your selection.

  • Page 25: Operation Cool Down

    OPERATION Display (Continued) ● Switch program is not allowed during FIT TEST program. OPERATION Cool Down Once the workout goal (time, distance, or calorie expenditure) has been obtained, the product will enter a two-minute cool down period. The display will count down from two to zero. When the countdown reaches zero, the cool down period will end.
  • Page 26 OPERATION Workout Programs (Continued) RANDOM This program provides a near infinite number of randomly generated workouts. A new workout illustration appears each time the RANDOM key is pressed. fAT BURN In this program, there are 1-20 different difficulty levels to select from. During program setting, before entering program mode, you must first select the STAGE, range from 1 - 20 (default value is STAGE 5).
  • Page 27 OPERATION Workout Programs (Continued) CARDIO/WEIgHT LOSS/CUSTOM HR In these heart rate control programs, the resistance level will automatically change to keep the exerciser’s pulse at the optimum rate for achieving his or her fitness goals. Target heart rates are calculated based on a standard “maximum” heart rate for the exerciser’s age.

  • Page 28: Operation User Preferences And Component Versions

    OPERATION User Preferences and Component Versions Basic settings determine units of measure and show total distance and time, along with display and drive board program version numbers. To access this information, at the startup banner screen, hold the CHANGE DISPLAY key for two seconds.

  • Page 29: About Heart Rate Detection

    7. ABOUT HEART RATE DETECTION Heart rate detection functions are selected at the time of purchase. Not every product has every type of heart rate detection. The following explains factors that influence the performance of two of the most common types of heart rate detection devices.

  • Page 30: Guidelines For Exercise

    Note that in dry areas in particular, static electricity can interfere with unit operation and shock people. To discharge static electricity from your body, touch something else before touching metal on the product. 8. gUIDELINES fOR EXERCISE HOW HARD SHOULD I EXERCISE? Studies show that to benefit from aerobic exercise, people need to maintain a certain heart rate during their workouts.

  • Page 31: Accessories

    9. ACCESSORIES There are accessories attached to this console; some are standard and some are optional. The following explains the details of each accessory and its function. USB CHARgER (Standard) The USB charger will provide 5V 500mA voltage for the smart phone or other devices charging.

  • Page 32: Accessories Entertainment Cap

    9. ACCESSORIES (CONTINUED) Entertainment Cap (a) RFID member card slot: work with both optional SA WELL+ and ECOFIT member cards. (Not available yet.) (b) Bluetooth connection button: press this button to unpair the smart phone SA WELL+ App. (c) USB port: this port is used for device charging as well as optional data transferring.

  • Page 33: Accessories Mye Wireless Tv Audio_Channel Receivers

    9. ACCESSORIES (CONTINUED) MyE Wireless TV Audio_Channel Receivers: If your equipment has been installed MYE Wireless TV Audio_Channel Receivers, the display must has Channel Keys. Please make sure your equipment is with the correct sticker as below. (a) None Treadmill (Bike, Elliptical and Stepper...etc.) Left display: Without Channel Keys.
  • Page 34 9. ACCESSORIES (CONTINUED) MyE Wireless TV Audio_Channel Receivers fuctions: 1. The receiver has two kinds of module as below. (Note: MyE Wireless TV Audio_Channel Receivers and Module not provided.) (1). MC3R-9(900MHZ) must work with MYE Wireless TV Audio_Channel Receivers MWTD-S9. (2).

  • Page 35: Maintenance

    10. MAINTENANCE Maintenance topics are presented below in the following order: maintenance schedule, task list, one-year maintenance log, and electronics block diagram. MAINTENANCE Message The following message can appear on this product for diagnostic purposes. ERR0R_8_x Error messages will appear on the display when the drive board communication is abnormal.

  • Page 36: Maintenance Schedule

    MAINTENANCE Schedule Area Day Week Month Quarter year Notes 1 Exterior Clean Inspect and secure Screws loose parts Seat Wipe clean with a bottom slightly damp towel. Inspect and secure Pedals loose parts...

  • Page 37: Maintenance Task List (Cycles)

    MAINTENANCE Task List (Cycles) Like cars, fitness products require maintenance. Regular maintenance extends product life, and failure to maintain products can void the manufacturer’s warranty. Copy the maintenance log sheet, and record maintenance work for each fitness product. Daily tasks 1.

  • Page 38: Maintenance One-Year Maintenance Log

    MAINTENANCE One-year Maintenance Log Facility:_______________________ Supervisor:____________________ Product model number:__________ Serial number:_________________ Start date: ____________________ End date:_____________________ Daily Tasks Weeks 1-7 Weeks 8-14 Weeks 15-21 Week 22-28 Completed Daily Tasks Week 29-35 Week 36-42 Week 43-49 Week 50-52 Completed Weekly Tasks Weeks 1-7 Weeks 8-14 Weeks 15-21 Weeks 22-28...

  • Page 39: Maintenance Electronics Block Diagram

    MAINTENANCE Electronics Block Diagram RFID Board Control Board USB Board Continua Adapter Board Option Bluetooth Connection key CSAFE Board Numeric Key Board HRC Board HTR Board Head Phone Board iPod Audio Board Option Contact HTR plates Model no. board Speed sensor Drive Board Fuse ○...
